Figure 63. DD9800 with ES30 shelves, HA (one rack)
DD9800 with HA (two racks)
For an HA DD9800 pair in two racks:
Table 14. DD9800 with ES30 HA primary node cabling instructions (two racks)
String
I/O - Port
(Loop)
1
I/O 3 - Port 1
1
I/O 2 - Port 0
Shelf Port
B controller HOST
port of shelf V1.1
A controller HOST
port of the highest number shelf in V1
Connect Cables and Power On
a
Length
2M
2M
59
