8 000 - 009
010 - 128
129 - 137
138 - 225

Technical Specifications

Photometrics

•
Light Source: 1x 12W CREE RGBW 4-in-1 LED
•
Coverage angle: 85°
•
LED Lifespan: 50,000 hours.

Power

•
Input Voltage: 100~240V AC, 50/60 Hz.
•
Power Consumption: 72W.
•
Connection: IEC in/out.

Control

•
Protocol: DMX512.
•
Operation modes: DMX, auto, manual, sound active, master/slave
•
DMX Channels: 8
•
Interface: 3-pin DMX in/out.
•
Display: LED Display with 4-button control.

Housing

•
Finishing: Matte Black.
•
Net Weight: 3.15kg
•
Dimensions: 168x309x314 mm.

Warranty

Please refer to your local dealer or contact Event Lighting.
www.event-lighting.com.au
4
The motor stops
Counter clockwise rotation speed
adjustment (slow to fast)
The motor stops
Clockwise rotation speed
adjustment (slow to fast)
