2025/2026 Critical Care Bed
MAINTENANCE MANUAL
For beds with serial numbers 9709035185 and above.
For Parts or Technical Assistance
1–800–327–0770

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2025 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Stryker Medical 2025

Summary of Contents for Stryker Medical 2025

  • Page 1 IMPORTANT File in your maintenance records 2025/2026 Critical Care Bed MAINTENANCE MANUAL For beds with serial numbers 9709035185 and above. For Parts or Technical Assistance 1–800–327–0770...

  • Page 2: Table Of Contents

    Table of Contents Introduction Specifications ................Warning/Caution/Note Definition .
  • Page 3 Table of Contents Replacement Parts and Kits ..............Assembly Drawings and Parts Lists Base Assembly .

  • Page 4: Introduction

    Introduction INTRODUCTION This manual is designed to assist you with the maintenance of the Model 2025/2026 Stryker Critical Care Bed. Read it thoroughly before beginning any maintenance on the equipment. SPECIFICATIONS Maximum Weight Capacity 500 pounds (227 kilograms) Weigh System Capacity (optional equipment) patients weighing up to 400 pounds or patients weighing up to 181.5 kilograms...

  • Page 5: Preventative Maintenance

    Preventative Maintenance Hand wash all surfaces of the bed with warm water and mild detergent. Dry thoroughly. DO NOT STEAM CLEAN, PRESSURE WASH, HOSE OFF OR ULTRASONICALLY CLEAN. Using these methods of cleaning is not recommended and may void this product’s warranty. Clean Velcro AFTER EACH USE.
  • Page 6 Preventative Maintenance MAINTENANCE CHECKLIST All fasteners secure Engage brake pedal and push on the bed to ensure all casters lock securely Optional locking steer caster or Fifth Wheel engages and disengages properly Siderails move, latch and stow properly All functions on siderails working properly (including LED’s) CPR release working properly Foot prop intact and working properly I.V.
  • Page 7 Preventative Maintenance NOTE To prevent a low battery condition when the bed is not plugged in, position the cord out switch at the head end of the bed to the off position. The switch is identified by the label shown below. If the switch is not posi- tioned as shown below and the bed power cord and pendant cord are unplugged, the life of the back–up bat- tery will be significantly reduced.

  • Page 8: Static Discharge Precautions

    2 and 3 of the following procedure. Do not place unprotected circuit boards on the floor. All circuit boards to be returned to Stryker Medical should be shipped in the static shielding bags the new boards were shipped in.

  • Page 9: Checking Hydraulic Fluid Level

    Maintenance Procedures – Base CHECKING HYDRAULIC FLUID LEVEL Required Tools: 3/16” Allen Wrench 3/4” Open End Wrench (2) Sawhorses (or equivalent) Large Phillips Screwdriver Bungee Cords (or equivalent) Hydraulic Fluid Procedure: 1. Raise the litter to the full up position. 2.

  • Page 10: Jack Descent Rate Adjustment

    Maintenance Procedures – Base JACK DESCENT RATE ADJUSTMENT Required Tools: Standard Screwdriver #2 Phillips Screwdriver Bungee Cords (or equivalent) Adjustment Procedure: 1. Pump the litter up to full height. 2. Using a #2 Phillips screwdriver, remove the three Phillips screws holding the base hood to the base frame. 3.

  • Page 11: Caster Cover Installation And Removal

    Maintenance Procedures – Base CASTER COVER INSTALLATION AND REMOVAL Looking through the larger of the two side cut–outs, align the cover with the axle nut or bolt head, as shown. Double Prongs Push down on the opposite side of the cover until the single prong engages with the caster horn.

  • Page 12: Steer Caster Linkage Adjustment

    Maintenance Procedures – Base STEER CASTER LINKAGE ADJUSTMENT Required Tools: #2 Phillips Head Screwdriver 3/8” Open End Wrench 5/32” Allen Wrench 1/2” Open End Wrench Bungee Cords (or Equivalent) Adjustment Procedure: 1. Using a #2 Phillips screwdriver, remove the three Phillips screws holding the base hood to the base frame. 2.

  • Page 13: Brake Adjustment

    Maintenance Procedures – Base BRAKE ADJUSTMENT Required Tools: 3/32” Hex Allen Wrench Pry Bar Thread ”Locktite” Flat on thread of stud must always be aligned with the set screw. Turn must always be full circle only. POWER TREND AND PUMP PEDAL SWITCH REPLACEMENT Required Tools: #2 Phillips Screwdriver Bungee Cords (or equivalent)

  • Page 14: Power Cord Replacement

    Maintenance Procedures – Base POWER CORD REPLACEMENT Required Tools: #2 Phillips Screwdriver 7/64” Allen Wrench Bungee Cords (or Equivalent) 7/16” Socket Wrench Heyco Pliers Replacement Procedure: 1. Raise the litter up to full height. 2. Unplug the power cord from the wall socket. 3.

  • Page 15: Lift Potentiometer Replacement

    Maintenance Procedures – Base LIFT POTENTIOMETER REPLACEMENT Required Tools: #2 Phillips Screwdriver Small Standard Screwdriver Bungee Cords (or Equivalent) 1/2” Open End Wrench Wire Cutters Replacement Procedure: 1. Raise the litter up to full height and unplug the bed power cord from the wall socket. 2.

  • Page 16: Coil And Wire Replacement

    Maintenance Procedures – Base COIL AND WIRE REPLACEMENT (HEAD END) Required Tools: #2 Phillips Screwdriver Small Standard Screwdriver Bungee Cords (or Equivalent) 3/8” Nut Driver 7/64” Allen Wrench Replacement Procedure: 1. Raise the litter up to full height and unplug the bed power cord from the wall socket. 2.

  • Page 17: Manual Release Valve Replacement

    Maintenance Procedures – Base MANUAL RELEASE VALVE REPLACEMENT Required Tools: #2 Phillips Screwdriver Small Standard Screwdriver Bungee Cords (or Equivalent) Sawhorses (or Equivalent) 3/32” Allen Wrench 7/8” Open End Wrench Replacement Procedure: 1. Raise the litter up to full height and unplug the bed power cord from the wall socket. 2.

  • Page 18: Hydraulic Pump And Motor Replacement

    Maintenance Procedures – Base HYDRAULIC PUMP AND MOTOR REPLACEMENT Required Tools: #2 Phillips Screwdriver Small Standard Screwdriver 11/16” Open End Wrench Bungee Cords (or Equivalent) Saw Horses (or Equivalent) 3/8” Socket Wrench Wire Cutters 9/16” Open End Wrench Replacement Procedure: 1.

  • Page 19: Jack Replacement

    Maintenance Procedures – Base JACK REPLACEMENT Required Tools: #2 Phillips Screwdriver Small Standard Screwdriver Bungee Cords (or Equivalent) Sawhorses (or Equivalent) 3/16” Allen Wrench 3/8” Socket Wrench 9/16’ Open End Wrench 11/16” Open End Wrench 1/2” Open End Wrench 1/2” Socket Wrench Floor Jack 1/4”...

  • Page 20: Cpu Board Replacement

    Maintenance Procedures – Litter CPU BOARD REPLACEMENT Required Tools: #2 Phillips Screwdriver Needle Nosed Pliers Replacement Procedure: 1. Properly ground yourself (see page 7 for static discharge precautions). Verify the bed power cord has been unplugged from the wall socket. 2.

  • Page 21: Displaying Individual Load Cell Outputs

    Maintenance Procedures – Litter DISPLAYING INDIVIDUAL LOAD CELL OUTPUTS A defective load cell can be detected by entering diagnostics and displaying individual load cell outputs. 1. To enter the diagnostic mode, unplug the bed power cord from the wall socket. Press and hold the LBS/KG button.

  • Page 22: Scale Calibration Procedure

    Maintenance Procedures – Litter SCALE CALIBRATION PROCEDURE 1. Unplug the bed power cord from the wall socket. 2. Press and hold the “LBS/KG” button on the foot board. While holding the button, plug the bed power cord into the wall socket. 3.

  • Page 23: Power Board Replacement

    Maintenance Procedures – Litter POWER BOARD REPLACEMENT Required Tools: #2 Phillips Screwdriver 11/32” Nut Driver Replacement Procedure: 1. Properly ground yourself (see page 7 for static discharge precautions). Verify the bed power cord has been unplugged from the wall socket. 2.

  • Page 24: Siderail Switch Board Replacement

    Maintenance Procedures – Litter SIDERAIL SWITCH BOARD REPLACEMENT Required Tools: #2 Phillips Screwdriver Razor Knife Replacement Procedure: 1. Unplug the bed power cord from the wall socket. 2. Using a razor knife, carefully remove the outside siderail switch label. 3. Using a #2 Phillips screwdriver, remove the four screws holding the siderail switch assembly together. 4.
  • Page 25 Maintenance Procedures – Litter GATCH (KNEE) MOTOR REPLACEMENT Required Tools: #2 Phillips Screwdriver 1/2” Socket Wrench Hammer 1/8” Roll Pin Punch 7/16” Socket Wrench w/Short Extension Replacement Procedure: 1. Unplug the bed power cord from the wall socket. 2. If possible, manually crank the knee section up until it stops. (Even if the knee section will not crank up, proceed with step 3.) 3.

  • Page 26: Fowler Potentiometer Replacement

    Maintenance Procedures – Litter FOWLER POTENTIOMETER REPLACEMENT Required Tools: #2 Phillips Screwdriver Wire Cutters 1/2” Open End Wrench 7/64” Allen Wrench Replacement Procedure: 1. Manually crank the knee section up until it stops. 2. Using a #2 Phillips screwdriver, remove the four screws holding the litter access cover to the litter and remove the cover.

  • Page 27: Foot Board Hinge Removal

    Maintenance Procedures – Foot Board FOOT BOARD HINGE REMOVAL Required Tools: #2 Phillips Screwdriver Procedure: 1. Using a #2 Phillips screwdriver, remove the screws (A & B) holding the door and hinge assembly to the foot board. 2. If replacing the hinge only, use a Phillips screwdriver to remove the screws holding the hinge to the door. 3.

  • Page 28: Foot Board Interface Plug Replacement

    Maintenance Procedures – Foot Board FOOT BOARD INTERFACE PLUG REPLACEMENT Required Tools: #2 Phillips Screwdriver BOTTOM VIEW OF FOOT BOARD Procedure: 1. Unplug the bed power cord from the wall socket. 2. Remove the foot board from the bed to access the bottom of the board. 3.

  • Page 29: Troubleshooting Guide

    Electrical Troubleshooting TROUBLESHOOTING GUIDE DEFINITIONS: DMM = Digital Multi–Meter PCB = Printed Circuit Board CPU = Central Processing Unit NOTE See pages 33–38 for an outline of bed PCB’s and voltage test points. See page 19 for potentiometer calibra- tion. PROBLEM/FAILURE RECOMMENDED ACTION No power to bed...
  • Page 30 Electrical Troubleshooting TROUBLESHOOTING GUIDE (CONTINUED) PROBLEM/FAILURE RECOMMENDED ACTION No Fowler up motion. A. Check for 120 VAC on HDR11, Pin 3 and Pin 2 of the power board. B. Check for 5 VDC on HDR2 Pin 2 and HDR4 Pin 1 of the CPU board. No Fowler down motion.
  • Page 31 Electrical Troubleshooting SCALE SYSTEM TROUBLESHOOTING GUIDE (CONTINUED) PROBLEM/FAILURE RECOMMENDED ACTION Scale weighing too heavy – one position. A. Check for any mechanical interference between the weighing surface and the stationary sections of the bed. B. If in Trend position, calibrate bed (see page 21) and check again.

  • Page 32: Bed Circuit Boards

    Bed Circuit Boards CPU KIT (ALL OPTIONS) – P/N 2025–700–18 HDR 32 HDR 12 HDR 13 HDR 3 HDR 4 HDR24 HDR 23 CONNECTOR CABLE VOLTAGE POSITIVE NEGATIVE DESCRIPTION LOCATION LOCATION LEAD LEAD HDR 12 +5 VDC Pin 12 HDR 33...
  • Page 33 Bed Circuit Boards CPU KIT (ALL OPTIONS) – P/N 2025–700–18 CONNECTOR CABLE VOLTAGE POSITIVE NEGATIVE DESCRIPTION LOCATION LOCATION LEAD LEAD HDR 22 +5 VDC Pin 8 Pin 6 Foot Board HDR 22 16–18 VDC Pin 7 Pin 6 Foot Board HDR 24 16–18 VDC w/o...
  • Page 34 Bed Circuit Boards POWER BOARD – P/N 2025–300–930 HDR 1 HDR 11 HDR 9 HDR 3 HDR 2 HDR 6 HDR 4 HDR 8 HDR 10 MOTION INTERRUPT F1 – Fuse 6 Amp, 250 VAC, SLO–BLO – Stryker Part Number 59–149 F2 –...
  • Page 35 Bed Circuit Boards POWER BOARD – P/N 2025–300–930 (Continued) CONNECTOR CABLE VOLTAGE POSITIVE NEGATIVE DESCRIPTION LOCATION LOCATION LEAD LEAD HDR 4 +5 VDC Pin 4 Pin 1 + 5 VDC For CPU HDR 4 +16 – +18 VDC Pin 5...
  • Page 36 Bed Circuit Boards INTERNATIONAL POWER BOARD – P/N 3221–300–930 F1 & F3 – Fuse 4 Amp, 250 VAC, SLO–BLO – Stryker Part Number F2 – Fuse .125 Amp, 250 VAC, SLO–BLO – Stryker Part Number CONNECTOR CABLE VOLTAGE POSITIVE NEGATIVE DESCRIPTION LOCATION LOCATION...
  • Page 37 Bed Circuit Boards INTERNATIONAL POWER BOARD – P/N 3221–300–930 CONNECTOR CABLE VOLTAGE POSITIVE NEGATIVE DESCRIPTION LOCATION LOCATION LEAD LEAD HDR 4 +5 VDC Pin 4 Pin 1 + 5 VDC For CPU HDR 4 +16 – +18 VDC Pin 5 Pin 1 Bulk DC for Relays/ Siderail Lights...
  • Page 38 Bed Circuit Boards OPTIONAL DMS POWER SUPPLY PCB – P/N 3001–302–910 PS1 – Resettable Poly Switch F2 – Fuse – 3/10 Amp, 3 AG, 250 VAC, SLO–BLO – Stryker Part Number 59–730 CONNECTOR CABLE VOLTAGE POSITIVE LEAD NEGATIVE DESCRIPTION LOCATION LOCATION LEAD HDR 1...
  • Page 39 Bed Circuit Boards OPTIONAL HEADWALL INTERFACE PCB – P/N 3001–303–900 OPTIONAL HEADWALL INTERFACE PCB W/STRYKER PORT – P/N 3001–314–900 CONNECTOR CABLE VOLTAGE POSITIVE NEGATIVE DESCRIPTION LOCATION LOCATION LEAD LEAD HDR 7 0 VDC w/o Pin 5 HDR 8–6 Beeper Beeper On +5 VDC w/Beeper Energized HDR 8...

  • Page 40: Head Wall Output Configuration

    Head Wall Output Configuration 37–PIN CONNECTOR STRYKER PENDANT PORT Pin 1 Option 2 Common Pin 2 Read Light Pin 3 Room Light Pin 4 Speaker High Pin 5 Pot Wiper Pin 6 Radio Common Pin 7 Nurse Call Interlock Pin 8 Audio Transfer –...

  • Page 41: Replacement Parts And Kits

    ............. 2025–700–18 DMS Power Supply Board, Domestic .

  • Page 42: Base Assembly

    Base Assembly...
  • Page 43 Base Assembly HEAD END HEAD END...
  • Page 44 Base Assembly...
  • Page 45 Base Assembly...
  • Page 46 Pump Pedal Wldmt. 52–245 Bearing 2025–201–96 Coil Retainer Bracket 52–747 Nyliner Bearing 2035–001–801 Lift Coil Cord (DC) 52–783 U–Clip 2025–201–802 Lift Power Coil Cord (AC) 1 59–133 Push–Mount Wire Clip 2025–301–50 Base Frame Weldment 59–169 Strain Relief 2025–475–89 Pump/Motor Top Cover 715–1–11 Brake Cushion 3000–300–58...
  • Page 47 Base Assembly 2025–10–16 Power Trend Pedal Option Ass’y Item Part No. Part Name Qty. 11–53 Washer 42–13 Stop Collar 52–747 Flange Bearing 38–355 Extension Spring 715–1–126 Pedal Pad 2025–1–804 Power Trend Cable 2025–1–59 Release Pedal Weldment 3000–300–58 Cherry Switch 2025–271 Low Height Hydraulic Assembly 2026–271 Int.

  • Page 48: 715-201-150 Brake Adjuster Assembly

    715–201–150 Brake Adjuster Assembly Item Part No. Part Name Qty. 715–1–180 Cam Bearing 715–201–62 Threaded Stud Assembly 14–4 Nylon Washer 28–8 External Retaining Ring 715–1–213 Brake Cam Assembly Item Part No. Part Name Qty. 715–1–221 Brake Cam 16–59 Fiberlock Nut 8–21 Soc.

  • Page 49: Caster Assembly

    2025–10–25 Caster Assembly Item Part No. Part Name Qty. 3–99 Hex Hd. Cap Screw 11–310 Washer 16–60 Hex Nut 715–2–16 Horn Assembly 715–3–96 Hex Hd. Cap Screw 2025–1–47 Wheel Cover, Right 2025–1–48 Wheel Cover, Left (page 49) Molded Wheel Assembly...

  • Page 50: 715-2-25 Wheel Assembly

    715–2–25 Wheel Assembly Item Part No. Part Name Qty. 52–503 Bearing Spacer 81–226 Bearing 715–1–255 Wheel Bearing 715–2–124 Wheel...
  • Page 51 Standard & Low Height Jack Assembly Assembly part numbers: 2025–700–9 (Low Height Jack, Foot End) 2025–700–11 (Standard Height Jack, Foot End) 2025–700–13 (Standard Height Jack, Head End) 2025–700–15 (Low Height Jack, Head End)
  • Page 52 Cap Assembly 1550–70–6 Cap Assembly 390–1–243 Gasket 390–1–243 Gasket 1550–70–4 Actuator Cylinder 2025–70–98 Actuator Cylinder, Low Ht. 1 2025–270–95 Actuator 2025–270–99 Actuator, Low Height 45–14 O–Ring 45–14 O–Ring 926–20–161 Parker Packing 926–20–161 Parker Packing 2025–1–331 Piston End 2025–1–331 Piston End 926–20–162...
  • Page 53 Jack Base Assembly Assembly part number 2025–76–14 (reference only) Item Part No. Part Name Qty. Item Part No. Part Name Qty. 48–147 Hex Hd. O–Ring Plug 2025–75–85 Filter Screen 48–150 Check Valve 2025–75–87 Pin Housing 390–2–134 Conical Comp. Spring 2025–76–96 Solenoid Valve Body 715–1–307...
  • Page 54 715–100–425 Jack Pump Piston Assembly Assembly part number 715–201–325 (reference only) Item Part No. Part Name Qty. 715–1–328 Piston Wear Ring 715–1–400 O–Ring Back Up 715–200–316 Pump Cylinder 715–201–318 Pump Piston 715–201–327 Cylinder Wear Ring 14–50 Bearing Retainer 45–110 O–Ring 715–1–329 Pump Seal (not shown)

  • Page 55: Pump/Motor Assembly

    Standard & Low Height Jack Motor Assembly Assembly part numbers: 2025–371–10 Low Height Jack/Motor Assembly 2025–376–10 Standard Height Jack Motor Assembly 2026–371–10 International Low Height Jack/Motor Assembly 2026–376–10 International Standard Height Jack/Motor Assembly FOOT END FOOT END...

  • Page 56: Jack Assembly

    FOOT END Item Part No. Part Name Qty. Item Part No. Part Name Qty. 3–3 Hex Hd. Cap Screw 2025–75–93 Short Pressure Line 3–121 Hex Wash. Hd. Screw 2025–75–94 Long Pressure Line 16–28 Nylock Nut (page 51) Jack Assembly 30–40 E–A–R Grommet...

  • Page 57: Rack And Pinion Assembly

    2025–10–17 Rack & Pinion Assembly, Standard Height 2025–10–18 Rack & Pinion Assembly, Low Height...
  • Page 58 2025–10–17 Rack & Pinion Assembly, Standard Height 2025–10–18 Rack & Pinion Assembly, Low Height 2025–10–18 2025–10–17 Low Height Rack & Pinion Assembly Standard Height Rack & Pinion Assembly Item Part No. Part Name Qty. Item Part No. Part Name Qty.

  • Page 59: Fifth Wheel Assembly

    2025–10–13 Fifth Wheel Option Assembly Item Part No. Part Name Qty. 3–20 Machine Screw 16–28 Lock Nut 16–49 Nylock Hex Nut 23–25 Hex Wash. Hd. Tap. Screw 81–219 Ball Bearing (page 59) Fifth Wheel Assembly 715–1–136 Fifth Wheel Spring 715–1–149 715–1–157...
  • Page 60 2025–10–27 Fifth Wheel Assembly Item Part No. Part Name Qty. 3–31 Hex Head Cap Screw 3–82 Hex Head Cap Screw 16–11 Flexlock Nut 16–12 Flexlock Nut 390–1–54 Wheel 715–1–15 Spring 715–1–17 Fifth Wheel Bushing 715–1–339 Fifth Wheel Pivot Assembly 2025–10–98...

  • Page 61: Steer Caster Assembly

    2025–10–12 Steer Caster Option Assembly Item Part No. Part Name Qty. 8–30 Shoulder Bolt 14–2 Nylon Washer 15–32 Hex Jam Nut 38–211 Compression Spring 1000–59–10 Latch Assembly (page 61) Steer Caster Assembly 2020–46–215 Linkage Bar Assembly 2020–46–218 Right Linkage Bar...
  • Page 62 2025–10–24 Steer Caster Assembly Assembly part number 2025–10–24 Item Part No. Part Name Qty. 3–99 Hex Hd. Cap Screw 11–310 Washer 16–60 Hex Nut 700–10–50 Steering Horn Assembly 715–3–96 Hex Hd. Cap Screw 2025–1–47 Wheel Cover, Right 2025–1–48 Wheel Cover, Left...

  • Page 63: International Inlet Filter Assembly

    2026–201–20 International Inlet Filter Assembly Item Part No. Part Name Qty. 1–87 Flat Hd. Slotted Screw 3–221 Hex Washer Hd. Screw 16–23 Nylock Nut 16–33 Kep Nut 52–783 U–Clip 59–107 Strain Relief 2011–1–215 Grounding Lug 2026–201–50 Inlet Filter Housing Weldment 2026–201–99 Inlet Filter Box Cover 2026–201–803...

  • Page 64: Volt Outlet Option Assembly

    2025–10–14 110V Outlet Option Assembly Item Part No. Part Name Qty. 1–87 Flat Hd. Slotted Screw 3–121 Hex Hd. Cap Screw 13–10 Washer 59–107 Strain Relief Bushing 52–783 “U” Clip 2020–2–664 Fuse Holder 2020–2–666 Fuse 2020–11–222 Outlet Cover 2025–10–20 110 Box Cover 2026–10–99...

  • Page 65: No 110 Volt Outlet Option Assembly

    2025–10–15 No 110V Outlet Option Assembly Item Part No. Part Name Qty. 1–87 Flat Hd. Slotted Screw 2025–210–21 Box Cover Plate (w/o 110) 2025–10–22 Box Cover (w/o 110) 52–783 “U” Clip 4–126 Soc. Hd. Cap Screw...

  • Page 66: Litter Assembly

    Litter Assembly...
  • Page 67 Litter Assembly...
  • Page 68 Litter Assembly...
  • Page 69 Litter Assembly...
  • Page 70 Litter Assembly...
  • Page 71 Litter Assembly...
  • Page 72 Nylock Nut 2025–231–97 Seat Section Skin 16–28 Nylock Nut 2025–231–99 Bed Ext. Release Lever 23–25 Hex Wash. Hd. Tap. Scr. 2025–231–112 Bed Ext. Pull Lock Pin 23–80 Truss Hd. Screw 2025–231–805 Ground Strap 25–79 Rivet 2025–232–75 Actuator Box Cover 25–142 Pop Rivet 2025–331–52...
  • Page 73 Cable Clamp 2025–30–226 Iso. Foley Bag Hook, Rt. 2025–30–227 Iso. Foley Bag Hook, Lt. 2025–31–804 Ground Jumper 2025–230–801 Load Cell Cable, Hd. 2025–230–802 Load Cell Cable, Ft. 3001–307–55 Load Cell (p. 113) 2025–30–126 Ft. Bd. – Scale w/o B.E. 2025–30–150 2025–30–175...

  • Page 74: Actuator Box Assembly

    Actuator Box Assembly...
  • Page 75 Actuator Box Assembly...
  • Page 76 Actuator Box Assembly...
  • Page 77 Actuator Box Assembly...
  • Page 78 Fowler Motor Kit, Domestic AH 2025–32–68 Flange Bearing 2026–700–1 Fowler Motor Kit, Int’nl 28–120 Ext. Retaining Ring 38–478 Wave Washer 2025–32–15 Domestic Act. Box Electronics 2026–32–15 Internat’l Act. Box Electronics Item Part No. Part Name Qty. Item Part No. Part Name Qty. 2025–32–67 Power Board Fuse Label 2026–32–67...
  • Page 79 Actuator Box Assembly...
  • Page 80 Actuator Box Assembly 2025–41 Hybrid DMS Option 2025–42 Integrated DMS Option Item Part No. Part Name Qty. Item Part No. Part Name Qty. 59–725 M/F Screw 59–725 M/F Screw 4–299 But. Hd. Cap Screw 4–299 But. Hd. Cap Screw 12–30 Star Washer 12–30...

  • Page 81: Bed Extender Assembly

    Bed Extender Assembly Assembly part number 2025–231–15 (reference only) Gatch Manual Override Fowler Manual Override...
  • Page 82 Roll Pin 2025–31–107 Fowler Motor Coupler 28–88 Int. Retaining Ring 2025–31–109 Gatch Shaft Extension 38–209 Compression Spring 2025–31–110 Crank Handle 3001–200–228 Mounting Standoff 2025–331–801 Foot Board CPU Cable 378–24–29 Shoulder Bolt 58–76 Drive Fastener 958–34–717 Magnet 59–743 Wire Harness Clip...

  • Page 83: Head Wall Litter Options

    Head Wall Communication Option Assembly Assembly part number 2025–30–200 Item Part No. Part Name Qty. 3–124 Hex Washer Hd. Screw 7–49 Truss Hd. Screw 13–10 Ext. Tooth Lock Washer 13–18 Ext. Tooth Lock Washer 16–7 Fiberlock Nut 59–710 Static Cap 59–727...
  • Page 84 Head Wall w/Nurse Call & Battery Option Assembly Assembly part number 2025–30–201 Item Part No. Part Name Qty. 3–124 Hex Washer Hd. Screw 7–49 Truss Hd. Screw 13–10 Ext. Tooth Lock Washer 13–18 Ext. Tooth Lock Washer 16–7 Fiberlock Nut 59–710...
  • Page 85 Head Wall w/Nurse Call & 1 Stryker Port Option Ass’y Assembly part number 2025–30–202 Item Part No. Part Name Qty. 3–124 Hex Washer Hd. Screw 4–302 Hex Soc. But. Hd. Cap Screw 7–49 Truss Hd. Screw 13–10 Ext. Tooth Lock Washer 13–18...
  • Page 86 Head Wall w/Nurse Call & 2 Stryker Ports Option Ass’y Assembly part number 2025–30–203 Item Part No. Part Name Qty. 3–124 Hex Washer Hd. Screw 4–302 Hex Soc. But. Hd. Cap Screw 7–49 Truss Hd. Screw 13–10 Ext. Tooth Lock Washer 13–18...
  • Page 87 Head Wall Interface Assembly, Nurse Call Option Assembly part number 2025–30–204 Item Part No. Part Name Qty. 7–49 Truss Hd. Screw 13–10 Ext. Tooth Lock Washer 16–7 Fiberlock Nut 59–710 Static Cap 59–727 Jack Screw 2025–230–803 Nurse Call Cable 2025–30–806 Battery Cable 2025–32–71...
  • Page 88 Pendant Port Option Assembly, Motion Only Assembly part number 2025–30–205 Item Part No. Part Name Qty. 3–124 Hex Washer Hd. Screw 4–302 Hex Soc. But. Hd. Cap Screw 7–49 Truss Hd. Screw 13–10 Ext. Tooth Lock Washer 13–18 Ext. Tooth Lock Washer 16–7...

  • Page 89: Full-Length Siderail Assembly

    Full Length Siderail Assembly...
  • Page 90 Full Length Siderail Assembly...
  • Page 91 Self–Tapping Screw 25–139 Short Top Rail Rivet 25–149 Long Top Rail Rivet 25–150 Medium Top Rail Rivet 30–38 Cable Bushing 2025–20–801 Head End Cable Assembly 2025–20–803 Foot End Cable Assembly 2025–21–43 Angled Spindle 2025–21–46 Center Top Rail Connector 2025–321–50 Pivot Tube Weldment, Left 2025–22–62...

  • Page 92: Split Siderail Assembly

    Split Siderail Assembly...
  • Page 93 Split Siderail Assembly...
  • Page 94 Nylon Washer 14–20 Nylon Washer 23–248 Self–Tapping Screw 25–139 Short Top Rail Rivet 25–150 Medium Top Rail Rivet 30–38 Cable Bushing 2025–20–801 Head End Cable Assembly 2025–20–803 Foot End Cable Assembly 2025–21–43 Angled Spindle 2025–22–25 Straight Spindle 2025–22–26 Spindle Pivot 2025–22–27 Spindle End Cap 2025–22–28...

  • Page 95: Siderail Control Option Assembly

    Standard Siderail LEFT LEFT RIGHT RIGHT OUTER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT OUTER PCB SWITCH/CAP PLACEMENT HEAD 2025−200−130 (Blue Stone) 2025−000−110 (Blue Stone) 2025−000−118 2025−22−46 2025−200−230 (Forest Green) 2025−000−210 (Forest Green) LEFT LEFT RIGHT RIGHT...
  • Page 96 LEFT RIGHT SPEAKER MODULE RIGHT OUTER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT OUTER PCB SWITCH/CAP PLACEMENT HEAD 2025−200−131 (Blue Stone) 2025−000−111 (Blue Stone) 2025−000−117 2025−22−46 2025−200−231 (Forest Green) 2025−000−211 (Forest Green) LEFT LEFT SPEAKER MODULE...
  • Page 97 RIGHT SPEAKER MODULE RIGHT OUTER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT OUTER PCB SWITCH/CAP PLACEMENT HEAD 2025−200−131 (Blue Stone) 2025−000−115 (Blue Stone) 2025−000−126 (Blue Stone) 2025−22−46 2025−200−231 (Forest Green) 2025−000−215 (Forest Green) 2025−000−226 (Forest Green)
  • Page 98 Standard Siderail with Position Package #2* Option LEFT LEFT RIGHT RIGHT OUTER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT OUTER PCB SWITCH/CAP PLACEMENT HEAD 2025−200−136 (Blue Stone) 2025−000−110 (Blue Stone) 2025−22−46 2025−000−118 2025−200−236 (Forest Green) 2025−000−210 (Forest Green) LEFT LEFT RIGHT RIGHT...
  • Page 99 OUTER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT OUTER PCB SWITCH/CAP PLACEMENT HEAD 2025–22–33 (Ref.) 2025–22–69 (Ref.) 2025–22–68 (Ref.) 2025−200−132 (Blue Stone) 2025−000−111 (Blue Stone) 2025−000−117 2025−22−46 2025−200−232 (Forest Green) 2025−000−211 (Forest Green) LEFT LEFT SPEAKER MODULE...
  • Page 100 RIGHT SPEAKER MODULE RIGHT OUTER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT OUTER PCB SWITCH/CAP PLACEMENT HEAD 2025−200−132 (Blue Stone) 2025−000−115 (Blue Stone) 2025−000−126 (Blue Stone) 2025−22−46 2025−200−232 (Forest Green) 2025−000−215 (Forest Green) 2025−000−226 (Forest Green)
  • Page 101 Standard Siderail with DMS Option – International LEFT LEFT RIGHT RIGHT OUTER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT OUTER PCB SWITCH/CAP PLACEMENT HEAD 2025−200−137 (Blue Stone) 2025−000−114 (Blue Stone) 2025−000−118 2025−22−46 2025−200−237 (Forest Green) 2025−000−214 (Forest Green) LEFT LEFT RIGHT RIGHT...
  • Page 102 LEFT RIGHT SPEAKER MODULE RIGHT OUTER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT OUTER PCB SWITCH/CAP PLACEMENT HEAD 2025−200−135 (Blue Stone) 2025−000−112 (Blue Stone) 2025−000−117 2025−22−46 2025−200−235 (Forest Green) 2025−000−212 (Forest Green) LEFT LEFT SPEAKER MODULE...
  • Page 103 RIGHT OUTER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT OUTER PCB SWITCH/CAP PLACEMENT HEAD 2025−22−46 2025−000−118 2025−200−134 (Blue Stone) 2025−000−114 (Blue Stone) 2025−200−234 (Forest Green) 2025−000−214 (Forest Green) LEFT LEFT RIGHT RIGHT OUTER PCB SWITCH/CAP PLACEMENT...
  • Page 104 RIGHT SPEAKER MODULE RIGHT OUTER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT OUTER PCB SWITCH/CAP PLACEMENT HEAD 2025−200−135 (Blue Stone) 2025−000−113 (Blue Stone) 2025−000−126 (Blue Stone) 2025−22−46 2025−200−235 (Forest Green) 2025−000−213 (Forest Green) 2025−000−226 (Forest Green)
  • Page 105 LEFT RIGHT SPEAKER MODULE RIGHT OUTER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT OUTER PCB SWITCH/CAP PLACEMENT HEAD 2025−200−133 (Blue Stone) 2025−000−112 (Blue Stone) 2025−000−117 2025−22−46 2025−200−233 (Forest Green) 2025−000−212 (Forest Green) LEFT LEFT SPEAKER MODULE...
  • Page 106 RIGHT SPEAKER MODULE RIGHT OUTER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT INNER PCB SWITCH/CAP PLACEMENT OUTER PCB SWITCH/CAP PLACEMENT HEAD 2025−200−133 (Blue Stone) 2025−000−113 (Blue Stone) 2025−000−126 (Blue Stone) 2025−22−46 2025−200−233 (Forest Green) 2025−000−213 (Forest Green) 2025−000−226 (Forest Green)

  • Page 107: Foot Board Assembly

    Foot Board Assembly...
  • Page 108 2025–136–13 Foot Board Assembly – Chart Rack Option Item Part No. Part Name Qty. 3000–525–1 Chart Rack 3000–525–2 Chart Rod 3000–525–4 Pull Handle Label 2025–136–14 Foot Board Assembly – No Chart Rack Option Item Part No. Part Name Qty. 3000–500–8 Chart Rack Cover...
  • Page 109 Foot Board Assembly 2025–136–11 Foot Board Assembly – No Position Package Item Part No. Part Name Qty. (page 115) Standard Module Assembly...
  • Page 110 Foot Board Assembly 2025–136–12 Foot Board Assembly – Patient Positioning Option #1 Item Part No. Part Name Qty. (page 116) Patient Pos. Module Ass’y...
  • Page 111 Foot Board Assembly 2025–136–10 Foot Board Assembly – Patient Positioning Option #2 Item Part No. Part Name Qty. (page 116) Patient Pos. Module Ass’y 2025–136–21 E–Drop/Card. Ch. Module Ass’y 2025–136–801 E–Drop/Card. Chair Cable...
  • Page 112 Foot Board Assembly 2025–30–101 Foot Board Assembly – No Scale and No Bed Exit Option Item Part No. Part Name Qty. 3001–500–3 Blank Module 3000–500–26 Blank Module Label 3000–500–4 End Module 3000–500–27 Blank End Label...
  • Page 113 Foot Board Assembly 2025–30–176 Foot Board Assembly – Bed Exit Option Only Item Part No. Part Name Qty. 2025–30–177 Bed Exit Label 3001–400–953 Switch Cap (page 117) Bed Exit Module Assembly 3001–508–800 Bed Exit Keypad Cable 3001–500–3 Blank Module 3000–500–26 Blank Module Label 3000–500–4...
  • Page 114 Foot Board Assembly 2025–30–126 Foot Board Assembly – Scale Option Only Item Part No. Part Name Qty. 23–87 Pan Hd. Tapping Screw 23–91 Pan Hd. Tapping Screw 2025–30–127 Scale Lid Label 3001–400–953 Switch Cap 3001–507–1 Scale Module 3001–507–800 Scale Keypad Cable 3001–507–900...
  • Page 115 Foot Board Assembly 2025–30–151 Foot Board Assembly – Scale and Center of Gravity Bed Exit Option Only Item Part No. Part Name Qty. 23–87 Pan Hd. Tapping Screw 23–91 Pan Hd. Tapping Screw 2025–30–127 Scale Lid Label 3001–400–953 Switch Cap 3001–507–1...

  • Page 116: Foot Board Modules

    Foot Board Standard Module Assembly Assembly part number 2025–235–20 Item Part No. Part Name Qty. 2025–135–99 Foot Board Standard Module 3000–501–1 Gatch/Fowler Module 3001–400–953 Switch Cap 3001–500–930 Foot Board Main PCB Ass’y 23–87 Pan Hd. Screw...
  • Page 117 Foot Board Positioning Option Module Assembly Assembly part number 2025–236–20 Item Part No. Part Name Qty. 2025–136–99 Foot Board Pat. Pos. Module 3000–501–1 Gatch/Fowler Module 3001–400–953 Switch Cap 3001–500–930 Foot Board Main PCB Ass’y 23–87 Pan Hd. Screw...
  • Page 118 3001–508–30 Optional Bed Exit Module Assembly Item Part No. Part Name Qty. 3000–508–1 Bed Exit Module Panel 3001–400–953 Switch Cap 3001–508–910 Bed Exit Keypad Ass’y 23–87 Tapping Screw...
  • Page 119 2025–507–35 Scale Display Assembly Item Part No. Part Name Qty. 23–91 Pan Hd. Hi–Lo Tapping Screw 23–87 Pan Hd. Hi–Lo Tapping Screw 3001–507–910 Scale Keypad Assembly 3001–400–953 Switch Cap 3001–507–1 Scale Module 2025–000–152 Scale Module Label (Blue) 3001–507–900 Scale LCD Display 2025–000–252...

  • Page 120: Bed Labeling

    Blue Stone Labeling Assembly Options 2025–000–160 Standard Labels + Nurse Call 2025–000–161 Std. Labels + Nurse Call + DMS Item Part No. Part Name Qty. Item Part No. Part Name Qty. 2025–000–111 Std. NC Label, Inside, Lt. 2025–000–112 Std. DMS–NC, Inside, Lt.
  • Page 121 Part No. Part Name Qty. 2025–000–114 Std. DMS Label, Inside, Lt. 2025–000–114 Std. DMS Label, Inside, Lt. 1 2025–000–120 Std. Label, Inside, Rt. 2025–000–124 Std. DMS Label, Inside, Rt. 1 2025–200–130 Std. Label, Outside, Lt. 2025–200–137 Std. DMS Label, Outside, Lt.1 2025–200–140 Std.
  • Page 122 Blue Stone Labeling Assembly Options 2025–000–172 Std. Labels + Pat. Pos. Option #2 2025–000–173 Scale Option Labels Only Item Part No. Part Name Qty. Item Part No. Part Name Qty. 2025–000–110 Standard Label, Inside, Left 2025–000–152 Scale Module Label, Ft. Bd 2025–000–120 Standard Label, Inside, Right...
  • Page 123 Forest Green Labeling Assembly Options 2025–000–260 Standard Labels + Nurse Call 2025–000–261 Std. Labels + Nurse Call + DMS Item Part No. Part Name Qty. Item Part No. Part Name Qty. 2025–000–211 Std. NC Label, Inside, Lt. 2025–000–212 Std. DMS–NC, Inside, Lt.
  • Page 124 Part No. Part Name Qty. 2025–000–214 Std. DMS Label, Inside, Lt. 2025–000–214 Std. DMS Label, Inside, Lt. 1 2025–000–220 Std. Label, Inside, Rt. 2025–000–224 Std. DMS Label, Inside, Rt. 1 2025–200–230 Std. Label, Outside, Lt. 2025–200–237 Std. DMS Label, Outside, Lt.1 2025–200–240 Std.
  • Page 125 Forest Green Labeling Assembly Options 2025–000–272 Std. Labels + Pat. Pos. Option #2 2025–000–273 Scale Option Labels Only Item Part No. Part Name Qty. Item Part No. Part Name Qty. 2025–000–210 Standard Label, Inside, Left 2025–000–252 Scale Module Label, Ft. Bd 1 2025–000–220 Standard Label, Inside, Right...

  • Page 126: Head Board Assembly

    Head Board Assembly with CPR Option Assembly part number 2025–130–10 Item Part No. Part Name Qty. 23–88 Pan Hd. Screw 2222–500–7 Black “C” Bumper 3000–526–1 CPR Board 3000–526–2 CPR Board Clip 3000–526–3 CPR Board Label 3000–600–10 Head Board Clam Shell Ass’y 3000–600–56...

  • Page 127: Pendant Assembly

    Optional Pendant Assembly 3001–315–12 Combination Pendant 3001–315–16 Combination Pendant Motion/Communication Communication Only 3001–315–14 Combination Pendant 3001–315–18 Combination Pendant Motion Only Motion/NurseCall...

  • Page 128: Removable I.v. Pole Assembly

    3000–300–80 Removable I.V. Pole Assembly Item Part No. Part Name Qty. 3000–300–81 Outer Tube 3000–300–89 Label 24–50 Fluted Knob 52–17 Spacer 7–40 Phillips Truss Hd. Screw 1010–59–16 I.V. Hook 3000–300–85 Inner Tube Assembly...

  • Page 129: Permanent I.v. Pole Assembly

    2035–112 Optional 2–Stage I.V. Mounting Ass’y, Hd. End Item Part No. Part Name Qty. 1015–24–35 Retaining Pin 21–140 Set Screw 2035–112–1 I.V. Receptacle, Head, Left (page 130) I.V. Pole Assembly, Left 3000–311–16 I.V. Rest 2035–112–110 Specification Label...
  • Page 130 2035–111 Optional 2–Stage I.V. Mounting Assembly, Ft. End Item Part No. Part Name Qty. 4–199 But. Hd. Cap Screw 16–11 Flexlock Nut 21–140 Set Screw 2035–111–1 I.V. Receptacle, Foot, Left (page 130) I.V. Pole Assembly, Left 3000–312–35 I.V. Cradle 2035–112–110 Specification Label...
  • Page 131 2035–112–10 & 2035–113–11 Optional 2–Stage I.V. Ass’y 2035–112–10 Head End, Left 2035–113–11 Foot End, Right Item Part No. Part Name Qty. Item Part No. Part Name Qty. 8–31 Soc. Hd. Shoulder Screw 8–31 Soc. Hd. Shoulder Screw 52–17 Washer 52–17 Washer 52–310 Spacer...
  • Page 132 1211–210–26 I.V. Pole Latch Assembly Item Part No. Part Name Qty. 28–167 Retaining Ring 31–4 Steel Ball 38–392 Crest–to–Crest Spring 1211–91–34 Release Label 1211–110–18 I.V. Latch Seal 1211–110–20 Washer 1211–110–21 I.V. Latch Locking Pin 1211–110–22 I.V. Latch Guide 1211–110–24 I.V. Latch O.D. Housing 1211–110–35 Washer 1211–110–36...

  • Page 133: Upright Oxygen Bottle Holder

    2025–150–10 Optional Upright O2 Bottle Holder Ass’y Item Part No. Part Name Qty. 1010–30–11 Upright Bottle Holder 2025–150–1 Bottle Holder Adapter 2025–150–2 Specification Label...

  • Page 134: Defibrillator Tray Assembly

    2025–120 Optional Defibrillator Tray Assembly Item Part No. Part Name Qty. Item Part No. Part Name Qty. 8–49 Soc. Hd. Shoulder Bolt 1010–50–21 Long Strap 14–20 Thrust Washer 1010–50–50 Knob 14–21 Thrust Washer 1010–50–57 Max. Weight Label 16–28 Fiberlock Nut 1010–50–242...

  • Page 135: Fowler X-Ray Cassette Tray Assembly

    2025–141 Optional Fowler X–Ray Cassette Mtg. Ass’y Item Part No. Part Name Qty. 4–149 Hex Soc. But. Hd. Cap Screw 16–3 Self Locking Nut 25–50 Pop Rivet 2025–140–3 Tray Hinge 1020–23–14 Tray Latch...
  • Page 136 2025–140 Optional Fowler X–Ray Cassette Assembly Item Part No. Part Name Qty. Item Part No. Part Name Qty. 2025–140–1 Tray 1020–23–26 Spacer 1020–23–16 Post Housing 1020–23–19 Tray Hinge, Right 2025–140–2 Actuating Rod 1020–23–20 Tray Hinge, Left 926–23–64 Post 926–23–71 Bushing 1010–23–37...

  • Page 137: Bed Extender Mattress

    2025–40–10 Optional Bed Extender Mattress...

  • Page 138: Limited Warranty

    No employee or representative of Stryker is authorized to change this warranty in any way. Stryker Medical stretchers are designed for a 10 year expected life under normal use conditions and appropri- ate periodic maintenance as described in the maintenance manual for each device.

  • Page 139: Return Authorization

    Claims for any short shipment must be made within thirty (30) days of invoice. International Warranty Clause: This warranty reflects U.S. domestic policy. Warranty outside the U.S. may vary by country. Please contact your local Stryker Medical representative for additional information.
  • Page 140 European Representative Stryker France Phone: 33148632290 BP 50040–95946 Roissy Ch. de Gaulle Fax: 33148632175 Cedex–France 6300 Sprinkle Road, Kalamazoo, MI 49001–9799 (800) 327–0770 www.strykermedical.com DH 1/02 2025–100–8 REV A...

This manual is also suitable for:

2026

Table of Contents

Save PDF
