ARK-5261 / ARK-5261I
Intel® Celeron® Processor J1900 Fanless Embedded
BOX PC with PCI/PCIe Expansion and Dual Mobile
HDDs/SSDs
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. ARK-5261 System x 1
(ARK-5261I System x 1 P/N: ARK-5261I-J0A1E)
2. Startup Manual x 1
3. Driver CD x 1
4. Warranty Card
5. Wallmount bracket x2
6. DB37 to DB9 Cable*
Only for ARK-5261I version
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1:
For detailed contents of ARK-5261, please refer
to information on the enclosed CD-ROM (in PDF
format).
Note 2:
Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at: get.
adobe.com/reader (Acrobat is a trademark of
Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/default.
aspx
This manual is for the ARK-5261 Series Rev. A1.
Part No. 2001526110
Printed in China
P/N: ARK-5261S-J0A1E
P/N: 2001526110
P/N: 2061526100
P/N: 2190000902
P/N: 1960049826N001
1960049827N001
P/N:* 1700021869-01
1st Edition
Specifications
Processor System
• Intel® Celeron® Processor J1900 up to 2.41 GHz
Memory
• Support daul channel DDR3L (Lower power 1.35V)-1333
Mhz, 2GB per slot without ECC function; Max. capacity is
up to 8GB
Graphics
• Chipset integrated Intel HD Graphic
Serial Ports
• Standard Type:
- 4x RS-232/422/485, selection by BIOS
- Support Auto-flow control
- COM1 & COM2 support 5V/12V power, selection by
Jumper
• Isolation Type:
- 4 x RS-422/485 ports (by DB37 to 4x DB9 cable)
- ESD protection: 15Kv
- Suger production: 2Kv
- Electrical Isolation: 2Kv
Ethernet
• Interface: 10/100/1000 Mbps
• Controller:
LAN1: Intel I211, supports Wake on LAN
LAN2: Intel I211, supports Wake on LAN
Storage
• Internal 2.5" HDD Bay: 2
• m-SATA: 1 (Shared with SATA 2)
Front I/O
• Display: 1 x VGA
• USB: 1 x USB3.0; 4 x USB2.0; 1 x Internal USB2.0
• Serial: 4 x RS-232/422/485 selection by BIOS
• DIO: Support 8-bit GPIO by DB9 Connector
• Parallel port: Support D-sub 25 pin connector
• Keyboard/Mouse: 1 x PS/2 port, support PS/2 mouse
and Keyboard
Power Requirement
• Power Type: ATX / AX
• Power Input Voltage: 9~30 VDC
• Minimum Power Input:9V @ 6.6A ~ 30V @ 2A
• Power Adapter: AC to DC, 65W DC19V/3.4A
2014
ARK-5261 Startup Manual 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARK-5261 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Advantech ARK-5261

  • Page 1 • Power Type: ATX / AX aspx • Power Input Voltage: 9~30 VDC This manual is for the ARK-5261 Series Rev. A1. • Minimum Power Input:9V @ 6.6A ~ 30V @ 2A Part No. 2001526110 1st Edition • Power Adapter: AC to DC, 65W DC19V/3.4A...
  • Page 2: Jumpers And Connectors

    USB 1 USB 3.0 PS/2 Keyboard & Mouse connector The drivers for the ARK-5261 are located on the software COM 12 RS-232/422/485 with Power installation CD. Please click through the folder and follow the on screen instructions to install them.
  • Page 3: Hdd Installation

    6. Replace the HDD door and secure with screws. Simple Maintain Process Memory Installation Warring: ARK-5261 system already is on-board 4GB memory inside, if you want to expand to 8GB. Please connect your sales or agents to order com- patible memory modules, the part number below: AQD-SD3L4GN16-SG 4G SO-DDR3-1600 512x8 1.35v SAM...
  • Page 4: System Dimension

    System Dimension 240.97 Unit : mm(inch) 234.07 4 ARK-5261 Startup Manual...
  • Page 5 ARK-5261 / ARK-5261I 无风扇嵌入式工控机 搭载Intel® Celeron® 处理器J1900, 支持PCI/PCIe扩展和双移动HDD/SSD 快速入门手册 包装清单 产品规格 处理器系统 安装板卡之前,用户需确认包装中含有下面所列各项: 1. ARK-5261系统 x 1 P/N:ARK-5261S-J0A1E • Intel® Celeron® 处理器J1900,最高可达2.41 GHz (ARK-5261I系统 x 1 P/N:ARK-5261I-J0A1E) 内存 2. 快速入门手册 x 1 P/N: 2001526110 • 支持双通道DDR3L(低功耗1.35V)-1333 Mhz,每个插槽可 3. 驱动光盘 x 1 P/N: 2061526100 支持2 GB(不支持ECC功能);最大容量可达8 GB...
  • Page 6 COM 34 RS-232/422/485 软件安装 Isolation COM* RS-422/485隔离COM ARK-5261的驱动保存在软件安装光盘中。请双击文件夹中的 DIO1 GPI接口 驱动程序并按照屏幕指示进行安装。 打印机接口 注意! 计算机配置了由电池供电的实时时钟电路,如果 电池更换不正确,将有爆炸的危险。因此,只可 USB 2345 USB 2.0接口2、3、4、5 以使用制造商推荐的同一种或者同等型号的电池 Audio 音频插孔 x 2 进行替换。请按照制造商的指示处理旧电池。 DC 9 ~ 30V2 电源接口 符合性声明 * 仅适用于隔离版 本品符合FCC规则第15款限制。操作符合下列两种情况: 1. 此装置不可产生干扰,且 2. 此装置必须接受任何干扰,包括可能导致非预期操作的 干扰。 2 ARK-5261快速入门手册...
  • Page 7 系统I/O接口 简单安装步骤(续) HDD安装 1. 卸下HDD挡板上的螺丝。 2. 卸下HDD托架上的螺丝。 3. 用四颗螺丝将2.5”SATA HDD固定在支架的底部。 4. 将支架插入到机箱中。 5. 用螺丝将HDD托架固定。 6. 放回HDD挡板并用螺丝固定。 简单安装步骤 内存安装 警告: ARK-5261系统已内置板载4 GB内存。如需扩展为8 GB内存,请联系研华销售代表或销售代理订购适用 的内存模块。产品料号如下: AQD-SD3L4GN16-SG 4G SO-DDR3-1600 512x8 1.35v SAM 注: 若ARK-5261采用了不同品牌的SO-DIMM内存,则系 统将无法启动。 m-SATA安装 支持电源跳线选择的COM 1. 卸下两颗螺丝并移除顶盖。 1. 卸下并移除左侧盖上的螺丝。 2. 卸下螺丝并移除顶部支架和左侧机箱盖。...
  • Page 8 系统尺寸 240.97 Unit : mm(inch) 234.07 4 ARK-5261快速入门手册...
