Page 3: Package Contents
-n°7 wrench This kits contains all the material needed to mount a PC lens on Infinity Wash XL instead of default Fresnel lens and to change beam characteristics. We recommend to read and follow carefully these instructions in order to complete the operation without effort . - Page 4 -Remove all the weights from inside and outside the main frame. LE1507/1L 260.318ASM -Put the lens in the new mounting ring’s seat and fix in place. Ther is only one way to mount the ring: the following images explain how to proceed.
- Page 5 -Check that the lens is firmely fixed, check for loosing parts , then mount the covers on the fixture. WARNING ! Ensure that the flat back side of the lens is perfectly parallel to the front side of the fixture. Notice: Coemar declines any claim for damages to fixtures and kits caused by wrong assembly or inadequacy.
- Page 6 Coemar s.p.a. Via Inghilterra, 2/a Castel Goffredo (Mantova) Italy Ph. +39 0376/77521 – Fax 0376/780657 www.coemar.com - info@coemar.com Coemar reserves the right to effect modifications without notifications...
