- Page 1 Prevista Dry frame element Instructions for Use for Prevista Dry Plus fitting holder and module Model Year built: 8570 from 03/2019 en_INT...
- Page 2 Prevista Dry frame element 2 from 14...
-
Page 3: Table Of Contents
Table of contents Table of contents About these instructions for use Target groups Labelling of notes About this translated version Product information Intended use 2.1.1 Areas of use Product description 2.2.1 Overview Handling Assembly information 3.1.1 Installation dimensions Assembly 3.2.1 Mounting the element 3.2.2 Mounting the fitting holder... -
Page 4: About These Instructions For Use
This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use. -
Page 5: About This Translated Version
About these instructions for use About this translated version This instruction for use contains important information about the choice of product or system, assembly and commissioning as well as intended use and, if required, maintenance measures. The information about the products, their properties and application technology are based on the current standards in Europe (e.g. -
Page 6: Product Information
Product information 2 Product information Intended use 2.1.1 Areas of use The Prevista Dry frame element is suitable for Prevista Dry Plus fitting holders and modules. Product description 2.2.1 Overview Fig. 1: Component overview Prevista Dry frame element Screws for fixing quick-release clamp slot nuts Prevista Dry frame element... -
Page 7: Handling
Handling 3 Handling Assembly information 3.1.1 Installation dimensions Prevista Dry frame element 7 from 14... -
Page 8: Assembly
Handling Assembly 3.2.1 Mounting the element Mounting to a masonry wall Determine and mark the fixing points. X2: 460 mm Drill the holes. Insert the dowels. Determine and mark the fixing points on the floor. X3: 375 mm Drill the holes. Insert the dowels. - Page 9 Handling Adjust the construction height of the element in accordance with the on-site marking of the upper edge of the finished floor. X: 1000 mm Tighten the feet of the element using a fork spanner. ð The element is attached to the wall. Mounting in Prevista Dry Plus Mount the Prevista Dry Plus pre-wall construction pursuant to the instructions for use of the Prevista Dry Plus system.
- Page 10 Handling Set the height of the element by means of the feet. Fix the element with the Prevista Dry Plus Steptec rail connectors. ð The element is fixed in the Prevista Dry Plus pre-wall construc‐ tion. Prevista Dry frame element 10 from 14...
- Page 11 Handling Mounting in metal support profile Position the element on the floor rail. If necessary, adjust the foot depth from 50 mm (pre-mounted) to 75 Pull the foot out and turn by 90°. Screw the feet together with the support profile. Adjust the construction height of the element in accordance with the on-site marking of the upper edge of the finished floor.
-
Page 12: Mounting The Fitting Holder
Handling If applicable, connect further elements to the element via the sup‐ port profile. 3.2.2 Mounting the fitting holder Open the quick-release lever. Turn the lever 90° anti-clockwise. Prevista Dry frame element 12 from 14... - Page 13 Handling Insert the quick release through the fitting holder and into the ele‐ ment. Turn the quick-release lever 90° anti-clockwise. Close the quick-release lever. Repeat these steps on the other side. ð The fitting holder is fastened in the element. Prevista Dry frame element 13 from 14...
-
Page 14: Disposal
Handling Disposal Separate the product and packaging materials (e. g. paper, metal, plastic or non-ferrous metals) and dispose of in accordance with valid national legal requirements. Prevista Dry frame element 14 from 14...
