Hyundai Matrix 2003 Owner's Manual page 168

J070A03FC-GAT
ENGINE
ITEMS
Engine Type
Idle Speed (RPM)
A/CON OFF
A/CON ON
Spark Plug NGK
Unleaded
CHAMPION
NGK
Leaded
CHAMPION
Spark Plug Gap
Unleaded
Leaded
Valve Clearance Intake
For adjusting
(Cold engine:20 ± 5°C) Exhaust
Intake
For checking
Exhaust
Ignition Timing
Firing Order
9-2
VEHICLE SPECIFICATIONS
GASOLINE
1.6/1.8 4Cylinder in-line DOHC
800 ± 100 (1.6L), 750 ± 100 (1.8 L)
800 ± 100 (1.6L), 800 ± 100 (1.8 L)
BKR5ES-11
RC10YC4
BKR5ES
RC10YC
1.0 ~ 1.1 mm (0.039 ~ 0.043 in.)
0.7 ~ 0.8 mm (0.028 ~ 0.032 in.)
0.17 ~ 0.23 mm (0.0067 ~ 0.0091 in.) (1.8DOHC)
0.25 ~ 0.31 mm (0.0098 ~ 0.0122 in.) (1.8 DOHC)
0.12 ~ 0.28 mm (0.0047 ~ 0.011 in.) (1.8 DOHC)
0.20 ~ 0.38 mm (0.0079 ~ 0.015 in.) (1.8 DOHC)
BTDC 5° ± 5° (1.6L), BTDC 7° ± 5° (1.8L)
1 - 3 - 4 - 2
DIESEL
1.5 3Cylinder in-line SOHC
800 ± 100
800 ± 100
-
-
-
-
-
-
AUTO LASH
(1.6DOHC/Diesel)
AUTO LASH
(1.6DOHC/Diesel)
-
1 - 3 - 2
