Crestron CNLGE-8
LED INDICATOR
(ONE PER CHANNEL)
ILLUMINATES WHEN
RELAY CONTACTS
ARE CLOSED
CONTACT RATING:
20A UP TO 277VAC
ALL CONTACTS SPST MECHANICALLY LATCHING - SHIPPED IN CLOSED POSITION.
THIS PRODUCT USES ELECTRO-MECHANICAL RELAYS FOR SWITCHING THE LOADS.
CERTAIN ELECTRONIC BALLASTS HAVE VERY HIGH INRUSH CURRENTS WHICH MAKE
THEM INCOMPATIBLE WITH ELECTRO-MECHANICAL RELAYS. CHECK WITH BALLAST
MANUFACTURER FOR COMPATIBILITY.
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
Tel: 888.CRESTRON
Fax: 201.767.7576
Network Power Switching Modules with 8 Mechanical Relays
8
7
6
H
I D
CODE
L
4
3
CONTROL
2
NETWORK
TOP
24
ACTIVITY
Y
Z
POWER
G
BOTTOM
1
CAUTION:
LOW VOLTAGE
CONNECTION
ONLY
EXTERNAL
20A BREAKER
120 VAC OR
277 VAC
NEUTRAL
TO CRESNET
SYSTEM COMPUTER
(SEE NETWORK
INTERCONNECT
DRAWING D5411)
TO CNLPS-120/277
REQUIRED FOR PROPER
OPERATION
(1 MODULE SPACE REQ'D)
Specifications subject to change without notice.
TO
LOAD
DOC. 5574
10.03
www.crestron.com
