Hardware & Tools List - Trojan POWER RACK User Manual

INSTRUCTIONS FOR ASSEMBLY
• Before you start to assemble, please check the hardware packaging to make sure all parts are included.
• Basic tools, such as spanners will be provided for assembly.
#13
(8 PCS)
#17
(46 PCS)
No. Description
13 Carriage Bolt M10 x 75
14 Hex Head Cap Screw M10 × 75
15 Hex Head Cap Screw M10 × 80
16 Hex Head Cap Screw M10 × 20
17 Flat Washer Ø10.4 × Ø20 × 2.0T
18 Flat Washer Ø10.2 × Ø35 × 2.5T
19 Nylon Nut M10
27 Wrench S17
HARDWARE & TOOLS LIST
#14
(4 PCS)
#18
(6 PCS)
6
#15
(16 PCS)
#19
(28 PCS)
Qty
8
4
16
4
46
6
28
2
#16
(4 PCS)
#27
(2 PCS)
PRACK
