Advantech B+B SmartWorx SE400 Series User Manual page 24

The following view applies to SE416, SEC410, SEC418 series.
1
Table 12: Top View
No. Item
1 Terminal block
Bottom View
The following view applies to SE408 series.
Table 13: Bottom View
No. Item
1 Ground terminal
DC 12-48V PWR2 1A@24V PWR1
V2- V2+ V1- V1+
P-Fail
Figure 9: Top View
Description
Connect cabling for power and alarm wiring.
Figure 10: Bottom View
Description
Screw terminal used to ground chassis.
10
SE400 SERIES
1
