2010 Critical Care Bed
OPERATIONS MANUAL
For Parts or Technical Assistance
1–800–327–0770

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Stryker Medical 2010

Summary of Contents for Stryker Medical 2010

  • Page 1 2010 Critical Care Bed OPERATIONS MANUAL For Parts or Technical Assistance 1–800–327–0770...

  • Page 2: Table Of Contents

    Table of Contents Introduction ................Specifications .

  • Page 3: Introduction

    Introduction INTRODUCTION This manual is designed to assist you with the operation and maintenance of the 2010 Stryker Manual Critical Care Bed. Read it thoroughly before using the equipment or beginning any maintenance on it. SPECIFICATIONS Maximum Weight Capacity 500 pounds Overall Bed Length/Width 90”/38”...

  • Page 4: Set Up Procedures

    Set–Up Procedures SET UP PROCEDURES It is important that the 2010 Stryker Manual Critical Care Bed is working properly before it is put into service. The following list will help test the bed. Depress the curved pedal to set the four wheel brakes and assure all four wheels lock. Lift the pedal to the neutral position to release the brakes.

  • Page 5: Operation Guide

    Operation Guide Fowler Crank Turn crank clockwise to raise Fowler. Turn crank counterclockwise to lower Fowler. Gatch Crank Turn crank clockwise to raise Knee Gatch. Turn crank counterclockwise to lower Knee Gatch. Lift Pedal Pump pedal to raise litter. Trendelenberg Pedal Depress pedal to lower head end.

  • Page 6: Operating Directional Steering Caster

    Operation Guide OPERATING DIRECTIONAL STEERING CASTER When transporting a patient, the steer caster helps to maintain the bed’s path along a straight line and aids pivoting at corners. Brake/Steer Pedal Depress pedal fully to set four wheel brakes. Lift pedal fully to engage steer caster. For proper ”tracking”...

  • Page 7: Trendelenberg/Fowler Display Option

    Operation Guide TRENDELENBERG/FOWLER DISPLAY OPTION The Trend/Fowler display option indicator lights are powered by 3 ”D” size (1.5 V each) alkaline batteries. The batteries are located under the foot end frame end. To replace the batteries, remove the two screws on the frame end bumper and lift off the plastic frame end.

  • Page 8: Operating Optional Permanently Attached I.v. Pole

    Operation Guide OPERATING OPTIONAL PERMANENTLY ATTACHED I.V. POLE NOTE An optional permanently attached I.V. Pole may have been installed at either the head, foot or both ends of the stretcher. The choice was made at the time the stretcher was pur– chased.

  • Page 9: Using The Optional X-Ray Cassette Holder

    Operation Guide USING THE OPTIONAL X–RAY CASSETTE HOLDER 1. To access the Fowler x–ray cassette holder, raise the Fowler section. 2. Grasp handles (A) and squeeze, allowing locating pins (B) to disengage from mounting brackets (C). 3. Lower tray and install x–ray cassette. 4.

  • Page 10: Weigh System Control Panel Guide

    Weigh System Control Panel Guide The weigh system power switch is located under the foot end frame end. Pull the switch toward you to turn on power to the weigh system. When weigh system is not in use, turn off the switch to conserve battery life. SYMBOL ACTION MONITOR...
  • Page 11 Weigh System Control Panel Guide SYMBOL ACTION MONITOR To lockout selected weigh system functions: Press and release ”LOCK/UNLOCK”. ”LOCK/UNLOCK KEY?” LOCK/ UNLOCK Press and release selected weigh ”KEY LOCKED” system button. Multiple functions can be locked out by repeating above steps. If a button is pressed for a function that has been locked out, the display will read: ”KEY LOCKED OUT”.

  • Page 12: Weigh System Usage

    Weigh System Usage See Note Below BEFORE PUTTING A NEW PATIENT ON THE BED Prepare bed for patient stay (linens, blankets, pillows, etc.). The weigh system on/off/reset switch is located under the foot end frame end. Push the switch away from you to turn on power to the weigh system.
  • Page 13 Weigh System Usage AFTER PUTTING A NEW PATIENT ON THE BED (CONTINUED) If it is necessary to add or remove special equipment (monitors, pumps, etc.) during the patient’s stay, press and release ”SCALE SYSTEM ON” to activate the weigh system. After the scale monitor activates and then turns off, press and release ”PATIENT WEIGHT”.

  • Page 14: Warranty

    Warranty Limited Warranty: Stryker Medical Division, a division of Stryker Corporation, warrants to the original purchaser that its products should be free from defects in material and workmanship for a period of one (1) year after date of delivery. Stryker’s obligation under this warranty is expressly limited to supplying replacement parts and labor for, or replacing, at its option, any product which is, in the sole discretion of Stryker, found to be defective.

  • Page 15: Return Authorization

    Claims for any short shipment must be made within thirty (30) days of invoice. International Warranty Clause: This warranty reflects U.S. domestic policy. Warranty outside the U.S. may vary by country. Please contact your local Stryker Medical representative for additional information.
  • Page 16 6300 Sprinkle Road, Kalamazoo, MI 49001–9799 (800) 327–0770 DH 6/92 2010–1–110 REV__...
