Summary of Contents for Crestron CNXHUB
-
Page 3: Table Of Contents
Crestron CNXHUB Contents Cresnet Hub/Repeater: CNXHUB Description...1 Functional Description...1 Physical Description...1 Leading Specifications...2 Preparation for Use...3 Problem Solving...3 Troubleshooting...3 Further Inquiries...4 Return and Warranty Policies...5 Merchandise Returns / Repair Service ...5 CRESTRON Limited Warranty ...5 Operations Guide - DOC. 8146... -
Page 5: Cresnet Hub/Repeater: Cnxhub
(sold separately). CNXHUB Ports All six ports (labeled A–F) are on the rear panel of the CNXHUB. Attach wiring per latest revision of either the Network Interconnection Drawing (Doc. 5411) or the Mini Network Interconnection Drawing (Doc. 5819). The Crestron or CAT 5 cables can be secured to the six supplied mini-phoenix connectors which can be plugged into the CNXHUB ports. -
Page 6: Leading Specifications
Cresnet Hub/Repeater CNXHUB Indicators Seven LED indicators are located on the front panel of the CNXHUB. The PWR (Power) LED illuminates when power is supplied to the CNXHUB. The six NET ACTIVITY (A–F) LEDs illuminate when the device on a respective segment transmits data. -
Page 7: Preparation For Use
The CNXHUB connectors support various cable types. A single Crestron cable can be used or up to two CAT 5 cables can be accommodated by the connector. If you are using Crestron cable, refer to the latest revision of the Network Interconnection Drawing (Doc. -
Page 8: Further Inquiries
Cresnet Hub/Repeater Further Inquiries If after reviewing this Operations Guide for the CNXHUB, you cannot locate specific information or have questions, please take advantage of Crestron's award winning technical support team by calling: For local support from exclusive Crestron factory-trained personnel call: Cresnet Hub/Repeater: CNXHUB In the US and Canada, call Crestron’s corporate headquarters at 1-888-... -
Page 9: Return And Warranty Policies
(3) years from the date of shipment to purchaser. Disk drives and any other moving or rotating mechanical parts are covered for a period of one (1) year. CRESTRON warrants all its other products for a period of one year from the defects mentioned above, excluding touchscreen display components which are covered for 90 days.
