Tektronix WVR5200 Technical Reference page 20

Instrument Connectors
Headphone Jack
Table 9: Headphone jack specifications
Connector
USB Connector
Table 10: USB connector specifications
Connector
10
Use the headphone jack, located on the front panel, to listen to the audio associated
with the selected video input signal. The following table describes the signal
characteristics of the headphone jack.
Characteristic
Output Type
Use the USB connector, located on the front panel, to save and restore instrument
presets and captured data using a USB memory drive. The following table
describes the signal characteristics of the USB connector.
Characteristic
Type
Speed
Description
Standard 1/4-inch stereo phone jack,
capable of driving a 6.25 dBu sine wave into
32 Ω or 16 Ω
Description
Host
Complies with USB 1.1 and 2.0 Full Speed
Specification (12 Mb/s)
WVR5200 System Integrator
