- Page 1 IMPORTANT Keep manual on file at all times. Model 6080–170 Defibrillator Platform OPERATIONS/MAINTENANCE MANUAL For Parts or Technical Assistance 1–800–784–4336...
-
Page 2: Table Of Contents
Table of Contents Warranty Obtaining Parts and Service ............. . . Supplemental Warranty Coverage . -
Page 3: Warranty
Warranty Limited Warranty: Stryker Medical Division, a division of Stryker Corporation, warrants to the original purchaser that its products should be free from defects in material and workmanship for a period of one (1) year after date of delivery. Stryker’s obligation under this warranty is expressly limited to supplying replacement parts and labor for, or replacing, at its option, any product which is, in the sole discretion of Stryker, found to be defective. -
Page 4: Return Authorization
Claims for any short shipment must be made within thirty (30) days of invoice. International Warranty Clause: This warranty reflects U.S. domestic policy. Warranty outside the U.S. may vary by country. Please contact your local Stryker Medical representative for additional information. -
Page 5: Safety Precautions
Safety Precautions The following is a list of safety precautions that must be observed when operating the Defibrillator Platform. The precautions are repeated throughout the manual, where applicable. Carefully read this list before using the unit. WARNING To avoid equipment damage and/or patient injury, the Defibrillator Platform must be mounted and secured properly to the Rugged cot, To avoid equipment damage and/or patient injury, the defibrillator must be secured properly to the Defibril- lator Platform with the straps provided. -
Page 6: Preventative Maintenance
Platform straps intact – not frayed or torn Both latch hooks intact and secure Completed By:_________________________________ Date:_____________ Parts, Service or Technical Assistance: Contact Stryker Customer Service at 1–800–784–4336 or Stryker Medical 6300 Sprinkle Road Kalamazoo, MI 49001 ATTN: Customer Service... - Page 7 Operating the Defibrillator Platform Defibrillator Platform in the stored position. Open the legs of the Defibrillator Platform. Lift the I.V. pole if the cot is equipped with one. Place the Defibrillator Platform on the cot frame. NOTE The ”inside” legs (A) of the Defibrillator Platform must be toward the foot end of the cot or the Platform will not fit properly on the cot frame.
-
Page 8: Operating The Rugged Defibrillator Platform
Operating the Defibrillator Platform Place the latch hook (A) under the cot litter frame and push the tab (B) up until it locks into place with an audible ”click”. Repeat on the other side of the Defibrillator Platform. WARNING: To avoid equipment damage and/or patient injury, the Defibrillator Platform must be mounted and secured properly to the Rugged cot. - Page 9 Operating the Defibrillator Platform Ensure the Defibrillator Platform is properly secured to the cot. Place the defibrillator on the Defibrillator Platform and secure it with the straps. WARNING: To avoid equipment damage and/or patient injury, the defibrillator must be secured properly to the Defibrillator Platform with the straps provided.
-
Page 10: Latch Strap Assembly
6080–170–20 Latch Strap Assembly Item Part No. Part Name Qty. 6080–170–21 Clamp Base 6080–170–22 Clamp Lever 6080–170–23 Clamp Lever Spacer 6080–170–24 Latch Restraint Strap 6080–170–26 Hook Boot 6080–170–27 Lever Grip 26–281 Groove Pin 6080–170–28 Latch Hook... -
Page 11: Defibrillator Platform Assembly
Defibrillator Platform Assembly Assembly part number 6080–170–10... - Page 12 Defibrillator Platform Assembly Item Part No. Part Name Qty. 6080–170–11 Top Panel 6080–170–12 Leg Support 6080–170–13 Stationary Leg 6080–170–14 Sliding Leg 6080–170–15 Leg Support Pivot 6080–170–16 Leg Collar 6080–170–50 U–Foot Weldment 6080–170–26 U–Foot Boot (page 9) Latch Strap Assembly 4–234 Hex Soc.
- Page 13 European Representative Stryker France Phone: 33148632290 BP 50040–95946 Roissy Ch. de Gaulle Fax: 33148632175 Cedex–France 6300 Sprinkle Road, Kalamazoo, MI 49001–9799 (800) 327–0770 DH 6/00 6080–170–9 REV D...
