Trojan POWER RACK User Manual page 7

1L
4
3
5
7L
10L
9R
No. Description
1L Left Stabiliser
1R Right Stabiliser
2 Support Frame
3 Support Beam
4 Upper Horizontal Tube
5 Multi-Purpose Connection 'U'
6 Lower Horizontal Tube
HARDWARE & TOOLS LIST
8
7R
10R
Qty
1
1
2
2
1
2
1
1R
6
9L
PARTS DIAGRAM
No. Description
7L Left Pull Up Bar
7R Right Pull Up Bar
8 Dumbbell Bar
9L Left Long Safety Catch
9R Right Long Safety Catch
10L Left Short Safety Catch
10R Right Short Safety Catch
7
2
Qty
1
1
2
1
1
1
1
PRACK
