Important: Read all the operating and maintenance instructions in this manual before assembly (EC Machinery Directive 98/37) USER AND MAINTENANCE MANUAL Assembly instructions Spare Parts Rev. 0 04.10...
Page 3
INDEX USER AND MAINTENANCE MANUAL ..........................1 Machine Directive and harmonized standards ..........................2 CE DECLARATION OF CONFORMITY ....................................2 INTRODUCTION............................................ 4 ..................4 BOUT HAY RAKES ..................4 BOUT THE MANUAL ....................4 ARRANTY ............5 CERTIFICATION AND IDENTIFICATION ........
Page 4
Italian. A2 About the manual The ENOROSSI firm (the “Manufacturer”) designed and created the device in accordance with the relative safety standards to ensure the safety of Symbols used in this manual: personnel and the entire operating system.
Page 5
The Customer, upon receipt of the shipment, must check the entire ENOAGRICOLA ROSSI s.r.l. structure for any signs of damage and that the components are intact and CALZOLARO DI UMBERTIDE - PERUGIA - none are missing. Any claims must be made to the Manufacturer in writing within 8 (eight) days of receiving the rake.
Page 6
A5 Main components and technical specifications 1. Mechanical end stop (to adjust the rake wheel to the ground) 2. Shock absorbing spring 3. Rear wheel 4. Rake wheel 5. Frame 6. Hydraulic quick couplings 7. Supporting foot 8. Tractor coupling device 9.
Page 7
SAFETY WARNING Loading and unloading must always be carried out with all due B1 General regulations precautions as they can entail a certain element of risk. This manual describes the safety regulations to be followed when using the rake. As most work-related accidents occur due to non-compliance with the most basic of safety regulations, it is obligatory to read this Always take the following precautions: manual before carrying out any work with the rake and to follow all the...
Page 8
IMPORTANT You must remember that the transportation configuration entails closing the side arms and fitting the equipment with the following The tractor must also, by law, be fitted with a protective roll-bar or safety devices: ROPS or FOPS cabin. It is strictly forbidden to install the rake device on a tractor without the required protection.
Page 9
B3 Operator's responsibilities and safety Use: the rake must only be put to the use for which it was intended: to Safety is of primary importance to personnel operating the rake device and rake up cut forage. Any other use is therefore improper and forbidden. therefore each operator is directly responsible for controlling the rake's The rake's technical characteristics must also not be altered in any way to operation, maintenance, repairs and/or use of spare parts or consumable...
Page 10
IMPORTANT Warning labels and pictograms must be replaced if they become faded and risk becoming illegible. In this case, the operator must not use the rake until any faded labels are replaced with new ones. It is also strictly forbidden to remove the pictograms and labels from the equipment.
INSTALLATION When the tractor is near the rake's attachment (type 1 or 2 – see picture), the operator turns the lever on the C1 Rake assembly foot support (2) to lift or lower the rake's attachment As mentioned above, the equipment is fully dismantled for delivery to the and insert it in the tractor's attachment.
Page 12
are made (quick couplings, as illustrated) to their corresponding attachments on the tractor's auxiliary circuits. C4 Removal To remove the rake from the tractor, follow the above instructions in reverse order. The hydraulic connections have to be removed before the actual rake.
• OPERATION and USE Firstly, the operator must remove any safety devices that need to be removed for transportation, i.e. The jacks' end stop devices (B) and the arms' tie rods (A): ∆1 ∆1 ∆1 ∆1 Preliminary information Suitable and optimal use of the rake not only helps avoid accidents but is also the only way to ensure high yield and make use of the rake's full potential and performance.
Page 14
Once the operator has turned the tractor, he can apply the command to re- open the side arms and then lower the rake wheels to continue the work. CONTROL A To move the forage in the central swath, one or more additional rake wheels need to be installed at the centre of the frame.
Page 15
Kicker wheel Figure 1 Figure 2 Prior to work breaks (even short ones) the operator must always: Kicker wheel adjustment • Switch off the tractor’s engine • After installing the kicker wheel (assembly instructions on page 40), the Apply the parking brake •...
MAINTENANCE serious infections. You must therefore use safety glasses with side protection and a piece of cardboard or wood to look for leaks. E2 Scheduled maintenance E1 Maintenance instructions Scheduled maintenance is purely informative and depends on normal The Manufacturer has drawn up a rake maintenance schedule based on operating conditions.
Page 17
E3 Lubrication PUNTI DA The jacks move even To top up the greasers, remove their protection caps (if Jack seals are worn Replace seals LUBRIFICARE when the command present), remove all traces of dust and then use the isn’t given pump to inject the grease.
Page 18
Machine assembly instructions Assembly 1 For Easy-Rake SUPER STAR 16-18-20 IM1 ERS 16-18-20 A) Connect the cross drawbar Pos. 1 to the rear pullbar Pos. Fix the 920x230x15 plate Pos. 3 using the 10 T.E. M20x200 screws Pos. 4 and the M20 self-locking nuts Pos.
Page 19
Assembly 2 For Easy-Rake SUPER STAR 16-18-20 A) Connect pullbar Pos. 10 with the rear IM2 ERS 16-18-20 pullbar Pos. using T.E. M20x55 screws Pos. 9 self- locking nuts pos. 8. B) Connect front pullbar Pos. 11 with the pullbar Pos. 10. Fix using T.E.
Page 20
Assembly 3 For Easy-Rake SUPER STAR 16-18-20 A) Assemble the joint for the right and left frame Pos. 14 IM3 ERS16-18-20 into the right and left leg support Pos. 12, by placing the antisiezure fifth wheel AS 5070 Pos. 21 under the joint bush and on the leg support bracket.
Page 21
Assembly 4 For Easy-Rake SUPER STAR 16-18-20 26 24 23 A) Use a lifting truck to raise the already assembled cross IM4 ERS16-18-20 drawbar, already assembled with the rear pullbar, the central drawbar and the front drawbar. The front part of the pullbar must stay on the ground making sure it is all very stable.
Page 22
Assembly 5 For Easy-Rake SUPER STAR 16-18-20 33 34 A) Assemble the two rear frames, right and left Pos. 40, by fixing IM5 ERS16-18-20 them to the two leg supports with the pin joints Ø50x225 Pos. 33 (see detail A). Fix pin Ø50 Pos. 33, with screw T.E.
Page 23
Assembly 6 For Easy-Rake SUPER STAR 16 A) Assemble the front right frame Pos. 63 with frame Pos. 43. Fix with T.E. IM6 ERS16 M16x45 screws Pos. 62 and M16 self- locking nuts Pos. 60. B) Assemble the front wheel support Pos. 66.
Page 24
Assembly 7 For Easy-Rake SUPER STAR 18-20 A) Assemble the right mobile frame Pos. IM7 ERS18-20 49. Fix using pin Ø40x296 Pos. 50 placing nylon washers Ø41x60x2.5 Pos. 48. Fix the pin Pos. 50 with washers Ø25x55x5 Pos. 45 and M24 self-locking nut Pos.
Page 25
Assembly 8 For Easy-Rake SUPER STAR 18 A) Assemble the front pivoting support Pos. 73 to the frame Pos. 43. Fix the two frames with T.E. M16x45 screws IM8 ERS 18 Pos. 70 and M16 self-locking nuts Pos. 69. B) Assemble the front wheel support Pos.
Page 26
Assembly 9 For Easy-Rake SUPER STAR 20 A) Assemble the front jointed tie-rod IM9 ERS 20 Pos. 57 to the frame Pos. 43. Fix using T.E. M16x45 screws Pos. 54 and M16 self-locking nuts Pos. 51. B) Assemble the frame extension Pos. 55.
Page 27
Assembly 9 bis For Easy-Rake SUPER STAR 16-18-20 A) Insert the fifth-wheel AS 50-70 Pos. 84 in the pin Ø50 Pos. 86 of the pivoting wheel. B) Assemble the two wheels with pivoting IM9bis ER16-18-20 fork Pos. 86 in the support Pos. 56 C) Assemble the brake disc pos.
Page 28
Assembly 10 For Easy-Rake SUPER STAR 16-18-20 IM10 ERS 16-18-20 Rev. 0 04.10...
Page 29
Assembly 11 For Easy-Rake SUPER STAR 16-18-20 A) Assemble the jack support Pos. 89 and fix with T.E. M12x25 Pos. 90 screws. Assemble the rubber foot Pos. 91 and clamp with M8 nut M8 Pos. 88 B) Fix the hydraulic cylinder Pos. 92 and fix with pin Ø30x100 Pos.
Page 30
Assembly 12 For Easy-Rake SUPER STAR 16-18-20 A) Assemble the rod Pos. 95 and fix it in the elbow side with pin Ø30x175 Pos. 98 and circlips Ø10x60 Pos. 99. Fix the rod Pos. 95 in the slide side with pin Ø30x135 Pos. 97 and snap pins Ø8 Pos.
Page 31
Assembly 13 For Easy-Rake SUPER STAR 16-18-20 Star movement bars assembly: IM13 ER16-18-20 A) Assemble the hydraulic cylinder Pos. 108 and fix it in the frame with the pin Ø25x62 Pos. 114. Fix pin Ø25x62 103 104 Pos. 114 with spring pins Ø5x100 Pos.
Page 32
Assembly 13 bis For Easy-Rake SUPER STAR 16-18-20 IM13bis ER16-18-20 Rev. 0 04.10...
Page 33
Assembly 14 For Easy-Rake SUPER STAR 16 A) Connect the bush Ø34x80 Pos. 115, Pos. 110. IM14 ER16 Assemble the star movement bar Ø26x1370 Pos. 116 (for mod. 16). Fix using T.E. M8x50 screws Pos. 114 and screw M8 nuts Pos. 118. Rev.
Page 34
Assembly 15 For Easy-Rake SUPER STAR 18-20 A) Assemble the bar Ø26x515 Pos. 122 and connect it to the rear bar Pos. 110 IM15 ER18-20 using the bush Ø34x80 Pos. 121. B) Connect the two bars Ø26x515 Pos. 121 122 122 with the joint bracket Pos.
Page 35
Assembly 16 For Easy-Rake SUPER STAR 16-18-20 A) Assemble right and left arms Pos. 126 Insert the pin Ø30 the spacer Ø30.5x44x21 Pos.128. Fix the first arm using the snap pin Ø5 Pos. 130. Fix the other arms using the circlip Ø6x50. IM16 ERS 16-18-20 Rev.
Page 36
Assembly 17 For Easy-Rake SUPER STAR 16-18-20 A) Assemble the springs Ø50x200 Pos. 134, by inserting the spring hook into the arm bracket (FIGURE C). The other spring hook must be inserted into the fifth ring in the chain counting from the clamp Pos. 136, keeping the spring hook facedown (see FIGURE C of the assembled spring).
Page 37
144 145 146 Assembly 18 IM18 ERS 16-18-20 For Easy-Rake SUPER STAR 16-18-20 Assembly of hydraulic hoses: A) Assemble the two rear hydraulic hoses Lg. Detail B 140 153 140 154 2500 Pos. 142 and connect them to the two hydraulic cylinders Pos.
Page 38
Assembly 19 For Easy-Rake SUPER STAR 16-18-20 A) Assemble the right and left star wheels Pos. 159. Fix them to the arm hub with T.E. M10x25 screws Pos. 160 and M10 self-locking nuts Pos. 158. IM 19 ERS 19-18-20 Rev. 0 04.10...
Page 39
Assembly 20 For Easy-Rake SUPER STAR 16-18-20 Assembly of the transport bars: IM20ERS 16-18-20 A) The transport bars Pos. 161 must be hitched tot he two side frames and the central pullbar using the relative pins Ø25x100 Pos. 162. Rev. 0 04.10...
Page 40
Assembly 21 For Easy-Rake SUPER STAR 16-18-20 Assembly of the central stars (optional) A) Connect the fixed frame Pos. 190, to the front pullbar Pos. 11, fix using the plate 174x240x10 Pos. 164, T.E. M16x160 screws Pos. 163 and M16 self-locking nuts Pos. 165. The best position of the fixed frame Pos.
Page 41
Assembly 22 For Easy-Rake SUPER STAR 16-18-20 Assembly of the hydraulic circuit for central rods (OPTIONAL). A) Assemble the ½ GAS male 3-way fitting Pos. 190, in the 5/16 hydraulic hose LG: 550 mm. Pos. 192. B) Insert the hose, Pos. 192, between the Ø5/16 LG.
Page 42
Assembly 23 For Easy-Rake SUPER STAR 16-18-20 Assembly transport lights (OPTIONAL) IM23 ERS 16-18-20 A) Assemble the two support brackets Pos. 198 in the towing bar in points A. Fix the two brackets using T.E. M8x10 screws Pos. 199. Fix the lights kit using T.E.
Page 43
Assembly 24 For Easy-Rake SUPER STAR 16-18-20 IM24 ERS 16-18-20 Rev. 0 04.10...
Page 58
Table 6 cod. 19010546 - EASY RAKE SUPER STAR 16-18-20 Rev. 0 04.10...
Page 59
Table 6 cod. 19010546 - EASY RAKE SUPER STAR 16-18-20 POS. CODE DESCRIPTION DESCRIZIONE 18032666 CONNECTING BAR Biella 12060868 PIN Ø30 L.138 Perno per slitta Ø30 L.138 12880614 SPLIT PIN Spina a scatto 2050109 SKID Slitta 3080105 SPRING PIN 8X50 Spina elastica 8x50 3120111 RING Ø52...
Page 60
Table 7cod. 19010547 - EASY RAKE SUPER STAR 16-18-20 Rev. 0 04.10...
Page 61
Table 7 cod. 19010547 - EASY RAKE SUPER STAR 16-18-20 POS. CODE DESCRIPTION DESCRIZIONE 12760222 HYDRAULIC HOSE L. 5.540 E.R. SS 16 Tubo idraulico L. 5.540 per E.R. SS 16 12760224 HYDRAULIC HOSE L. 6.410 E.R. SS 18 Tubo idraulico L. 6.410 per E.R. SS 18 12760215 HYDRAULIC HOSE L.
Page 62
Table 8 cod. 19010548 - EASY RAKE SUPER STAR 16-18-20 Rev. 0 04.10...
Page 63
Table 8 cod. 19010548 - EASY RAKE SUPER STAR 16-18-20 POS. CODE DESCRIPTION DESCRIZIONE 11010508 ARM SPRING Molla richiamo stella 3011206 SCREW T.E. M10X30 Vite T.E. M10x30 3030169 WASHER M10X30 Rondella M10X30 3020201 SELF LOCKING NUT M10 Dado autoblocc. M10 18030415 VICON TOOTH Dente stellare VICON...
Page 64
Table 9 cod. 19010549 - EASY RAKE SUPER STAR 16-18-20 Rev. 0 04.10...
