3.0 Specifications

Model number ......................................................................................................................................... JCDC-1.5
Stock number ........................................................................................................................................... 717515M
Motor and electricals:
Motor type ........................................................................ .totally enclosed fan cooled, induction, capacitor start
Horsepower ............................................................................................................................. 1-1/2 HP (1.1kW)
Phase .......................................................................................................................................................... single
Voltage ......................................................................................................................................................... 230V
Cycle ............................................................................................................................................................ 50Hz
Listed FLA (full load amps) ............................................................................................................................. 8 A
Start capacitor .......................................................................................................................... 300MFD 125VAC
Run capacitor ..................................................................................................................................... 30µF 250V
On/off switch ................................................................................................................... KJD-12 Magnet Switch
Motor speed ........................................................................................................................................ 2850 RPM
Power cord ....................................................................................................................... VDE H05VV-F 1.0mm
Power plug ..................................................................................................... VDE CE Plug, 16A/250A installed
Recommended circuit and fuse/breaker size
Sound emission (at 9.84 ft./3m)
Performance:
Inlet diameter ................................................................................................................................ 6 in. (152 mm)
Inlet adaptors, number of ................................................................................................................................... 2
Inlet adaptors, diameter of ............................................................................................................. 4in. (100 mm)
Filter efficiency ........................................................................................................................... 99% at 2 micron
Air Flow with filters installed .................................................................. ......................... 899 CFM (1,527 m³/hr)
Air Velocity ............................................................................................ ........................... 4,567 FPM (23.2 m/s)
Static pressure loss (WC) ..................................................................... ..................... 2.36 in-H
Maximum static pressure loss (WC) ..................................................... ................... 5.43 in-H
Impeller:
Impeller diameter ........................................................................................................................ 13 in. (330 mm)
Impeller type .......................................................................................................................................... radial fin
Impeller material .......................................................................................................................................... steel
Canister filter:
Filter type ........................................................................................................ cartridge and spunbond polyester
Canister filter diameter ........................................................................................................ 14-9/16 in. (370 mm)
Canister filter length .............................................................................................................. 15-3/4 in. (400 mm)
Filter surface area .................................................................................................................... 21.53 sq. ft. (2m
Filter efficiency ............................................................................................................. 99% of 2 micron particles
Cleaning system ............................................................................................................ manual scraper rotation
Collection drum:
Capacity .................................................................................................................................................... 20 gal.
Diameter ............................................................................................................................. 16-9/16 in. (420 mm)
Height ............................................................................................................................... 19-11/16 in. (500 mm)
Material ........................................................................................................................................................ steel
1
Subject to local/national electrical codes. Recommendation based upon dedicated circuit.
2
The specified values are emission levels and are not necessarily to be seen as safe operating levels. As workplace
conditions vary, this information is intended to allow the user to make a better estimation of the hazards and risks
involved only.
1
.............................................................................................. 16A
2
................................................................................................................ 75 dB
7
2
O (60 mm-H O)
2 2
O (138 mm-H O)
2 2
2
)
