The following view applies to SE416, SEC410, SEC418 series.
Table 10: Rear View
No. Item
1 DIN-Rail mounting
plate
Top View
The following view applies to SE408 series.
1
Table 11: Top View
No. Item
1 Terminal block
1
Figure 7: Rear View
Description
Mounting plate used for the installation to a standard DIN rail.
DC 12-48V PWR2 1A@24V PWR1
V2- V2+ V1- V1+
P-Fail
Figure 8: Top View
Description
Connect cabling for power and alarm wiring.
