WC installation frame for Prevista with LED
lighting
Instructions for Use
for all Prevista concealed cisterns
Model
8650.1
en_INT
Year built:
from 09/2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8650.1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Viega 8650.1

  • Page 1 WC installation frame for Prevista with LED lighting Instructions for Use for all Prevista concealed cisterns Model Year built: 8650.1 from 09/2018 en_INT...
  • Page 2 WC installation frame for Prevista with LED lighting 2 from 10...
  • Page 3: Table Of Contents

    Table of contents Table of contents About these instructions for use Target groups Labelling of notes About this translated version Product information Intended use 2.1.1 Areas of use Product description 2.2.1 Overview Handling Assembly 3.1.1 Mounting the installation frame Disposal WC installation frame for Prevista with LED lighting 3 from 10...
  • Page 4: About These Instructions For Use

    This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use.
  • Page 5: About This Translated Version

    About these instructions for use About this translated version This instruction for use contains important information about the choice of product or system, assembly and commissioning as well as intended use and, if required, maintenance measures. The information about the products, their properties and application technology are based on the current standards in Europe (e.g.
  • Page 6: Product Information

    Product information 2 Product information Intended use 2.1.1 Areas of use The installation frame is intended for the installation of the WC flush plates for Prevista Visign for More 201 and 204 in dry construction pre- walls. Product description 2.2.1 Overview Fig.
  • Page 7: Handling

    Handling 3 Handling Assembly 3.1.1 Mounting the installation frame Requirements: The power pack is installed and connected to the motor. The control has been plugged onto the cover plate. The cistern is fitted into the pre-wall. The pre-wall is tiled. Turn the cover plate lock 90°...
  • Page 8 Handling Guide the two ends of the Y-cable forward through the right-hand opening of the cover plate. Replace the cover plate and lock it. Put on the installation frame. Insert the retaining bolts. Turn the retaining bolts by 90° in a clockwise direction. WC installation frame for Prevista with LED lighting 8 from 10...
  • Page 9 Handling Align the installation frame. To fix the retaining bolts, turn safety rings in a clockwise direction. INFO! When using the WC flush plate Visign for More 201: Loosen the infrared sensor and plug it on the bottom wall bracket. Apply the silicon grease to the connections.
  • Page 10: Disposal

    Handling Disposal Separate the product and packaging materials (e. g. paper, metal, plastic or non-ferrous metals) and dispose of in accordance with valid national legal requirements. WC installation frame for Prevista with LED lighting 10 from 10...
