Summary of Contents for Coemar Pixel
- Page 1 Pixel Provisional instruction manual Version 1.0...
- Page 2 Please note in the space provided above the relative service information of the model and the retailer from whom you purchased your Pixel: this information will assist us in providing spare parts, repairs or in answering any technical enquiries with the utmost speed and accuracy.
-
Page 3: Table Of Contents
Italiano Indice 1. Packaging and transportation .....................Pag. 4 1.1 Packaging ............................Pag. 4 1.2 Transportation ..........................Pag. 4 2. General information ........................Pag. 4 2.1 Safety informations ........................Pag. 4 2.2 Warranty conditions ........................ Pag. 5 2.3 EC norms ............................. Pag. 5 3. -
Page 4: Packaging And Transportation
Packing list Make sure the packaging contains: 1 Pixel 1 Instruction manual Transportation The Pixel must be transported exclusively in its original packaging or in an appropriate flight case. . General information Important Safety information Fire prevention: 1. Never locate the fixture on any flammable surface. -
Page 5: Warranty Conditions
Italiano 1. The level of technology of Pixel requires the use of specialised personnel for all service applications; refer all work to your authorised Coemar service centre. 2. A good earth connection is essential for the proper functioning of the projector. -
Page 6: Product Specifications
Italiano . Product specifications Technical charateristics Alimentazione 48Vac Corrente massima 0.25 A @ 48Vac Potenza della sorgente luminosa Temperatura colore RGBW Peso 1 kg - 2.20 lbs Massima temperatura ambientale 35°C Grado di protezione IP65 Dimensions 89 mm 3,50 in... -
Page 7: Unit's Main Components
Italiano Unit’s main components Components description Cable gland Spring Docking accessory Yoke Fixing screw Adjustment yoke screw Cable hole Fixing washer *without yoke *with yoke... -
Page 8: Installation
Installation Mechanical installation Pixel may be hung from an appropriate structure in any position or on tripode. If hanging the fixture from a lighting truss or similar, we recommend the use of an appropriate yoke “A”, as shown in the following diagram. -
Page 9: Fastening In Series
Italiano Fastening in series Pixel can be connected in series with other Pixel up to a maximum of 32. To do so follow the instruction given below. • Position two Pixel one beside the other; • Slide the two Pixel (in the direction shown below) until the fixing washer “A” will not be entered in the hole “B”;... -
Page 10: Powering Up
Operating voltage and frequency The unit may operates with a voltages of 48 Vdc. It is not needed to effect any setup procedures: Pixel will automatically adjust its operation to suit any frequency or voltage within this range. Connection to mains power... -
Page 11: Control Signal Connections
International standards for the transmission of DMX 512 data. The connection must be serial, by connecting the single output cable from the Pixel in the RegoPixel’s entrance “A”, which will be connected to a console. The connectors provided with the Pixel are IP rating, ensuring protection against dust and water. -
Page 12: Turning On The Projector
DMX addressing Every Pixel uses 4 address channels for its complete functioning and it is controlled with a DMX512 signal. The assignment of the DMX channel is automatically done by the Pixel at the moment it will be connected to RegoPixel;... -
Page 13: Accessories And Spare Parts
Italiano Accessories and spare parts All Pixel’s components are available as spare parts from your Coemar service centers. Specifying in detail the projector model and the replacement part requested, will help the service center to serve you in the best way. -
Page 14: Regopixel
RDM, allowing all the possible action of setting DMX channels. RegoPixel is seen as a transparent object, it means that the signal goes directly to the single Pixel. RegoPixel can be used as a DMX recorder too, thanks to the SD card dadicated slot you can memorize one or more shows. -
Page 15: Input Description
10.2 Input description The device has 4 digital input (IN1 - IN4) whose functionality is described below. • Input IN1-IN2: Run prerecordered Shows on SD card, in according to table below. 0 = input false 1 = input true: Function Stop Play show n.1 Play show n.2... -
Page 16: Recording A Show
10.3 Recording a show To record a show in the SD card, follow the instruction below: • Select the number of the show that you wish to record (1-3) acting on IN1 and IN2; • If a show is present (so it is started in Play), stop it activating IN4 briefly; • Give the signal to record on DMX In or ArtNet;... - Page 17 LED signaling table: LED 6 LED 3 Condition GREEN DMX In Mode, no signal in entrance DMX IN mode, DMX Engaged, trasmission ArtNet + RegoPixel flash DMX IN mode, ArtNet In available, trasmission RegoPixel flash DMX Out Mode, no signal in entrance DMX Out, ArtNet IN, DMX Out + RegoPixel flash Universe filter on , 25% duty on Green...
-
Page 18: Rdm Setting Screen
10.5 RDM setting screen Slave discovery Slave identification Sub Net device DMX address... -
Page 19: Maintenance
Pixel fimware updated through protocol (ANSI E1.20). Contact Coemar assistance to receive the software and the device updater. 11.2 Periodic cleaning Lenses Even a fine layer of dust can reduce the luminous output and alter the compactness of the beam. Regularly clean all filters and lenses using a soft cotton cloth, dampened with a specialist lens cleaning solution. -
Page 20: And Answers
. F.A.Q. and answers The following list shows common issues that may be simply solved. If issues persist, the unit must be repaired by qualified personnel or just contact your Coemar service near you. Question Possible solution Projector not powered on:... - Page 21 User notes ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 22 Information on disposal of the equipment The equipment at the end of its useful life must be disposed of at an appropriate recycling center for waste electrical and electronic equipment. The treatment and disposal of environmentally friendly, helps prevent potential negative environmental and health and promote the reuse and / or recycling of materials making up the equipment.
- Page 23 Coemar Lighting s.r.l. Via Carpenedolo 90 46043 Castiglione delle Stiviere, Mantova, Italia tel. +39 0376/1514412 - fax +39 0376/1514380 info@coemar.com Coemar reserves the right to effect modifications without notification...
