Instrument Connectors
Instrument Connectors
4
The instrument has connectors on the front and rear panels. The following pages
describe the connector types, pin numbering, and associated signal requirements.
NOTE.
More illustrations and photographs of these instruments are available in
JPEG format on the Tektronix Web site (www.tektronix.com) and on the Product
Documentation CD that was shipped with your instrument.
Figure 2: Rear panel
WVR5200 System Integrator
