Clearance Requirements; Operating Environment - Entrust EM1 Installation And Administrator's Manual

Clearance Requirements

The following measurements show the printer dimensions when the input hopper and printer
cover are open and the power cord is connected. Provide at least 3 inches (76.2 mm) of
additional clearance around the system to maintain access to the power cord and data cables, to
load and remove cards and supplies, and to provide ventilation.
17.5 in
444 mm
13.1 in
333 mm

Operating Environment

Use the following guidelines when operating the printer:
Operating temperature
Operating humidity
4
10.9 in
277 mm
4.2 in
107 mm
60°–95° F (15°–35° C)
20–80%, non-condensing
21.9 in
556 mm
Printer Installation
17.5 in
444 mm
