Instructions for Use
Urinal flush plate for Prevista
Visign for Style 21
for urinal flushing systems
Model
8611.2
Year built (from)
03/2019
INT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8611.2 and is the answer not in the manual?

Questions and answers

Related Manuals for Viega 8611.2

Summary of Contents for Viega 8611.2

  • Page 1 Instructions for Use Urinal flush plate for Prevista Visign for Style 21 for urinal flushing systems Model Year built (from) 8611.2 03/2019...

  • Page 2: Table Of Contents

    Table of contents Table of contents About these instructions for use 1.1 Target groups 1.2 Labelling of notes 1.3 About this translated version Product information 2.1 Standards and regulations 2.2 Intended use 2.2.1 Areas of use 2.2.2 Maintenance 2.3 Product description 2.3.1 Overview 2.3.2...

  • Page 3: About These Instructions For Use

    This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use.

  • Page 4: About This Translated Version

    About these instructions for use About this translated version This instruction for use contains important information about the choice of product or system, assembly and commissioning as well as intended use and, if required, maintenance measures. The information about the products, their properties and application technology are based on the current standards in Europe (e.g.

  • Page 5: Product Information

    Product information Product information Standards and regulations The following standards and regulations apply to Germany / Europe and are provided as a support feature. Regulations from section: Technical data Scope / Notice Regulations applicable in Ger‐ many Flush flow DIN 3265 Noise class DIN 4109 Intended use...

  • Page 6: Product Description

    Product information Product description 2.3.1 Overview Fig. 1: Scope of delivery flush plate silicon grease cartridge valve actuator sleeve retaining bolt installation frame 2.3.2 Technical data The product has the following technical data: Minimum flow pressure 0.05–0.5 MPa (0.5–5 bar) Flush flow, see Ä...

  • Page 7: Handling

    Handling Handling Assembly information 3.1.1 Required material and tools Tool The following tools are required for mounting: cutting knife Assembly 3.2.1 Insert cartridge valve Requirements: The pre-wall element has been mounted. The tiling work is completed. The revision opening is freely accessible. The urinal ceramic has been mounted.
  • Page 8 Handling ▶ Cut into the corners of the revision shaft. ▶ Fold the sides of the revision shaft outwards up to the tile level and snap them off. ▶ Open the shut-off with a screwdriver for a few seconds to rinse the pipeline.
  • Page 9 Handling ▶ Place the brass nut on the cartridge valve. INFO! Check that the sealing element is properly positioned. ▶ Place the cartridge valve on straight and carefully screw in (fine thread). Tightening torque: 5 Nm ▶ Screw in the cartridge valve (size 27). ▶...

  • Page 10: Mounting The Flush Plate

    Handling ▶ Set the flush volume. Setting range 1 l to 6 l ▶ Actuate a flushing and check the set flush volume. ▶ Re-set the flush volume if applicable. 3.2.2 Mounting the flush plate Requirements: The cartridge valve is mounted and set. ▶...
  • Page 11 Handling ▶ Place the sleeve over the actuator. ▶ Measure the actuator. INFO! The actuator must not protrude over the sleeve. ▶ Take the installation frame and actuator off again. ▶ Cut the actuator to length. Urinal flush plate for Prevista Visign for Style 21...
  • Page 12 Handling ▶ Insert the actuator. Observe proper alignment. ▶ Apply the installation frame. ▶ Place the sleeve over the actuator. ▶ Secure the sleeve with a 90° clockwise turn. ▶ Slide the retaining bolt in. ▶ If necessary, remove the retaining bolts again and cut the segments to length.
  • Page 13 Handling ▶ Align the installation frame. ▶ Turn the retaining bolts by 90° in a clockwise direction. ▶ To fix the retaining bolts, turn safety rings in a clockwise direction. ▶ Mount the flush plate. ▷ The flush plate is mounted. Urinal flush plate for Prevista Visign for Style 21...

  • Page 14: Errors, Faults And Remedy

    Handling Errors, faults and remedy Error Cause Remedy The urinal does not flush. The shut-off valve closed. Open the shut-off valve. The cartridge valve dirty or dam‐ Clean the cartridge valve, if neces‐ aged. sary replace it. Ä Chapter 3.4.2 „Cleaning car‐ tridge valve“...
  • Page 15 Handling ▶ Turn the safety rings 90° anti-clockwise. ▶ Turn the retaining bolts 90° anti-clockwise. ▶ Turn the sleeve 90° clockwise to unlatch it. ▶ Loosen the installation frame. Urinal flush plate for Prevista Visign for Style 21...

  • Page 16: Disposal

    Handling ▶ Close the shut-off. ▶ Remove the actuator. ▶ Unscrew the cartridge valve. ▶ Rinse the cartridge valve under running water. Remove coarse dirt with a soft brush. ▶ Re-mount the cartridge valve and the flush plate in accordance with Ä...
  • Page 17 Viega Technology GmbH & Co. KG service-technik@viega.de viega.com INT • 2020-07 • VPN200177...
