Physical, Environmental, And Power Specifications - Tektronix WVR5200 Technical Reference

Physical, Environmental, and Power Specifications
Table 1: Physical specifications
Characteristic
Dimensions Height
Width
Depth (front to back including handles and BNCs)
Weight Net
Shipping
Required Bare Instrument (no optional sleeves)
Clearances
Rack
Table 2: Power specifications
Characteristic
Input Voltage
Power
Input Power Frequency
Power Consumption, typical
Table 3: Environmental specifications
Characteristic
Temperature
Operating
Nonoperating
Humidity Operating
Nonoperating
WVR5200 System Integrator
The physical, environmental, and power specifications apply to all instrument
models. Use this information to ensure proper ventilation and clearance when
installing an instrument into a rack.
NOTE.
More information about the power connector is available in this document.
(See page 5, Power Connector.) You can also read about the power-on and
power-off procedures. (See page 14.)
Description
1.71 in (43.4 millimeters)
8.12 inches (206.3 millimeters)
4.75 inches (120.7 millimeters)
1.8 pounds (0.82 kilograms)
12 pounds (5.4 kilograms), approximate, excluding options
and accessories
Do not block more than half the vent holes on the sides.
Use only the VTSRACK-S2, VTSRACK-L1, or VTSRACK-L2
rackmount adapters for this instrument. The rack intake air to
the side vents must not exceed 40 °C.
Description
100 to 240 VAC, continuous
50 or 60 Hz
50 to 110 VA at 110 or 240 VAC
Description
0 °C to +40 °C
-20 °C to +60 °C
20% to 80% RH (relative humidity) at up to +40 °C,
noncondensing
5% to 90% RH (relative humidity) at up to +60 °C,
noncondensing
1
