Prevista installation set
Instructions for Use
for Prevista remote flush actuations
Model
8640.14
en_INT
Year built:
from 03/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Prevista 8640.14 and is the answer not in the manual?

Questions and answers

Related Manuals for Viega Prevista 8640.14

Summary of Contents for Viega Prevista 8640.14

  • Page 1 Prevista installation set Instructions for Use for Prevista remote flush actuations Model Year built: 8640.14 from 03/2019 en_INT...
  • Page 2 Prevista installation set 2 from 10...

  • Page 3: Table Of Contents

    Table of contents Table of contents About these instructions for use Target groups Labelling of notes About this translated version Product information Intended use 2.1.1 Areas of use Product description 2.2.1 Overview Handling Assembly Disposal Prevista installation set 3 from 10...

  • Page 4: About These Instructions For Use

    This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use.

  • Page 5: About This Translated Version

    About these instructions for use About this translated version This instruction for use contains important information about the choice of product or system, assembly and commissioning as well as intended use and, if required, maintenance measures. The information about the products, their properties and application technology are based on the current standards in Europe (e.g.

  • Page 6: Product Information

    Product information 2 Product information Intended use 2.1.1 Areas of use The Prevista installation set is required for the installation of WC remote flush actuations for Prevista. Product description 2.2.1 Overview Fig. 1: Scope of delivery Concealed socket Screws and plates for fixing Protective pipe Prevista installation set 6 from 10...

  • Page 7: Handling

    Handling 3 Handling Assembly Requirements: The maximum cable length is 3 m. – Factor in at least 0.25 m for the cistern. The distances conform to the specifications: Fasten the screws and securing plates in the concealed socket. Push through the concealed socket at the pre-punched location. Prevista installation set 7 from 10...
  • Page 8 Handling WC element, construction height 1120 mm or 980 mm Cut in the cap crosswise for the free water connection. Insert the empty pipe into the cistern. WC element, construction height 820 mm Route the empty pipe through the shower WC connection into the cistern.
  • Page 9 Handling Cut out the template for the remote flush actuation from the accom‐ panying instructions. Cut the recess for the empty pipe from the template. Route the empty pipe through the template. Position the template on the gypsum cladding panel. Route the empty pipe through the concealed socket.

  • Page 10: Disposal

    Handling Screw on the concealed socket. Disposal Separate the product and packaging materials (e. g. paper, metal, plastic or non-ferrous metals) and dispose of in accordance with valid national legal requirements. Prevista installation set 10 from 10...
