ENFORCER SD-9 63 Series Manual

® No Touch Request-To-Exit Sensor
ENFORCER

Example Installation:

Typical installation with an electric lock:

Care and Cleaning for the SD-9x63 Series Sensor:

The sensor requires special care to ensure reliability and a long operating life.
1. Use a soft, clean cloth for cleaning. Use the mildest type of cleaner available.
2. When cleaning, spray the cleaning solution onto the cleaning cloth instead of the unit.
3. Be sure to wipe off any excess liquid from the sensor. Wet spots or areas may affect the
sensor's performance.
WARNING: Incorrect mounting which leads to exposure to rain or moisture inside the enclosure
could cause a dangerous electric shock, damage the device, and void the warranty.
WARRANTY This SECO-LARM product is warranted against defects in material and workmanship while used in
normal service for a period of one (1) year from the date of sale to the original consumer customer.
SECO-LARM's obligation is limited to the repair or replacement of any defective part if the unit is returned,
transportation prepaid, to SECO-LARM.
This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse,
neglect, repair, or alteration, improper or abnormal usage, or faulty installation, or if for any other reason
SECO-LARM determines that such equipment is not operating properly as a result of causes other than defects in
material and workmanship.
The sole obligation of SECO-LARM, and the purchaser's exclusive remedy, shall be limited to replacement or
repair only, at SECO-LARM's option. In no event shall SECO-LARM be liable for any special, collateral, incidental,
or consequential personal or property damages of any kind to the purchaser or anyone else.
NOTICE: The information and specifications printed in this manual are current at the time of publication. However,
the SECO-LARM policy is one of continual development and improvement. For this reason, SECO-LARM
reserves the right to change specifications without notice.
SECO-LARM is not responsible for misprints or typographical errors.
Copyright © 2014 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied,
in whole or in part, without the written permission of SECO-LARM.
®
U.S.A., Inc.
SECO-LARM
16842 Millikan Avenue, Irvine, CA 92606
Tél: 800-662-0800 / 949-261-2999 Fax: 949-261-7326
4
Override button is prewired in the factory
No further wiring necessary
Website: www.seco-larm.com
MiSD-9x63-KSxQ_1406.docx
Email: sales@seco-larm.com
Order Part # 763-171-5%
SECO-LARM U.S.A., Inc
Request-To-Exit Sensor
Language
English
Spanish
French
English
w/ mechanical override button
The ENFORCER Outdoor No Touch Request-To-Exit Sensor is a full-featured exit plate which
uses IR technology to allow egress from a protected area or activate a device with the simple
wave of a hand. Since it is No Touch, this sensor is ideal for use in hospitals, clinics, labs,
cleanrooms (to reduce the risk of contamination), schools, factories, or offices.
PITSW1
Outdoor No Touch
Manual
Slimline Plate Single Gang Plate
SD-9163-KSQ SD-9263-KSQ
SD-9163-KS1Q SD-9263-KS1Q
SD-9163-KS2Q SD-9263-KS2Q
SD-9163-KSVQ SD-9263-KSVQ
w w
Featuring:
• Built-in Timer (0.8~30 seconds or toggle)
• Programmable LED (Red to Green or Green to Red)
European Plate
SD-9363-KSQ
n/a
n/a
n/a
w
