Ethernet Requirements

You can connect multiple network printers to one PC. The maximum number of printers depends
on the capacity of the network to deliver data to the printer.
The following components are required to install a printer on a network:
An Ethernet network that uses the TCP/IP protocol and can run at one of the following:

1Gbase-T (1 gigabyte per second) or 100base-T (100 megabits per second).
An Ethernet cable to connect the printer to the network. (An Ethernet cable is not supplied

with the printer.)
A PC that meets the

with, the network.

USB Requirements

You can connect up to eight card printers to a PC using USB cables.
To install a printer using a USB connection, the following components are required:
A high-speed USB port. USB 3.0 is preferred.

A USB cable to connect the printer to the PC. A USB cable is supplied with the printer.

A PC that meets the

If you need to connect two card printers to a PC with one USB port, use a single, independently
powered USB hub to which you can connect both printers.

Electrical Requirements

The power supply detects the input voltage and works within the range stated.
Universal 100–200Vac, single-phase/
50–60 Hz/1.6Amp
If your system includes additional components, refer to the documentation for the
appropriate component for its electrical requirements.
2
"PC Requirements"
"PC Requirements"
Electrical Requirements
Input
on page 1, and is connected to, and communicating
on page 1.
Output
24V/3.0Amp/72W
Printer Installation
