720 Transport Stretcher
Operations Manual
For Parts or Technical Assistance
800 - 327 - 0770

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 720 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Stryker Medical 720

  • Page 1 720 Transport Stretcher Operations Manual For Parts or Technical Assistance 800 - 327 - 0770...
  • Page 2: Table Of Contents

    Table of Contents Introduction ................2, 3 Applying the Brake System .
  • Page 3: Introduction

    Introduction INTRODUCTION This manual is designed to assist you with the operation of the 720 Transport Stretcher. Read it thoroughly before using the equipment or beginning any maintenance on it. SPECIFICATIONS Maximum Weight Capacity 500 pounds Overall Bed Length/Width 81”, 30”...
  • Page 4: Introduction

    Introduction Before operating this stretcher, it is important to read and understand all information in this manual. Carefully read and strictly follow the warnings listed on this page. WARNING Always apply the caster brakes when a patient is getting on or off the stretcher. Push on the stretcher to en- sure the brakes are securely locked.
  • Page 5: Applying The Brake System

    Stretcher Operation APPLYING THE BRAKE SYSTEM (A) Brake and Steer Functions (Head End) (B) Brake and Steer Functions (Foot End) To engage the brakes from the head (non-control) end of the stretcher, push fully down on the left side of pedal (A).
  • Page 6: Operating Directional Steering Caster/5Th Wheel Options

    ADJUSTING STRETCHER HEIGHT NOTE The 720 Transport Stretcher is available from the factory in three ”fixed” heights: 28”, 30”, and 32”. The stretcher height was determined at the time of purchase. Follow the procedure below to change the stretcher height.
  • Page 7: Using Siderails

    Stretcher Operation USING THE SIDERAILS CAUTION Be sure the siderail latching mechanism (B) is working properly at all times. If it is not, refer to your stretcher maintenance manual for ”Siderail Latch Adjustment”. To engage siderails: Pull up siderail (A) and raise to full up position so that latch (B) engages. To disengage siderails: Pull up on latch (B) and guide siderail to the full down position.
  • Page 8: Using The Patient Transfer Board

    Stretcher Operation USING THE PATIENT TRANSFER BOARD WARNING When using the transfer board to transfer a patient, always lock the brakes on all stretchers, beds, etc. being used and always be certain the transfer board is placed securely on the surface of the mating stretcher or bed.
  • Page 9: Operating The Fowler

    Stretcher Operation OPERATING THE FOWLER NOTE There are two types of fowler options: 1) manually operated, 2) pneumatic operated. Manual Fowler: Lift up on the Fowler handles (A). The brace as- sembly (B) will fall into position as the Fowler is raised to the desired height.
  • Page 10: Using The Optional 2-Stage I.v. Pole

    Stretcher Operation OPERATING THE OPTIONAL 2 - STAGE PERMANENTLY ATTACHED I.V. POLE DETAIL OF I.V. POLE LATCH NOTE The 2-stage permanently attached I.V. pole is an option and may have been installed at either the head, foot or both ends of the stretcher. The choice was made at the time the stretcher was purchased. To use the 2-stage permanently attached I.V.
  • Page 11: Using The Optional 3-Stage I.v. Pole

    Stretcher Operation OPERATING OPTIONAL 3 - STAGE PERMANENTLY ATTACHED I.V. POLE DETAIL OF I.V. POLE LATCH DETAIL OF I.V. POLE GRIP NOTE The 3-stage permanently attached I.V. pole is an option and may have been installed at either the head, foot or both ends of the stretcher.
  • Page 12: Operating The Optional Tethered I.v. Pole

    Stretcher Operation OPERATING THE OPTIONAL TETHERED I.V. POLE 1. Remove the I.V. pole from the storage trough under the litter and insert into the receptacle on the corner of the litter frame. 2. To raise the height of the pole, turn knob (A) counterclockwise and pull up on the telescoping portion (B) of the pole to raise it to the desired height.
  • Page 13: Preventative Maintenance Checklist

    Preventative maintenance should be performed at a minimum of annually. A preventative maintenance pro- gram should be established for all Stryker Medical equipment. Preventative maintenance may need to be performed more frequently based on the usage level of the product.
  • Page 14: Cleaning

    Cleaning Hand wash all surfaces of the stretcher with warm water and mild detergent. Dry thoroughly. DO NOT STEAM CLEAN, PRESSURE WASH, HOSE OFF OR ULTRASONICALLY CLEAN. Using these methods of cleaning is not recommended and may void this product’s warranty. Clean Velcro AFTER EACH USE.
  • Page 15: Limited Warranty

    No employee or representative of Stryker is authorized to change this warranty in any way. Stryker Medical stretchers are designed for a 10 year expected life under normal use conditions and appropri- ate periodic maintenance as described in the maintenance manual for each device.
  • Page 16: Return Authorization

    Claims for any short shipment must be made within thirty (30) days of invoice. International Warranty Clause: This warranty reflects U.S. domestic policy. Warranty outside the U.S. may vary by country. Please contact your local Stryker Medical representative for additional information.
  • Page 17 European Representative Stryker EMEA RA/QA Director Stryker France ZAC Satolas Green Pusignan Av. De Satolas Green 69881 MEYZIEU Cedex France 6300 S. Sprinkle Road, Kalamazoo, MI 49001-9799 (800) 327-0770 www.strykermedical.com DH 8/03 0720-100-126 REV G...
