Chapter 5 Operation

When the unit is powered up, do not move the flipper arm by hand.

5.1 Manual Operation

The Filter Flipper offers a fully featured motion control capability including Transit
Time and I/O Configuration. When the unit is connected to the PC, these parameters
are automatically set to allow "out of the box" operation with no further "tuning"
required. However, further adjustment is possible via the Kinesis Server software -
see Chapter 6.
The flip action is activated manually by a button on the top of the unit, or by handset
supplied.
The unit features two SMA connectors, marked DIG IO 1 & DIG IO 2. A TTL trigger
input (configured in the Settings panel - see Section 6.3.) causes the flipper to toggle
to the next state. If the user button or another trigger signal comes in before the end
of the move then the flipper will ignore the demand until the current move is complete.
If power is removed, the unit may remain in the same position, or due to
The external DIG IO connectors can be configured as input or output to accept
various different signal types. A particular IO configuration can be 'persisted
(saved) within the unit for future use when operating in Stand Alone mode
without a control PC - see Section 6.3. for more information.

5.2 PC-Base Operation

5.2.1 Introduction
The following brief tutorial guides the user through a typical series of moves and
parameter adjustments performed using the software. It assumes that the unit is
electrically connected as described in Section 4.2. and that the Software is already
installed - see Section 4.1.
As the unit is raised and lowered, items can become trapped in the
mechanism. During operation, keep fingers, clothing and tools away from
When the unit is powered up, do not move the flipper arm by hand.
14
Warning
Notes
gravity, may move to the lower limit.
Warning
any moving parts.
