  • Page 2 Please note in the space provided above the relative service information of the model and the retailer from whom you purchased your Pin Lite LED : this information will assist us in providing spare parts, repairs or in answering any technical enquiries with the utmost speed and accuracy.
  • Page 3 English Index 1. Packaging and transportation Pag. 4 1.1. Packaging “ 1.2. Transportation “ 2. General information Pag. 4 2.1. Important safety information “ 2.2. Warranty conditions “ 2.3. Certification “ 3. Product specifications Pag. 5 3.1. Technical characteristics “ 3.2.
  • Page 4 2. For mains connection, adhere strictly to the guidelines outlined in this manual. 3. The level of technology inherent in the Pin Lite LED requires the use of specialised personnel for all service applications; refer all work to your authorised Coemar service centre.

  • Page 5: Product Specifications

    140.9mm 6.65” 5.55” 243.8mm 9.6” 3.3. Projector components The principal components of the Pin Lite LED are shown in the diagram below. Descrizione dei componenti 1. IP20 rear panel 2. IP65 rear panel 3. Projector body 4. Dip-switch panel 5. Led control PCB 6.

  • Page 6: Mechanical Installation

    Pin Lite LED may be floor mounted or hung from an appropriate structure in any position. Permanent installation Use the hole “A” (Ø13) on the yoke of the Pin Lite LED for robust, permanent installation. Mobile installations If hanging the fixture from a lighting truss or similar, we recommend the use of appropriate clamps “B”, affixed to the yoke in the hole “A”...

  • Page 7: Safety Chain

    4.2. Safety chain When hanging the Pin Lite LED we recommend the use of a safety chain “C” affixed to the yoke and to the suspension device. The safety chain should be either a metal wire rope or a metal chain, both suitably rated for the purpose.

  • Page 8: Opening And Closing Up The Projector

    4.5. Adjusting the beam angle Several optional optical groups are available for Pin Lite LED. They are used to vary the beam dimension and make it suitable for dif- ferent lighting applications and specifically: a group of lenses for a larger projection angle, a flood reflector and several filters that can be fitted either internally or externally to the unit The standard optical group, fitted on Pin Lite LED, is composed by a group of lenses that gives 12°...
  • Page 9 To vary the wideness of the beam without opening the unit, it’ s possible to install an external filter holder “S” (code CO9188/1), as shown on following drawing. The following table details the range of beam angle and diffusion filters available for the Pin Lite LED. Optical group...

  • Page 10: Operating Voltage And Frequency

    • Prior to connecting the device to mains power, ensure that the mains characteristics are within the recommended range for use with the Pin Lite LED. • A good earth connection is essential for the correcdt operation of the Pin Lite LED. Never install the unit unless the yellow/gree earth cable is securely connected.

  • Page 11: Connecting Dmx Signal

    Control signal is digital and is transmitted via two pair screened cable, as recommended in international standards for the transmission of DMX512. Connection is serial, utilising the XLR3 sockets located on the rear panel of the Pin Lite LED. Signal connection via the XLR3 connectors Connection is to international standards.

  • Page 12: Dmx Addressing

    IMPORTANT NOTE: the following points are valid for all the instructions which follow. 1. Setting a dip-switch to the ON position activates its function 2. The DMX address may be altered without the need to turn the Pin Lite LED off. The following are examples only for setting DMX addresses.

  • Page 13: Test Function

    English 7. Test function With the dip-switch set to the ON position, Pin Lite LED will test each individual channel without the need for a DMX controller to be connected. For example: set the dip-switch to ON on the Pin Lite LED.

  • Page 14: Auto Function

    9.1. MASTER/SLAVE mode In MASTER/SLAVE mode, it is possible to control, via a projector set as MASTER, a series of Pin Lite LED units set to act as SLAVE fixtures. The table below displays the settings required for fixtures to be connected in this manner.

  • Page 15: Standalone Mode

    Pin Lite LED set as STAND ALONE running program 1 To configure the Pin Lite LED as STAND ALONE simply set dip-switch Auto to the ON position and select the program you wish to run and the hold and crossfade times to fol-...
  • Page 16 10.1. Setting up functionality via DR1 (FUNC) Using the inbuilt functionality of the Pin Lite LED via the DR1, it is possible to alter the function settings of the fixture. The following diagram illustrates the menu navigation system of the DR1 in FUNC.
  • Page 17 10.2. Function modes using DR1 (MODE) Using the inbuilt functionality of the Pin Lite LED via the DR1, it is possible to alter the function mode of the fixture. The following dia- gram illustrates the menu navigation system of the DR1 in MODE.
  • Page 18 This procedure should only be undertaken by qualified and experienced technical personnel.. The display panel of the DR1+ allows for the electronic alignment of the colors. This procedure is performed by Coemar at the factory. It may be useful to perform this procedure in the case of internal components being replaced (electronic parts).
  • Page 19 To end the electronic calibration procedure and to record it UPLOAD function Using this function it is possible to upload software to the Pin Lite LED using a DR1+. For further information, consult the DR1 manual. DOWNLOAD function Using this function it is possible to download software from the Pin Lite LED to a DR1+.

  • Page 20: Thermal Protection

    DMX OK connected 12. Thermal protection A thermal sensor in the body of the Pin Lite LED protects the fixture against overheating. The sensor operates by removing power to the leds should the operating temperature exceed the factory preset. 13. Maintenance Whilst every possible precaution has been taken to ensure the trouble-free operation of your Pin Lite LED, the following periodic main- tenance is highly recommended.

  • Page 21: Frequently Asked Questions

    • Pin Lite LED may be incorrectly addressed. Check the DMX addres- sing. The Pin Lite LED is set to auto but is not running any pro- In addtion to setting the AUTO dip-switch to on, it is necessary to also grams select a program number (see section 9.
  • Page 22 Coemar s.p.a. via Inghilterra 2/A - 46042 Castel Goffredo (Mantova) Italy ph. +39 0376/77521 - fax +39 0376/780657 info@coemar.com Coemar si riserva il diritto di apportare modifiche senza preavviso. Coemar reserves the right to effect modifications without notification...
