DESCRIPTION
SERVICE MANUAL
Applies to:
Hyundai Coupe/Tiburon 1998-2001
GROUP
Restraints
Return to Main Menu(s):
DESCRIPTION
The supplement restraint system (SRS AIR BAG) is designed to supplement the seat belt to help reduce the risk or
severity of injury to the driver and passenger by activating and deploying the driver and passenger side air bag in
certain frontal collisions.
The SRS (Air Bag) consists of: a driver side air bag module located in the center of the steering wheel, which
contains the folded cushion and an inflator unit; a passenger side air bag module located in the passenger side crash
pad contains the folded cushion assembled with inflator unit; SRSCM located on the floor panel behind the T.G.S.
select lever assembly which monitors the system, and accelerometer which senses the vehicle deceleration an spring
interconnection (clock spring) located within the steering column; system wiring and wiring connector; and a knee
bolster located under the steering column.
The impact sensing function of the SRSCM is carried out by electronic accelerometer that continuously measure the
vehicle's acceleration and delivers a corresponding signal through amplifying and filtering circuitry to the
microprocessor.
Deployment of the air-bag is designed to occur in frontal or near-frontal impacts of moderate of severe force. Only
authorized service personnel should do work on or around the SRS components. Those service personnel should
read this manual carefully before doing any such work. Extreme care must be used when servicing the SRS to avoid
injury to the service personnel (by inadvertent deployment of the air bag) or the driver (by render the SRS
inoperative).
file:///C/Mes%20Sites%20Web/RD%20service%20manual%20mechanical/www.newtonnet.co.uk/coupe/service/webtech/iindex-565.html[16/09/2019 11:46:12]
SRS Air Bag System
Mechanical Manual
Electrical Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Coupe 1998 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hyundai Coupe 1998

  • Page 1 DESCRIPTION SERVICE MANUAL Applies to: Hyundai Coupe/Tiburon 1998-2001 GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual DESCRIPTION The supplement restraint system (SRS AIR BAG) is designed to supplement the seat belt to help reduce the risk or severity of injury to the driver and passenger by activating and deploying the driver and passenger side air bag in certain frontal collisions.
  • Page 2 SERVICE MANUAL Hyundai Coupe/Tiburon 1998-2001 Applies to: GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual CUSTOMER CAUTIONS Failure to carry out service operations in the correct sequence could cause the airbag system to unexpectedly deploy during servicing, possibly leading to a serious injury.
  • Page 3: Special Service Tools

    SERVICE MANUAL Hyundai Coupe/Tiburon 1998-2000 Applies to: GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual SPECIAL SERVICE TOOLS Tool Name and Description Airbag wiring harness checker (0957A- 29000) Airbag wiring harness checker Harness inspection...
  • Page 5: Electrical System

    SERVICE MANUAL Hyundai Coupe/Tiburon 1998-2001 Applies to: GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual ELECTRICAL SYSTEM The SRS airbag system has deliverate and sophisticate electrical and electronic components, therefore the airbag operating components should be handled very carefully.
  • Page 6: Warning/Caution Labels

    SERVICE MANUAL Hyundai Coupe/Tiburon 1998-2000 Applies to: GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual WARNING/CAUTION LABELS A number of caution labels relating to the SRS are found in the vehicle, as shown in the following illustration.
  • Page 7 """-: /_ - - \.: I_;;---:;...
  • Page 8 A. DAB + PAB B. DAB + PAB Airbag system is normal if "SRS" lamp, in cluster flashes approximately 6 times and then goes out after ignition key is turned on. However, if any of the following conditions occur CAUTION the system must be serviced.
  • Page 9 service manual instructions. key. To re-center rotate clockwise until tight. Then Failure to do so may damage SRS clock spring rotate in opposite direction approximately 2 9/10 and render SRS system inoperative, risking turns and align. serious driver injury. Failure to follow to instructions may render SRS system inoperative risking serious driver injury.
  • Page 10: Check Procedures

    SERVICE MANUAL Hyundai Coupe/Tiburon 1998-2000 Applies to: GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual DTC - B1346, B1347 DTC CODE DISPLAY ON HI-SCAN CONDITION Ignition switch "ON" or start release B1346 DAB resistance - High DAB module malfunction >...
  • Page 11: Check Procedure

    13 to 14 Non-continuity CHECK CLOCK SPRING Remove the clock spring connector. Connect the SRS harness checker to clock spring side connector and DAB dummy terminal. Check continuity between checker terminal 3 and 4. LIMIT B1346: Continuity B1347: Non-continuity CHECK PROCEDURE...
  • Page 12 SERVICE MANUAL Hyundai Coupe/Tiburon 1998-2000 Applies to: GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual DTC - B1348, B1349 DTC CODE DISPLAY ON SCAN TOOL CONDITION Ignition switch "ON" or start release Resistance between DAB module...
  • Page 13: Clock Spring

    CLOCK SPRING Disconnect DAB and clock spring connector and SRSCM connector. Connect SRS harness checker to the SRS harness checker to clock spring connector. Connect battery and ignition "ON" and check continuity or voltage between terminals 3, 4 to body ground respectively.
  • Page 14 SERVICE MANUAL Hyundai Coupe/Tiburon 1998-2000 Applies to: GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual DTC - B1352, B1353 DTC CODE DISPLAY ON SCAN TOOL CONDITION Ignition switch "ON" or start release B1352 PAB resistance - High kPAB module circuit resistance >...
  • Page 15 CLOCK SPRING INFLATOA [ n l In l · ---. · · ·· · · · ·· · · · ·· · · ·· ·- - -- ·· · • ..------ • • · • · • ············· ·-· 0957A-29000 SRS HARNESS CHECKER...
  • Page 16 SERVICE MANUAL Hyundai Coupe/Tiburon 1998-2000 Applies to: GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual DTC - B1354, B1355 DTC CODE DISPLAY ON SCAN TOOL CONDITION Ignition switch "ON" or start release Resistance between PAB module...
  • Page 17 INFlATOR CIRCUIT EB 0 ....••II•••.,,_I 0957A-29000 SRS HARNESS CHECKER...
  • Page 18 SERVICE MANUAL Hyundai Coupe/Tiburon 1998-2000 Applies to: GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual DTC - B1372, B1661, B1650 DTC CODE DISPLAY ON SCAN TOOL CONDITION SRSCM firing circuit DAB - Ignition switch "ON" or start release...
  • Page 19 SERVICE MANUAL Hyundai Coupe/Tiburon 1998-2000 Applies to: GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual DTC - B2500 DTC CODE DISPLAY ON SCAN TOOL CONDITION Ignition switch "ON" or start release SRS service reminder indicator circuit voltage <...
  • Page 20 LIMIT SRS SRI ON If no fault is found in wiring or connector, replace the SRSCM.
  • Page 21 SERVICE MANUAL Hyundai Coupe/Tiburon 1998-2000 Applies to: GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual DIAGNOSIS WITH SCAN TOOL CHECK PROCEDURES Connect the Scan tool DLC to the vehicle data link connector located at underneath the dash panel.
  • Page 22 SERVICE MANUAL Hyundai Coupe/Tiburon 1998-2000 Applies to: GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual TROUBLESHOOTING USING HARNESS CHECKER (0957A-29000) The SRS harness check (0957A-29000) is available for troubleshooting of airbag system. If a fault code is confirmed by using Scan tool, it is recommendable to check whether there is an abnormal condition in the connector or wiring around the Scan tool indicated components.
  • Page 23 Dummy terminal can be used to simulate the airbag system while removing the both DAB and PAB. If the Scan tool displays that the trouble is in DAB and PAB itself, it is necessary to confirm the trouble. To verify the source of trouble with Scan tool, first remove the DAB or PAB module connector as necessary and connect the dummy terminal to harness checker.
  • Page 24: Power Source

    SERVICE MANUAL Hyundai Coupe/Tiburon 1998-2000 Applies to: GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual DTC - B1111, B1112 DISPLAY ON SCAN DTC CODE CONDITION TOOL Ignition switch "ON" or start release B1111 Battery voltage - High input battery voltage >...
  • Page 25 LIMIT: Continuity...
  • Page 26 SERVICE MANUAL Hyundai Coupe/Tiburon 1998-2001 Applies to: GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual COMPONENTS...
  • Page 27 SERVICE MANUAL Applies to: Hyundai Coupe/Tiburon 1998-2000 GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual INFLATOR MODULES (DAB, PAB) Both DAB (Driver airbag) and PAB (Passenger airbag) module are comprised of inflator and cushion. The initiator (A gas generator igniting device) is assembled in the inflator.
  • Page 28: Clock Spring

    DAB and PAB module circuit when the connectors are disconnected. The circuits to the inflator module are shorted in this way to help prevent unwanted deployment of the airbag when serving the airbag module. SRSCM INDEPENDENT LAMP ACTIVATION The SRS malfunction indicator lamp (MIL) is located on the cluster giving information of SRS operating conditions by the control signals from SRSCM.
  • Page 29 CLOCK SPRING , , , ..SRSCM /< .,.-------- ,·...
  • Page 30: Air Bag Module Disposal Procedures

    SERVICE MANUAL Hyundai Coupe/Tiburon 1998-2000 Applies to: GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual AIR BAG MODULE DISPOSAL FIELD DEPLOYMENT PROCEDURES CAUTION When handling the deployed airbag be care not the by-product dust enter to eye and always wear gloves to avoid direct contact the by-product material.
  • Page 31 Car scrapping (DAB, PAB) with SST Crash (Deployed) Service station disposes the Air-bag module UNDEPLOYED AIR BAG MODULE DISPOSAL CAUTION 1. If the vehicle is to be scrapped, junked, or otherwise disposed of, deploy the air bag inside the vehicle. 2.
  • Page 32: Deployed Air Bag Module Disposal Procedures

    Remove the center console box. Remove Air-bag SRSCM connector. Connect disposal tool to the air bag checker R-terminal. Connect SRS air bag adapter harness battery (+) and (-) when the SRS harness checker still disconnected, to prevent sudden unexpected deployment of the air bag. Connect the SRS harness checker to SRSCM harness side connector.
  • Page 33 The inflator will be quite hot immediately following deployment, so wait at least 30 minutes to allow it to cool before attempting to handle it. Do not put water or oil on the air bag after deployment. There may be, adhered to the deployed air bag module, material that could irritate the eyes and or skin, so wear gloves and safety glasses when handling a deployed air bag module.
  • Page 34: Circuit Diagram

    SERVICE MANUAL Hyundai Coupe/Tiburon 1998-2000 Applies to: GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual CIRCUIT DIAGRAM...
  • Page 35 SERVICE MANUAL Hyundai Coupe/Tiburon 1998-2001 Applies to: GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual REASSEMBLY Return to Main Menu(s): Mechanical Manual Electrical Manual REMOVAL...
  • Page 36 CAUTION 1. Never attempt to disassemble or repair the air bag module or clock spring. 2. Do not drop the air bag module or allow contact with water, grease or oil. Replace it if a dent, crack, deformation or rust are detected. 3.
  • Page 37 SERVICE MANUAL Hyundai Coupe/Tiburon 1998-2001 Applies to: GROUP Restraints SRS Air Bag System Return to Main Menu(s): Mechanical Manual Electrical Manual COMPONENTS Return to Main Menu(s): Mechanical Manual Electrical Manual...
  • Page 38 SRSCM CONNECTOR VIEW "A" CAUTION Install the SRSCM with the arrow mark on the SRSCM facing toward the front of the vehicle. PIN DESCRIPTION (Connector pin layout) Pin 1 Not used Pin 2 Not used Pin 3 Not used Pin 4 Not used Pin 5 Ignition voltage...
  • Page 39 PIN DESCRIPTION (Shorting bar removal tab) Pin 16, 17 Not used Pin 18, 19 Not used Pin 21, 22 SRS SRI Pin 25, 26 Driver inflator Pin 28, 29 Passenger inflator...
