4400 Infant Bassinet
Operations/Maintenance Manual
For Parts or Technical Assistance
800-327-0770

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Stryker Medical 4400

Summary of Contents for Stryker Medical 4400

  • Page 1 4400 Infant Bassinet Operations/Maintenance Manual For Parts or Technical Assistance 800-327-0770...

  • Page 2: Table Of Contents

    Table of Contents Introduction Warning / Caution / Note Definition ............Specifications .

  • Page 3: Introduction

    Introduction INTRODUCTION The Stryker Infant Bassinet is intended for use as a support and transport surface for an infant in a health care environment. This manual is designed to assist you with the operation of the Stryker Infant Bassinet. Read it thoroughly before using the equipment or beginning any maintenance on it.

  • Page 4: Specifications

    Introduction SPECIFICATIONS 18.38 34.22 38.13 22.50 32.50 MODERN STYLE 18.38 34.22 38.13 32.75 22.75 SHAKER, TRADITIONAL AND EURO STYLES (EURO SHOWN)

  • Page 5: Safety Tips And Guidelines

    Introduction SAFETY TIPS AND GUIDELINES Before operating the Stryker Infant Bassinet, it is important to read and understand all information in this manual. Carefully read and strictly follow the safety guidelines listed on this page. WARNING To avoid risk of injury, never leave an infant unattended and do not leave sheets, blankets, pillows or other items in the bassinet with the infant.

  • Page 6: Proper Bassinet Pushing Technique

    Bassinet Operating Instructions PROPER BASSINET PUSHING TECHNIQUE TOP VIEW OF BASSINET DRAWER / DOOR SIDE LABEL #1 WARNING DO NOT PUSH IN THESE DIRECTIONS LABEL #2 WARNING Push the bassinet only from the ends as indicated by the illustrations above. Do not push the bassinet from the sides or tipping of the bassinet could occur and injury could result.

  • Page 7: Trendelenburg Positioning

    Bassinet Operating Instructions TRENDELENBURG POSITIONING To put the bassinet into the Trendelenburg/Reverse Trendelenburg position, lift up on either end of the tub, then lower it until the “J” hook engages securely with the end rail (see above). WARNING When putting the bassinet into Trendelenburg/Reverse Trendelenburg, verify the “J” hook is engaged and secure before releasing the tub or injury could occur.

  • Page 8: Preventative Maintenance Checklist

    Preventive Maintenance MAINTENANCE CHECKLIST All fasteners secure All casters secure and swiveling properly No debris in casters Front casters hold when brakes are applied Pull-out chart board intact and secure Trendelenburg hook intact Drawers intact and sliding smoothly Doors intact and hinges operating smoothly Warning labels intact and legible Serial No.______________ ______________...

  • Page 9: Modern-Style Bassinet Assembly

    Modern-Style Bassinet Assembly Assembly part number 4400-118-001 (reference only) EACH INTERIOR SIDE EACH SIDE BUMPER ASSEMBLY TYPICAL 4 PLACES Item Part No. Part Name Qty. (page 9) Modern Bassinet 8804-002-700 Bumper 8801-580-200 Grabber Screw 8800-469-800 8800-455-200 8800-346-300 Mattress 4400-1 18-400...
  • Page 10 Modern-Style Bassinet Assembly Assembly part number 4400-118-002 (reference only) Item Part No. Part Name Qty. 4400-1 18-100 Modern Cabinet 4400-1 18-218 Push Handle 4400-1 18-219 Push Handle Rod 4400-1 10-064 Bolt 4400-1 10-065 T-Nut 4400-1 10-063 Screw 4400-1 10-060 Locking Swivel Caster...

  • Page 11: Shaker-Style Bassinet Assembly

    Shaker-Style Bassinet Assembly Assembly part number 4400-219-001 (reference only) EACH INTERIOR SIDE EACH SIDE BUMPER ASSEMBLY TYPICAL 4 PLACES Item Part No. Part Name Qty. (page 11) Shaker Bassinet 8804-002-700 Bumper 8801-580-200 Grabber Screw 8800-469-800 8800-455-200 8800-346-300 Mattress 4400-1 18-400...
  • Page 12 Shaker-Style Bassinet Assembly Assembly part number 4400-218-001 (reference only) Item Part No. Part Name Qty. 4400-218-100 Shaker Cabinet 4400-1 18-218 Push Handle 4400-1 18-219 Push Handle Rod 4400-1 10-064 Bolt 4400-1 10-065 T-Nut 4400-1 10-063 Screw 4400-1 10-060 Locking Swivel Caster...

  • Page 13: Traditional-Style Bassinet Assembly

    Traditional-Style Bassinet Assembly Assembly part number 4400-318-001 (reference only) EACH INTERIOR SIDE EACH SIDE BUMPER ASSEMBLY TYPICAL 4 PLACES Item Part No. Part Name Qty. (page 13) Traditional Bassinet 8804-002-700 Bumper 8801-580-200 Grabber Screw 8800-469-800 8800-455-200 8800-346-300 Mattress 4400-1 18-400...
  • Page 14 Traditional-Style Bassinet Assembly Assembly part number 4400-318-002 (reference only) Item Part No. Part Name Qty. 4400-318-100 Traditional Cabinet 4400-1 18-218 Push Handle 4400-1 18-219 Push Handle Rod 4400-1 10-064 Bolt 4400-1 10-065 T-Nut 4400-1 10-063 Screw 4400-1 10-060 Locking Swivel Caster...

  • Page 15: Euro-Style Bassinet Assembly

    Euro-Style Bassinet Assembly Assembly part number 4400-318-001 (reference only) EACH INTERIOR SIDE EACH SIDE BUMPER ASSEMBLY TYPICAL 4 PLACES Item Part No. Part Name Qty. (page 15) Euro Bassinet 8804-002-700 Bumper 8801-580-200 Grabber Screw 8800-469-800 8800-455-200 8800-346-300 Mattress 4400-1 18-400...

  • Page 16: Euro-Style Bassinet Assembly

    Euro-Style Bassinet Assembly Assembly part number 4400-418-002 (reference only) Item Part No. Part Name Qty. 4400-418-100 Euro Cabinet 4400-1 18-218 Push Handle 4400-1 18-219 Push Handle Rod 4400-1 10-064 Bolt 4400-1 10-065 T-Nut 4400-1 10-063 Screw 4400-1 10-060 Locking Swivel Caster...

  • Page 17: Knobs

    Knobs - All Bassinets KNOBS Part Number Description 8100-000-003 Round Knob, Brushed Antique Brass 8100-000-004 Round Knob, Polished Brass 8100-000-005 Oval Knob, Polished Chrome 8100-000-010 Round Knob, Polished Chrome 8100-000-01 1 Round Knob, Brushed Stainless Steel 8100-000-012 Oval Knob, Polished Brass 8100-000-013 Oval Knob, Brushed Antique Brass 8100-000-014...

  • Page 18: Warranty

    No employee or representative of Stryker is authorized to change this warranty in any way. Stryker Medical stretchers are designed for a 10 year expected life under normal use conditions and appropri- ate periodic maintenance as described in the maintenance manual for each device.

  • Page 19: Return Authorization

    Claims for any short shipment must be made within thirty (30) days of invoice. International Warranty Clause: This warranty reflects U.S. domestic policy. Warranty outside the U.S. may vary by country. Please contact your local Stryker Medical representative for additional information.
  • Page 20 European Representative Stryker France Phone: 33148632290 BP 50040-95946 Roissy Ch. de Gaulle Fax: 33148632175 Cedex-France 6300 Sprinkle Road, Kalamazoo, MI 49001-9799 (800) 327-0770 www.strykermedical.com DH 9/02 4400-118-400 REV A...
