Summary of Contents for ZOLL AutoPulse 100
- Page 1 Resuscitation System Model 100 User Guide P/N 12555-001 Rev 9...
- Page 2 The information in this User Guide applies to the ZOLL AutoPulse Resuscitation System Model 100. ZOLL shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
-
Page 3: Table Of Contents
User Guide Table of Contents Figures ..............................v Tables ..............................vii Preface ..............................ix Who Should Read this Guide ......................ix General Warnings and Precautions ....................ix Symbols ..............................xi ® 1 Introduction of the AutoPulse System ..................1-1 1.1 Indication for Use .......................... 1-1 1.2 Description of the System ...................... - Page 4 User Guide 3.2 Starting Chest Compressions ......................3-7 3.3 Ending Active Device Use ......................3-14 3.4 Preparing the Platform for Its Next Use ..................3-14 3.5 Periodic Electrocardiogram (ECG) Monitoring and/or Defibrillation ........3-14 3.6 Patient Alignment and Securing for Transport ................3-15 3.6.1 Recommended Method of Patient Extrication ..............
-
Page 5: Figures
User Guide Figures Figure 1-1 The AutoPulse System ...................... 1-2 Figure 1-2 Platform (Patient and Back Surfaces) ................1-3 Figure 1-3 On/Off Button Location ....................1-4 Figure 1-4 User Control Panel ......................1-5 Figure 1-5 Low Battery Warning ......................1-9 Figure 2-1 Sliding the LifeBand Band Clip into the Driveshaft Slot .......... - Page 6 User Guide Figure 3-21 Connected Display Panel Screen ................... 3-21 Figure 3-22 Transmitting... Display Panel Screen ................3-22 Figure 4-1 Battery Charger with Charging Bay .................. 4-1 Figure 4-2 Battery Charger Control Panel ..................4-2 Figure 5-1 Low Battery Warning ......................5-1 Figure 5-2 Replace Battery Screen ......................
- Page 7 User Guide Tables Table 1-1 Patient/AutoPulse System Operating Parameters ..............1-1 Table 1-2 Battery Charge Status Indicator Specifics ................. 1-10 Table 1-3 Operating Characteristics ....................1-10 Table B-1 Operating Parameters ......................B-1 Table B-2 Physical Specifications ...................... B-1 Table B-3 Environmental Specifications .................... B-2 Table B-4 Li-Ion Battery Specifications .....................
- Page 8 User Guide [This page left intentionally blank.] Page viii...
-
Page 9: Preface
User Guide Preface ® This document describes the operating steps and maintenance requirements for the AutoPulse Resuscitation System Model 100. Proper use of the AutoPulse System requires a thorough understanding of the product, appropriate training and practice. Please read the entire User Guide before operating the AutoPulse System. Who Should Read this Guide This document should be read by personnel who will use this product and who are trained in Basic Life Support (BLS) and/or Advanced Life Support (ALS) techniques. - Page 10 AutoPulse System will perform improperly if non-approved accessories are used. Caution: Only use ZOLL Batteries specifically designed for use with the AutoPulse System. The use of other batteries may cause permanent damage to the AutoPulse System and will void the warranty.
-
Page 11: Symbols
User Guide Symbols The symbols below may be found in this User Guide, on the Platform, the LifeBand, the Multi- Chemistry Battery Charger (Battery Charger), or Li-Ion Battery. Follow instructions for use Date of Manufacture Manufacturer Authorized Representative Serial Number Defibrillation Protected, Type BF Patient Connection Degree of Protection Provided by Enclosure Per IEC 60529 IP25... - Page 12 User Guide Do Not Incinerate Fuse DC Voltage Caution: Charging Ready Fail Test Cycle Power Caution Catalog number Prescription use only ONLY Importer Medical device Page xii...
-
Page 13: Introduction Of The Autopulse ® System
User Guide ® Introduction of the AutoPulse System The AutoPulse System is an automatic cardiopulmonary resuscitation (CPR) product. Indication for Use The AutoPulse is intended to be used as an adjunct to manual CPR, on adult patients only, in cases of clinical death as defined by a lack of spontaneous breathing and pulse. -
Page 14: System Components
User Guide Battery Charger User Control Panel AutoPulse Platform LifeBand Li-Ion Batteries (Primary and Spare) Figure 1-1 The AutoPulse System System Components Figure 1-1 shows the main components of the AutoPulse System. The AutoPulse System consists of the following: • Platform •... -
Page 15: Lifeband Load-Distributing Band
User Guide ON/OFF Button User Control Panel Back Surface Battery Cooling Vent Start/Continue Button Stop/Cancel Button Patient Alignment Carry Handle Reference Cooling Vent LifeBand ® AutoPulse Roller Guide Slotted Drive Shaft Patient Surface Figure 1-2 Platform (Patient and Back Surfaces) 1.3.2 LifeBand Load-distributing Band The LifeBand is a load-distributing band that consists of a cover plate and two bands integrated with a... -
Page 16: User Controls And Indicators
User Guide Battery Charger: The Battery Charger is a stand alone unit designed to charge and automatically maintain the Li-Ion Battery. The Battery Charger has two charging bays, and each bay has its own indicators. The Battery should always be properly maintained and be fully charged and ready for use before deploying the AutoPulse. -
Page 17: Start/Continue Button
User Guide Alert (red) Display Panel Power (green) Increase Contrast Move Up Select Choice Decrease Contrast Move Down Tone Mute Stop/Cancel Start/Continue Stop/Cancel Menu/Mode Switch Start/Continue Figure 1-4 User Control Panel 1.4.2.1 Start/Continue Button The green Start/Continue button is active when “Start” or “Continue” appears on the display panel above the button and its green LED is illuminated. -
Page 18: Menu/Mode Switch Button
User Guide 1.4.2.3 Menu/Mode Switch Button On initial power-up the gray Menu/Mode Switch button functions as the Menu button. Pressing this button allows you to: Enter the communication mode View last patient session information View AutoPulse Platform information View AutoPulse Battery information For a complete description of the available information and how to access it, refer to section Section 3.7, “Viewing Platform Information,”... -
Page 19: Select Choice Button
User Guide 1.4.2.5 Select Choice Button Pressing the Select Choice button selects the currently highlighted menu or list item. 1.4.2.6 Tone Mute Button The ventilation and pause tones are always generated at the appropriate times by the system and cannot be turned off, but they can be muted for a short period of time as set in the Administration Menu (refer to section Section 2.3, “Administrative Menu: User Pre-set Options,”... -
Page 20: Increase/Decrease Contrast Button
User Guide 1.4.2.7 Increase/Decrease Contrast Button Pressing the Increase Contrast button (plus sign) increases the contrast of the display panel screen. Each key press increases the contrast of the display panel screen by one level. There are a total of eight contrast levels. Pressing the Decrease Contrast button (minus sign) decreases the contrast of the display panel screen. -
Page 21: Figure 1-5 Low Battery Warning
User Guide 3 0 : 2 LOW BATTERY Figure 1-5 Low Battery Warning When five minutes of active operation remain on a Battery, the User Control Panel will give a “Low Battery” indication (see Figure 1-5). The “Low Battery” indication will remain on until the Battery is replaced or depleted. -
Page 22: Performance Characteristics
User Guide Table 1-2 Battery Charge Status Indicator Specifics Battery Charge Icon Bars Showing Charge Level No bars showing. The Battery has been depleted. Replace the Battery immediately. One bar showing. The Battery’s capacity is less than one-third of a full charge. Be prepared to exchange this Battery with a fully-charged Battery. -
Page 23: Preparing The Autopulse System For Use
User Guide Preparing the AutoPulse System for Use The AutoPulse System is delivered fully assembled, except for the LifeBand and the AutoPulse Battery. LifeBand Load-distributing Band Note: Do not cut the LifeBand before removing it from the Platform. Cutting the LifeBand may cause the Platform to report a Fault and will require specific steps to clear that Fault. -
Page 24: Figure 2-2 Seating The Lifeband Band Clip Properly Into The Driveshaft Slot
User Guide Make sure that the band clip is seated properly and fully into the slot on the driveshaft (see Figure 2-2). Note: If the band clip is properly seated, you should be able to turn the driveshaft in each direction by hand. -
Page 25: Figure 2-3 Snapping The Lifeband Cover Plate Into Place
User Guide LifeBand Cover Plate Alignment Arrows Figure 2-3 Snapping the LifeBand Cover Plate into Place Flip down and snap into place the hinged belt guards of the LifeBand cover plate to engage the LifeBand chest bands to the rollers (see Figure 2-4). Belt Guard Figure 2-4 Flip Down the Hinged Belt Guards of the LifeBand... -
Page 26: Removing The Lifeband
User Guide 10. Turn the Platform over and press the On/Off button to power it up. If the User Control Panel reports a user advisory, check the installation of the LifeBand band clip into the slot in the driveshaft. 2.1.2 Removing the LifeBand Note: Please do NOT cut the LifeBand before removing it from the Platform. -
Page 27: Figure 2-6 Pinching The Locking Tabs Of The Lifeband
User Guide Using both hands, pinch together the locking tabs of the LifeBand cover plate and firmly pull the plate straight up and away from the Platform (see Figure 2-6). Figure 2-6 Pinching the Locking Tabs of the LifeBand Page 2-5... - Page 28 User Guide Guide Plate Figure 2-7 Removing the LifeBand from the Platform Warning: Removing the band clip when the driveshaft is not at its home position (see Figure 2-10) will result in a permanent User Advisory (45) that the user will not be able to clear. This may be the case if the LifeBand has been cut.
-
Page 29: Removing A Lifeband That Is Cut Or Not In The Home Position
User Guide Inspect the new, replacement LifeBand for cuts or tears. Install the new LifeBand following the procedures in Section 2.1.1, “Installing the LifeBand”. 2.1.2.1 Removing a LifeBand that is Cut or Not in the Home Position The chest band must be completely unwound from the driveshaft before it is removed. When the chest band is completely unwound the seam is visible and the driveshaft rests in the Home Position (see Figure 2-10). -
Page 30: Figure 2-9 Positioning The Lifeband For Removal
User Guide If the chest band is not completely unwound from the driveshaft follow this procedure: Figure 2-9 Positioning the LifeBand for Removal Once the cover plate is removed, take hold of the chest band on either side of the driveshaft and pull both bands outward. -
Page 31: Battery Installation And Removal
User Guide Battery Installation and Removal Remove a charged Battery from the Battery Charger. Ensure the Battery is fully charged before insertion into the Platform (refer to the AutoPulse Power System User Guide for more information). Replace the Battery remaining in the Platform with one that is fully charged. 2.2.1 AutoPulse Li-Ion Battery Installation and Removal Finger Latch... -
Page 32: Administrative Menu: User Pre-Set Options
Locking Bar and allow the Li-Ion Battery to be pulled straight out until it fully clears the Battery compartment. Caution: Only use ZOLL Batteries specifically designed for use with the Platform. The use of other batteries may cause permanent damage to the Platform and will void the warranty. -
Page 33: Figure 2-12 Administrative Menu
User Guide 3 0 : 2 A D M I N M E N U S e t M o d e ( 3 0 : 2 o r C o n t ) S e t M o d e ( 3 0 : 2 o r C o n t ) S e t M u t e D u r a t i o n ( 3 0 s ) S e t To n e V o l u m e ( H i g h ) V i e w L a s t P a t i e n t I n f o... -
Page 34: Figure 2-14 Compression Mode Menu
User Guide To exit from the Administrative Menu, press the “START” (green) button under the word “RESTART.” The Platform will restart and place you into the idle state, ready for patient alignment or for system power-down. Note: The current setting is displayed in the parenthesis after the main menu item. 3 0 : 2 M O D E 1 5 : 2 o r C o n t i n u o u s... -
Page 35: Figure 2-15 Mute Duration Menu
User Guide 3 0 : 2 M U T E D U R AT I O N 3 0 s e c o n d s 3 0 s e c o n d s 6 0 s e c o n d s 1 2 0 s e c o n d s D i s a b l e d b a c k... -
Page 36: Figure 2-16 Ventilation/Pause Tone Volume Menu
User Guide 3 0 : 2 VENT/PAUSE TONE VOLUME H i g h L o w b a c k Figure 2-16 Ventilation/Pause Tone Volume Menu The “Set Tone Volume” menu item allows you to select the volume of the audible tone sequence that is used to cue for ventilation during active compressions and to alert the operator that the system has been deliberately stopped (paused) while actively doing compressions. -
Page 37: Figure 2-17 Continuous Mode Ventilation Tone Menu
User Guide CONTINUOUS C O N T V E N T T O N E 1 Beep 1 Beep 3 Beeps b a c k Figure 2-17 Continuous Mode Ventilation Tone Menu The “Set Cont Vent Tone” menu item allows you to select how many ventilation tones sound when in Continuous Compression Mode. - Page 38 User Guide [This page left intentionally blank.] Page 2-16...
-
Page 39: Using The Autopulse System
- similar to that which is used in auto racing - is suggested for roles and positions of the staff involved in performing defibrillation and using the AutoPulse System. Your local ZOLL representative can provide you with appropriate detailed instructions based upon the setting in which you work (EMS or hospital) and the number of clinicians that are typically involved in dealing with sudden cardiac arrest. -
Page 40: Figure 3-2 Self-Test Display Panel Screen
User Guide Note: Make sure that no User Advisory, Fault or System Error messages display. 3 0 : 2 I n i t i a l i z i n g . . . Figure 3-2 Self-Test Display Panel Screen The Platform indicates that it is ready for use (see Figure 3-3). -
Page 41: Figure 3-4 Cutting Patient Clothing And Positioning Of Autopulse
User Guide After assessing the patient’s condition, sit the patient up and make a single cut down the back of the patient’s clothing (see Figure 3-4), or undo any ties on the back of the gown in a hospital. The posterior defibrillation/pacing pad may be placed on the patient's back at this time if the local protocol calls for anterior-posterior placement. -
Page 42: Figure 3-5 Removal Of All Clothing From The Torso
User Guide Grasp the clothing by the sleeves and pull down toward the ankles to remove all of the clothing from both the front and back of the torso (see Figure 3-5). The anterior pad(s) may be placed at this time. Figure 3-5 Removal of all Clothing from the Torso Page 3-4... -
Page 43: Figure 3-6 Correct Patient Alignment
User Guide Position the patient so that he/she is centered laterally (from left to right) and that the armpits are aligned with the Platform using the yellow line positioning guides on the platform as shown in Figure 3-6. Warning: Do not place or position the patient on the Platform in either a facedown orientation or on the patient's side. -
Page 44: Figure 3-7 Aligning The Lifeband
User Guide Band Band LifeBand ® Alignment Slot LifeBand Alignment Tab Figure 3-7 Aligning the LifeBand Close the LifeBand around the patient's chest. Caution: Make sure that the LifeBand is not twisted before automatic compressions begin. Note: AED or defibrillation pads are not components of the LifeBand. To properly align the two sides of the LifeBand: Place band 1 on top of patient’s chest (see Figure 3-7). -
Page 45: Starting Chest Compressions
User Guide Figure 3-8 Fastening the LifeBand Starting Chest Compressions Make sure that the yellow upper edge of the LifeBand is aligned with the patient's armpits, and is directly over the yellow line on the Platform. Also make sure that there are no obstructions, such as clothing, straps or equipment, with the bands. -
Page 46: Figure 3-9 Analyzing Patient Size Display Panel Screen
User Guide Press and release the Start/Continue button once. The Platform automatically adjusts the bands to the patient's chest (see Figure 3-9). Warning: Do not touch the patient or the LifeBand while the Platform is analyzing the patient’s size. 3 0 : 2 A n a l y z i n g P a t i e n t s i z e . -
Page 47: Figure 3-10 Verifying Patient Alignment Display Panel Screen
User Guide 3 0 : 2 C h e c k p a t i e n t a l i g n m e n t . S T O P START Figure 3-10 Verifying Patient Alignment Display Panel Screen After the 3 second verify patient alignment pause is complete, compressions will automatically begin. -
Page 48: Figure 3-11 Chest Compression Display Panel Screen
User Guide 3 0 : 2 0 0 : 1 7 COMPRESSING ... S w i t c h t o STOP CONTINUOUS Figure 3-11 Chest Compression Display Panel Screen Depending on the Mode setting in Administrative Menu (refer to section Section 2.3, “Administrative Menu: User Pre-set Options,”... -
Page 49: Figure 3-12 Ventilation Pause Display Panel Screen
User Guide 3 0 : 2 VENTILATE 0 0 : 2 4 S w i t c h t o STOP CONTINUOUS Figure 3-12 Ventilation Pause Display Panel Screen Note: Positive pressure ventilation can be performed synchronously with any decompression and/or during the ventilation pause. -
Page 50: Figure 3-13 Mode Change Confirm Display Panel Screen
User Guide 3 0 : 2 0 0 : 0 4 COMPRESSING ... Confirm STOP CONTINUOUS Figure 3-13 Mode Change Confirm Display Panel Screen If 30:2 on-the-fly mode switching has been enabled you may press the gray Menu/Mode switch button to switch between 30:2 and continuous compressions. If 15:2 on-the-fly mode switching has been enabled you may press the gray Menu/Mode switch button to switch between 15:2 and continuous compressions. -
Page 51: Figure 3-14 Stopping Compressions Display Panel Screen
User Guide 3 0 : 2 S t o p p i n g . . . Figure 3-14 Stopping Compressions Display Panel Screen 3 0 : 2 R e a l i g n p a t i e n t , 0 0 : 2 6 c l o s e L i f e B a n d , p r e s s C O N T I N U E... -
Page 52: Ending Active Device Use
User Guide Ending Active Device Use After either successful resuscitation or termination of activities, press the Stop/Cancel button followed by the On/Off button. The Stop/Cancel button action will cease the compression cycles and relax the LifeBand (see Figure 3-14). The On/Off button action will power down the Platform. ®... -
Page 53: Patient Alignment And Securing For Transport
User Guide Patient Alignment and Securing for Transport Warning: The Platform is not intended for carrying or transporting a patient. The Platform should be secured to the top of a backboard or other equipment used to carry or transport the patient, if necessary. -
Page 54: Recommended Method Of Patient Extrication
User Guide 3.6.1 Recommended Method of Patient Extrication This extrication method includes the AutoPulse Shoulder Restraint, Head Immobilizer, and Soft Carry Stretcher. Head Immobilizer Shoulder Restraint Figure 3-16 Securing the Patient for Transport Page 3-16... -
Page 55: Figure 3-17 Transporting The Patient
Maintain the LifeBand at 90 degrees with the Platform. Ensure that the LifeBand is not impeded by anything such as the patient's arms, clothing, straps, and buckles that may interfere with the movement of the LifeBand. For more information about strapping and patient restraint options, contact ZOLL at +1.800.348.9011 (or +1.978.421.9655). Page 3-17... -
Page 56: Viewing Platform Information
User Guide Viewing Platform Information On initial power-up, pressing the Menu/Mode Switch button allows you to: Enter Communication mode (refer to Section 3.8.1, step 3 on page 3-20) View last patient session information View Platform information View Battery information Items 2-4 above may also be accessed from the Administrative Menu (refer to section Section 2.3, “Administrative Menu: User Pre-set Options,”... -
Page 57: Uploading Platform Information To Your Pc
Prior to using the Platform infrared communication port, the Code Review software must be installed on your host computer. This software may be acquired from ZOLL Data Systems (www.zolldata.com) or from your ZOLL Data Systems representative (+1.978.421.9655). Installation instructions, the software's User Guide and system requirements are provided with the software. -
Page 58: Information Upload Procedure
User Guide 3.8.1 Information Upload Procedure Turn on your PC (the host computer). Start the Code Review software. 3 0 : 2 MENU E n t e r C o m m M o d e V i e w L a s t P a t i e n t I n f o V i e w P l a t f o r m I n f o V i e w B a t t e r y I n f o e x i t... -
Page 59: Figure 3-20 Waiting For Connection
User Guide W a i t i n g f o r C o n n e c t i o n . . . RESTART Figure 3-20 Waiting for Connection... Display Panel Screen Upon entering the Communication Mode the platform will immediately attempt to establish a communication connection with the host computer. -
Page 60: Figure 3-22 Transmitting
User Guide U p l o a d i n g D a t a . . . Figure 3-22 Transmitting... Display Panel Screen From your computer send the start transmission of data command. See the Code Review software User Guide for instructions. The “Transmitting...” panel screen will be displayed while the patient information is being transferred between the platform and your computer. -
Page 61: Maintaining The Autopulse System
User Guide Maintaining the AutoPulse System Charging Batteries in the Battery Charger The Battery Charger can charge and maintain up to two Li-Ion Batteries. To charge a Battery, follow these steps: Slide the Battery into an available charging bay (see Figure 4-1). Make sure that the Battery locks into place (locking bar engaged). -
Page 62: Cleaning The Platform
User Guide The Battery Charger automatically detects the presence of the Li-Ion Battery within 5 seconds. The Battery Charger’s status will be indicated on the control panel (see Figure 4-2). Figure 4-2 Battery Charger Control Panel The Battery Charger will automatically perform a Test-Cycle when needed. This will automatically occur at a minimum of once every 30 days (For more information, refer to the AutoPulse Power System User Guide). -
Page 63: Storing The Platform
The AutoPulse System has no user-serviceable parts, nor does the device require regular maintenance. There are no components that require calibration. Users should periodically inspect the AutoPulse system to ensure the device’s functionality. In case of repair or service, contact ZOLL at +1.800.348.9011 or +1.978.421.9655. - Page 64 Inspect the Battery, including the connector for physical damage that would preclude its insertion in either the platform or the Battery Charger. Contact ZOLL as needed. Inspect the Battery for cracks in the Battery case exposing internal components. If the Battery is damaged, do not attempt to place the Battery into the Platform- this can cause damage to the internal connector of the Platform.
-
Page 65: Disposal And Recycling
User Guide If the product malfunctions or fails any of these inspections, contact ZOLL at +1.800.348.9011 or +1.978.421.9655. Disposal and Recycling 4.5.1 Platform Dispose of in accordance with local governing ordinances and recycling plans for electronic waste. 4.5.2 Battery Charger Dispose of in accordance with local governing ordinances and recycling plans for electronic waste. - Page 66 User Guide [This page left intentionally blank.] Page 4-6...
-
Page 67: Troubleshooting Procedures
User Guide Troubleshooting Procedures In the event of a user advisory, fault or system error, the User Control Panel Alert light-emitting diode (LED) illuminates (refer to Section 1.4, “User Controls and Indicators”). Consider the information in this chapter. Warning: If a persistent fault or system error occurs during active operation, immediately revert to manual CPR. -
Page 68: Troubleshooting User Advisories And Faults
Remove and replace the LifeBand with a new LifeBand and then press the Start/Continue button again. Check the Platform for blocked vents. If a User Advisory or Fault indicator cannot be cleared, record the User Advisory or Fault number and contact ZOLL at +1.800.348.9011 or +1.978.421.9655. Page 5-2... -
Page 69: Figure 5-3 A User Advisory Screen
User Guide In either User Advisory state or the Fault State, pressing the gray Menu/Mode Switch button, under the word “menu” allows you to access the Platform information menu (refer to section Section 3.7, “Viewing Platform Information,” on page 3-18). 3 0 : 2 USER ADVISORY(02) P u l l u p L i f e B a n d ,... -
Page 70: User Advisory (45)
Do not attempt to defeat the shaft lock mechanism, which keeps the driveshaft at its home position when a LifeBand is not installed. If a User Advisory (45) can't be cleared, Power off the Platform and contact ZOLL at +1.800.348.9011 or +1.978.421.9655. -
Page 71: Troubleshooting Errors
In the event of a System Error (see Figure 5-6), you can take no steps to return the Platform to normal operation. The Platform has detected an unrecoverable problem and cannot be restarted. Therefore, you must: Begin manual CPR immediately. Contact ZOLL at +1.800.348.9011 or +1.978.421.9655. 3 0 : 2 SYSTEM ERROR OUT OF SERVICE... - Page 72 User Guide [This page left intentionally blank.] Page 5-6...
-
Page 73: Appendix A Autopulse Daily Checklist
Charge Status Icon on the Platform User Control Panel should also be visible with 4 bars, if not replace Battery with a fully charged Battery from the Battery Charger. If the Platform red ALERT LED remains on, refer to the Chapter 5, “Troubleshooting Procedures”. If the RED LED can not be resolved, contact ZOLL. Page A-1... - Page 74 User Guide [This page left intentionally blank.] Page A-2...
-
Page 75: Appendix B Technical Specifications
Platform Physical Table B-2 Physical Specifications Category Specifications Manufacturer ZOLL Circulation, Inc. Size (L×W×H) 32.5 in. by 17.6 in. by 3.0 in. (82.6 cm by 44.7 cm by 7.6 cm). Weight (excluding Battery) 20.5 lbs. (9.3 kg). Display Dot matrix liquid crystal display (LCD), actively backlit, adjustable contrast. -
Page 76: Platform Environmental
Li-Ion Battery Physical and Environmental Table B-4 Li-Ion Battery Specifications (Page 1 of 2) Category Specifications Manufacturer ZOLL Circulation, Inc. Model Number 8700-0752-01 Size (L×W×H) 11.5 in. by 3.2 in. by 2.2 in. (29.2 cm by 8.1 cm by 5.7 cm) Weight 3.0 lbs. - Page 77 User Guide Table B-4 Li-Ion Battery Specifications (Page 2 of 2) Category Specifications Capacity 2500 mAh (typical) Current (maximum) 30 A continuous, 48 A pulse (96 ms max) Initial Battery run time 30 minutes (typical) (nominal patient) Maximum Battery charge Less than 4¼...
-
Page 78: Battery Charger Physical And Environmental
Battery Charger Physical And Environmental Table B-5 Battery Charger Specifications (Page 1 of 2) Category Specifications Manufacturer ZOLL Circulation, Inc. Model Number 8700-0753-01 Size (L×W×H) 16.01 in. by 9.50 in. by 6.54 in. (40.6 cm by 24.1 cm by 16.6 cm) Weight 7.1 lbs. - Page 79 User Guide Table B-5 Battery Charger Specifications (Page 2 of 2) Category Specifications Dips, interruptions, and Meets IEC 61000-4-11. variations Harmonics current emissions Meets IEC 61000-3-2, Class A. Radiated emissions Meets CISPR 11/EN55011, Group 1, Class A FCC part 15, Class A. Safety Meets IEC/EN60601-1.
-
Page 80: Fcc Statement
User Guide FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) The device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Guidance and Manufacturer’s Declaration–Electromagnetic Emissions Table B-6... -
Page 81: Table B-7 Guidance And Manufacturer's Declaration - Electromagnetic Immunity For Platform
User Guide Electromagnetic Immunity Declaration (EID) Table B-7 Guidance and Manufacturer’s declaration – Electromagnetic immunity for Platform The Platform is intended for use in the electromagnetic environment specified below. The customer or user of the Platform should ensure that it is used in such an environment. Immunity test IEC 60601 Test Level Compliance Level... -
Page 82: Table B-8 Guidance And Manufacturer's Declaration - Electromagnetic Immunity
User Guide Table B-8 Guidance and manufacturer’s declaration – electromagnetic immunity The Platform is intended for use in the electromagnetic environment specified below. The customer or the user of the Platform should assure that it is used in such an environment. Immunity test IEC 60601 Test Level Compliance Level Electromagnetic environment... -
Page 83: Table B-9 Recommended Separation Distances Between Portable And Mobile Rf Communications Equip
User Guide Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the Platform is used exceeds the applicable RF compliance level above, the Platform should be observed to verify normal operation. - Page 84 User Guide The use of Accessories, transducers, and cables other than those specified by the manufacturer, may result in increased Emissions or decreased Immunity of the AutoPulse System. The AutoPulse System should be observed to verify normal operation in the configuration in which it will be used.
-
Page 85: Limited Warranty For Autopulse Resuscitation System
(b) been damaged by causes external to the Warranted Product, including but not limited to failure of or faulty electrical power; (c) not been used in accordance with ZOLL Circulation’s instructions; (d) been affixed to any nonstandard accessory attachment; (e) had the serial number removed or made illegible;... - Page 86 WITHOUT LIMITATION LOST PROFITS) DIRECTLY OR INDIRECTLY ARISING FROM THE SALE, INABILITY TO SELL, USE OR LOSS OF USE OF ANY PRODUCT (HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY), EVEN IF ZOLL CIRCULATION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH LOSS. THE FOREGOING LIMITATIONS SHALL NOT APPLY...
-
Page 87: Index
User Guide Index Chest bands See Lifeband Chest Compression Assembly(CCA) active device use See Lifeband ending 3-14 chest compressions Administrative Menu 2-11 starting 3-7 Alert LED 1-8 chest displacement 1-1, B-1 AutoPulse cleaning AutoPulse Platform 4-2 battery 1-3 Code Review software 3-19 cleaning 4-2 compression components 1-2... - Page 88 User Guide installation Platform operating parameters B-1 LifeBand 2-1 Platform physical specifications B-1 interrupting compression cycles 3-14 positioning guides 3-5 Power LED 1-8 Last patient information 2-10, 3-18 LCD B-1 red LED 1-8 LifeBand band clip 2-1 securing patient for transport 3-15 cover plate 2-1 shoulder restraint 3-16 cutting 2-4, 2-7...
