This Owner's Manual should be considered a part of the car and remain with it when it is sold for the use of the next owner.
ORIGINAL:
ADDRESS:
DATE OF SALE:
SUBSEQUENT:
ADDRESS:
TRANSFER DATE:
OWNER'S I.D.
NAME:
STREET:
TOWN:
COUNTRY:
P.CODE:
NAME:
STREET:
TOWN:
COUNTRY:
P.CODE:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Matrix 2003 and is the answer not in the manual?

Questions and answers

Related Manuals for Hyundai Matrix 2003

Summary of Contents for Hyundai Matrix 2003

  • Page 1 A000A01A-GAT This Owner's Manual should be considered a part of the car and remain with it when it is sold for the use of the next owner. OWNER'S I.D. ORIGINAL: NAME: ADDRESS: STREET: TOWN: COUNTRY: P.CODE: DATE OF SALE: SUBSEQUENT: NAME: ADDRESS: STREET:...
  • Page 2 A020A01A-AAT RESPONSIBILITY FOR MAINTENANCE The maintenance requirements for your new Hyundai are found in Section 5. As the owner, it is your responsibility to see that all maintenance operations specified by the manufacturer are carried out at the appropriate intervals. When the vehicle is used in severe driving conditions, more frequent maintenance is required for some operations.
  • Page 3 Specifications HFC2072 All information in this Owner's Manual is current at the time of publication. However, Hyundai reserves the right to make changes at any time so that our policy of continual product improvement may be carried out. This manual applies to all Hyundai models and includes descriptions and explanations of optional as well as standard equipment. As a result, you may find material in this manual that does not apply to your specific vehicle.
  • Page 4 Your Owner's Manual will introduce you to the features and operation of your new Hyundai. It is suggested that you read it carefully because the information it contains can contribute greatly to the satisfaction you receive from your new car.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS SECTION PAGE FEATURES OF YOUR HYUNDAI ................1-1 DRIVING YOUR HYUNDAI ..................2-1 WHAT TO DO IN AN EMERGENCY ................3-1 CORROSION PREVENTION & APPEARANCE CARE ..........4-1 VEHICLE MAINTENANCE REQUIREMENTS ............5-1 DO-IT-YOURSELF MAINTENANCE ................6-1 EMISSION CONTROL SYSTEMS ................
  • Page 6 CAUTION: MODIFICATIONS TO YOUR HYUNDAI Modification of components may void the manufacturer's warranty Your Hyundai should not be modified in any way. Modifications may adversely affect the safety, durability and performance of your Hyundai. Components which are subjected to modification or are added to the vehicle resulting in consequential damage are not covered by the vehicle manufacturer's warranty.
  • Page 7 A090A01A-AAT SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as WARNING, CAUTION and NOTE. These titles indicate the following: WARNING: This indicates that a condition may result in harm, serious injury or death to you or other persons if the warning is not heeded.
  • Page 8 Hyundai warranty. In addition, any dam- through authorized Hyundai PARTS age to or failure of Genuine Hyundai Dealerships. Parts caused by the installation or fail- 1. What are Hyundai Genuine Parts? ure of an imitation, counterfeit or used Hyundai Genuine Parts are the same...

  • Page 9: Features Of Your Hyundai

    Use Diesel B010D01S-AAT Diesel fuel of 52 to 54 cetane is used in Hyundai Do not Use Methanol vehicle. If two types of diesel fuel are available, Fuels containing methanol (wood alcohol) use summer or winter fuel properly according to should not be used in your Hyundai.
  • Page 10 B030A01A-AAT Operation in Foreign Countries KEYS utes at one time. If you are going to drive your Hyundai in another o Don't tow a trailer during the first 2,000 km country, be sure to: (1,200 miles) of operation. o Observe all regulations regarding registra- tion and insurance.
  • Page 11 A code number is stamped on the number plate The vehicle key number is recorded upon a that came with the keys to your Hyundai. This metal tag attached to the keys when the vehicle key number plate should not be left with the is first delivered to you.
  • Page 12 UNLOCK After doing the limp home procedure, you have LOCK NOTE: to consult with your authorized Hyundai dealer You can get the limp home password when as soon as possible. the vehicle is first delivered to you. If you do...
  • Page 13 B040C01FC-GAT Locking From the Outside LOCK UNLOCK HFC2006 Your Hyundai is equipped with a "child-protec- tor" rear door lock assembly. When the lock mechanism is engaged, the rear door cannot B040D01FC be opened from the inside. It's use is recom-...
  • Page 14 FEATURES OF YOUR HYUNDAI B040G01FC-GAT B040H02L-GAT Park the car and stop the engine. Arm the Central Door Lock (If Installed) Speed Sensing Auto Door Locking system as described below. (If Installed) 1) Remove the ignition key from the ignition When the speed of the vehicle keeps above switch.
  • Page 15 FEATURES OF YOUR HYUNDAI B070C01FC-GAT After completion of the step above, the turn Unlocking doors Alarm Stage signal lights will blink twice to indicate that the 1. Push the "UNLOCK" button on the transmit- The alarm will be activated if any of the system is disarmed.
  • Page 16 FEATURES OF YOUR HYUNDAI To raise or lower the window, turn the window regulator handle clockwise or counterclock- Case wise. WARNING: When opening or closing the windows, make sure your passenger's arms, hands and body are safely out of the way.
  • Page 17 FEATURES OF YOUR HYUNDAI 3) Do not leave children alone in the car. risk that the driver and passenger will slide slide the seat forward or rearward on its track Always remove the ignition key for their until it locks into the desired position and cannot under the seat belt which may result in safety.
  • Page 18 FEATURES OF YOUR HYUNDAI o Do not operate the vehicle with the head- B080F01S-AAT B080G01FC-GAT Seat Cushion Height Adjustment UNDER TRAY (If Installed) rests removed as severe injury to an occupant may occur in the event of an (Driver's Seat Only) (If Installed) accident.
  • Page 19 FEATURES OF YOUR HYUNDAI B080H01FC-GAT B080I01FC-BAT B090A01FC-GAT REAR SEAT Adjusting Seatback Angle Adjustable Headrests (If Installed) Adjusting Seat Forward and Rearward Lock Knob Seatback folding lever HFC2061 B090A01FC To recline the seatback, push the seatback Headrests are designed to help reduce the risk...
  • Page 20 FEATURES OF YOUR HYUNDAI B090B01FC-GAT 5. To secure the seat, hook the securing strap Folding Rear Seatback and Seat under the seat cushion to the headrest stay of front driver and passenger seat. Cushion 6. Insert the removed headrests between the...
  • Page 21 FEATURES OF YOUR HYUNDAI o When you return the folded down B140A01B-GAT B150B01Y-GAT REAR SEAT WARNING Infant or Small Child seatback to its upright position, always be sure to install the headrests in their Some countries require the use of child re- proper positions.
  • Page 22 Hyundai Dealer. should be sitting up and the front seats should 1- 14...
  • Page 23 FEATURES OF YOUR HYUNDAI WARNING: B170A04A-AAT sudden stop or impact, however, the belt will HEIGHT ADJUSTABLE FRONT SEAT o The height adjuster must be in the locked lock into position. It will also lock if you try to SHOULDER BELT (If Installed) position when the vehicle is moving.
  • Page 24 FEATURES OF YOUR HYUNDAI lock into position. It will also lock if you try to B210A01A-AAT B220A01A-AAT To Release the Seat Belt SEAT BELTS (2-Point Static Type) lean forward too quickly. Check to make sure that the belt is properly locked and that the belt (Rear Seat Center) (If Installed) is not twisted.
  • Page 25 FEATURES OF YOUR HYUNDAI B220B01A-AAT B220C01A-AAT B230A04P-GAT Adjusting Your Seat Belt To Release the Seat Belt CHILD RESTRAINT SYSTEM (If Installed) Children riding in the car should sit in the rear seat and must always be properly restrained to minimize the risk of injury in an accident, sud- den stop or sudden maneuver.
  • Page 26 Always refer to the child restraint sys- o If the seat belt will not properly fit the child, Hyundai recommends the use of tem manufacturer's recommendation before an approved booster seat in the rear seat installing the child restraint system in your vehicle.
  • Page 27 If the seat belt does not operate as described, have the system checked Cover, Child Restraint immediately by your authorized Hyundai Hook Holder (4 door only) dealer. Bolt, Holder (5/16"-30 mm) WARNING: Washer, Conical Spring...
  • Page 28 An ISOFIX-seat can only be installed if it has vehicle-specific approval in accordance with Back panel the requirements of ECE-R44. For your Hyundai, the Hyundai ISOFIX GR1 / Hyundai Front of Vehicle Duo / Römer ISOFIX GR1 and the Römer B230E01FC Duo ISOFIX / Britax Duo ISOFIX is approved according to the requirement ECE-R44.
  • Page 29 Refer to "Securing a Child Re- NOTE: other manufacturers will furnish proof of straint System with the Tether Anchorage a respective certification, Hyundai is go- An ISOFIX-child-seat can only be installed System" on page 1-20. ing to evaluate this seat carefully and will...
  • Page 30 Driver's airbag Child Seat Restaint Suitability for Seat Pre-tensioner Seat Belt (If Installed) Position Your Hyundai vehicle is equipped with driver's Use child safety seats that have been officially and front passenger's pre-tensioner seat belts. Passenger's approved and are appropriate for your chil-...
  • Page 31 This tions and are not hazardous. the ignition key is turned to "ON", or if it must be done by an authorized Hyundai o Although it is harmless, the fine dust remains illuminated after blinking for dealer.
  • Page 32 The SRS is designed to deploy the airbags Your Hyundai is equipped with a Supplemental the deployment threshold speed. Restraint (Airbag) System. The indications of only when an impact is sufficiently se-...
  • Page 33 FEATURES OF YOUR HYUNDAI o Do not tamper with or disconnect SRS B240B01FC-GAT SRS Components and Functions wiring, or other components of the SRS system. Doing so could result in injury, due to accidental firing of the airbags or by rendering the SRS inoperative.
  • Page 34 Hyundai dealer. o Before you replace a fuse or disconnect A fully inflated airbag in combination with a CAUTION:...
  • Page 35 WARNING: B990B02Y o For best protection from the side impact B240C03Y-GAT Your Hyundai is equipped with a side airbag in airbag system and to avoid being injured SRS Care by the deploying side impact airbag, both each front seat. The purpose of the airbag is to...
  • Page 36 Do not replace the bumper or the bumper instrument panel, and the front guard with the one other than the Hyundai passenger's panel above the glove box, genuine parts. Otherwise, it can adversely...
  • Page 37 FEATURES OF YOUR HYUNDAI B250A01FC-GAT INSTRUMENTS AND CONTROLS 1. Front Fog Light Switch (If installed) 9101112 1234 2. Headlight Leveling Switch (If installed) 3. Rear Fog Light Switch (If installed) 4. Multi-Function Light Switch 5. Indicator and Warning Light 6. Horn and Driver's Airbag (If installed) 7.
  • Page 38 FEATURES OF YOUR HYUNDAI B260A01FC-GAT INSTRUMENT CLUSTER AND INDICATOR (GASOLINE ENGINE) 1. Temperature Gauge 2. Tachometer 3. Speedometer 4. Digital Clock 5. Odometer/Trip Odometer/Trip Computer (If installed) 6. Fuel Gauge 7. Turn Signal Indicator Light 8. Automatic Transaxle Position Indicator Light (Auto T/A only) 9.
  • Page 39 FEATURES OF YOUR HYUNDAI B260B01FC-GAT INSTRUMENT CLUSTER AND INDICATOR (DIESEL ENGINE) 1. Temperature Gauge 2. Tachometer 3. Speedometer 4. Digital Clock 5. Odometer/Trip Odometer/Trip Computer (If installed) 6. Fuel Gauge 7. Fuel Filter Warning Light 8. Turn Signal Indicator Light 9.
  • Page 40 If this occurs, have your vehicle checked by engine running, turn the engine off immedi- be consulted for repairs. your Hyundai dealer as soon as possible. The ately. In any instance where the oil light normal braking system will still be operational,...
  • Page 41 FEATURES OF YOUR HYUNDAI CAUTION: B260H03A-AAT Hyundai dealer for inspection. If further trouble Parking Brake/Low Brake Fluid is experienced, the vehicle should not be driven If the drive belt (generator belt) is loosen, at all but taken to a dealer by a professional...
  • Page 42 Hyundai dealer The sound may come and go or be heard all the accumulated inside the fuel filter. If this hap- and have the system checked.
  • Page 43 Then open the hood and after the engine has cooled, check the coolant level and the water pump drive belt. If you suspect cool- ing system trouble, have your cooling system checked by a Hyundai dealer as soon as pos- HFC2043 sible. 1- 35...
  • Page 44 FEATURES OF YOUR HYUNDAI B310B01FC-GAT Diesel engine ODOMETER/TRIP ODOMETER Without Trip Computer B330A01FC The tachometer registers the speed of your HFC2090 Reset switch 1. Odometer HFC2089 engine in revolutions per minute (rpm). It is useful to help you shift at the appropriate en-...
  • Page 45 TRIP COMPUTER (If Installed) o If the distance to empty is indicated "- -", have the trip computer system checked by your authorized Hyundai dealer. AVERAGE SPEED o The distance to empty can differ from the actual tripmeter according to driving conditions.
  • Page 46 Turn Signal Operation (If Installed) Pulling down on the lever causes the turn Your Hyundai is equipped with daytime running signals on the left side of the car to blink. lights. The daytime running lights are used to Pushing upwards on the lever causes the turn improve visibility for oncoming traffic.
  • Page 47 FEATURES OF YOUR HYUNDAI B340D01A-AAT B350A01A-AAT B350B01O-GAT WINDSHIELD WIPER AND WASHER High-beam Switch Windshield Washer Operation SWITCH To turn on the headlight high beams, push the lever forward (away from you). The high beam indicator light will come on at the same time.
  • Page 48 FEATURES OF YOUR HYUNDAI To use the intermittent wiper feature, place the B370A01A-AAT Mist Wiper Operation HAZARD WARNING SYSTEM wiper switch in the "INT" position. With the switch in this position, the interval between wipes can be varied from approximately 1 to 18 seconds by turning the interval adjuster barrel.
  • Page 49 FEATURES OF YOUR HYUNDAI B380A02HP-AAT B360B01FC-GAT B360A01Y-GAT REAR WINDOW DEFROSTER FRONT FOG LIGHT SWITCH REAR FOG LIGHT SWITCH (If Installed) SWITCH (If Installed) B360A01FC HFC2080 B360B01FC To turn on the rear fog lights, push the switch. They will come on when the headlight switch is...
  • Page 50 If it is necessary to replace the cigarette lighter, MIN - Push "M" to advance the minute indicat- use only a genuine Hyundai replacement or its approved equivalent. RESET - Push "R" to reset minutes to ":00" to facilitate resetting the clock to the correct time.
  • Page 51 FEATURES OF YOUR HYUNDAI B450B01FC-GAT B611A01FC-GAT B340G01FC-GAT REAR DRINK HOLDER REAR SEAT ARM REST (If Installed) HEADLIGHT LEVELING DEVICE (If Installed) SYSTEM (If Installed) B610A01FC B340G01FC HFC2098 This arm rest is located in the center of the rear seat back with box.
  • Page 52 FEATURES OF YOUR HYUNDAI WARNING: The sunshade can be opened and closed by Switch sliding it forward or rearward when the sunroof o Do not close a sunroof if anyone's hands, Loading condition position is closed. The sunshade will open automati-...
  • Page 53 FEATURES OF YOUR HYUNDAI NOTE: B480A01E-AAT FRONT INTERIOR LIGHT After washing the car or after there is rain, be sure to wipe off any water that is on the Map Light sunroof before operating it. With Sunroof Without Sunroof B460D01FC-GAT...
  • Page 54 FEATURES OF YOUR HYUNDAI B490A01E-AAT B491A02F-GAT B500A01A-AAT INTERIOR LIGHT SPECTACLE CASE (If Installed) GLOVE BOX Without Sunroof With Sunroof HFC2095 HXDOM241 B490A01E B490B01E The interior courtesy light has a button of three WARNING: The spectacle case is located on the front positions.
  • Page 55 FEATURES OF YOUR HYUNDAI To adjust the position of either B500B02E-GAT B510B01FC-GAT MULTI BOX OUTSIDE REARVIEW MIRROR mirror: Electric Type 1. Move the selecting switch to the right or left to activate the adjustable mechanism for the corresponding door mirror.
  • Page 56 HFC2080 The outside rearview mirror heater is actuated To fold the outside rearview mirrors, push them Your Hyundai is equipped with a day/night in connection with the rear window defroster. towards the rear. inside rearview mirror. The "night" position is...
  • Page 57 FEATURES OF YOUR HYUNDAI B530A01A-AAT B550A01S-GAT B810A01FC-GAT PARKING BRAKE HIGH-MOUNTED REAR STOP LIGHT FOLD-UP TRAY (If Installed) HFC2070 B530A01FC Always engage the parking brake before leav- B550A01FC For your convenience, it may be used as a table ing the car. This also turns on the parking brake holding a book, cup or can.
  • Page 58 ACCESSORY TRAY electric accessories or equipment only when the key is in the "ON" or "ACC" position. CAUTION: Do not use electric accessories or equip- ment other than the Hyundai genuine parts in the socket. B570A01FC-GAT HOOD RELEASE HFC2019 CAUTION:...
  • Page 59 FEATURES OF YOUR HYUNDAI B560A01HP-AAT B540A01FC-GAT REMOTE FUEL-FILLER LID RELEASE TAIL GATE UNLOCK LOCK HFC2016 WARNING: B540A01FC HFC2015 Fuel vapors are dangerous. Before refuel- ing, always stop the engine and never allow The fuel-filler lid may be opened from inside the WARNING: sparks or open flames near the filler area.
  • Page 60 FEATURES OF YOUR HYUNDAI B800A02FC-GAT B540D02FC-GAT B650A01FC-GAT CD Auto Changer (If Installed) Luggage Net (If Installed) CARGO AREA COVER (If Installed) HFC2105 B540D01HP B640A01FC Some objects can be kept in the net in the A CD Auto Changer is located under the front luggage compartment.
  • Page 61 HFC2106 o To use the roof rails as a roof rack, you HFC4001 If your Hyundai has a roof rack, you can load must fit the roof rails with two or more things on top of your vehicle. Crossrails and...
  • Page 62 (If Installed) To Adjust the Steering Wheel: Vanity mirror HFC2094 B610B01FC Your Hyundai is equipped with sun visors to Press the center hub of the steering wheel to give the driver and front passenger either fron- sound the horn. HFC2041 tal or sideward shade.
  • Page 63 FEATURES OF YOUR HYUNDAI B710A01Y-GAT B710A01S-AAT Heating and Cooling Control (If Installed) VENTILATION To operate the ventilation system: o Set the air intake control to "Fresh" mode o To direct all intake air to the dashboard vents, set the air flow control to "Face".
  • Page 64 FEATURES OF YOUR HYUNDAI B670A01FC-GAT B670B01A-AAT B670C02FC-GAT HEATING AND VENTILATION Fan Speed Control (Blower Control) Air Intake Control ROTARY TYPE (If Installed) HFC2067 HFC2065 B670A01FC This is used to turn the blower fan on or off and This is used to select fresh outside air or to select the fan speed.
  • Page 65 FEATURES OF YOUR HYUNDAI NOTE: B670D05A-AAT Air Flow Control o It should be noted that prolonged opera- tion of the heating in "Recirculation" mode will increase to fogging of the windshield and side windows and the air within the passenger compartment will become stale.
  • Page 66 FEATURES OF YOUR HYUNDAI This control is used to adjust the degree of heating or cooling desired. B690A02S-AAT HEATING CONTROLS For normal heating operation, set the air intake control to the "Fresh" position and the air flow control to "Floor".
  • Page 67 FEATURES OF YOUR HYUNDAI To remove interior fog on the windshield; NOTE: Your Hyundai is equipped with bi-level heating controls. This makes it possible to have cooler o Set the air flow control to the defrost ( When the A/C is operated continuously on air from the dashboard vents and warmer air position.
  • Page 68 FEATURES OF YOUR HYUNDAI B740A01S-AAT B740B01FC-GAT B740C01FC-GAT Air Conditioning Operation AIR CONDITIONING SYSTEM Dehumidified Heating Cooling (If Installed) Air Conditioning Switch B740C01FC B740B01FC For dehumidified heating: To use the air conditioning to cool the interior: HFC2069 o Turn on the fan control switch.
  • Page 69 FEATURES OF YOUR HYUNDAI CAUTION: B740D01A-AAT B760A01FC-GAT Operation Tips AIR FILTER (IN FRONT OF BLOWER o Replace the filter every 20,000 km (12,000 o If the interior of the car is hot when you first miles) or once a year. If the car is being...
  • Page 70 FEATURES OF YOUR HYUNDAI B750A02A-AAT AM reception FM radio station STEREO SOUND SYSTEM Ionosphere Unobstructed How Car Audio Works area FM reception Ionosphere Mountains Buildings Iron bridges SSAR012A SSAR011A Obstructed area AM broadcasts can be received at greater FM broadcasts are transmitted at high fre- distances than FM broadcasts.
  • Page 71 FEATURES OF YOUR HYUNDAI B750B02Y-AAT Using a cellular phone or a two-way radio When a cellular phone is used inside the ve- hicle, noise may be produced from the audio equipment. This does not mean that something is wrong with the audio equipment. In such a case, use the cellular phone at a place as far as possible from the audio equipment.
  • Page 72 FEATURES OF YOUR HYUNDAI H210A01O-AAT STEREO RADIO OPERATION (H210) (If Installed) 2. FADER Control Knob 5. TUNE/SEEK Select Button 4.BAND Selector 6. PRESET Station Select Button 3. BASS/TREBLE Control Knob 1. POWER ON-OFF, BALANCE, VOLUME, SCAN Control Knob H210A01O 1- 64...
  • Page 73 FEATURES OF YOUR HYUNDAI H210B02O-AAT will be emphasized (Front speaker sound will 6. PRESET STATION SELECT Button 1. POWER ON-OFF/VOLUME Control be attenuated). Six (6) stations for AM, FM1 and FM2 respec- Knob tively can be preset in the electronic memory 3.
  • Page 74 FEATURES OF YOUR HYUNDAI B220A01E-BAT STEREO RADIO OPERATION (H220) (If Installed) 2. FADER Control Knob 5. TUNE/SEEK Select Button 4.BAND Selector 6. PRESET Station Select Button 3. BASS/TREBLE Control Knob 1. POWER ON-OFF, BALANCE, VOLUME, SCAN Control Knob B220A01E-BAT 1- 66...
  • Page 75 FEATURES OF YOUR HYUNDAI H210B02O-AAT will be emphasized (Front speaker sound will 6. PRESET STATION SELECT Button 1. POWER ON-OFF/VOLUME Control be attenuated). Six (6) stations for AM, FM1 and FM2 respec- Knob tively can be preset in the electronic memory 3.
  • Page 76 FEATURES OF YOUR HYUNDAI B220C01E-BAT CASSETTE TAPE PLAYER OPERATION (H220) (If Installed) 2. EJECT Button 1. FF/REW Button 3. TAPE SLOT B220A01E 1- 68...
  • Page 77 FEATURES OF YOUR HYUNDAI B200D01E-BAT 1. FF/REW/PROGRAM BUTTON Pushing the Fast-forward button will cause the tape to move rapidly in the forward direction of play. Pushing the Rewind button will cause the tape to move rapidly in the reverse direction of play.
  • Page 78 FEATURES OF YOUR HYUNDAI H260A01O-AAT STEREO RADIO OPERATION (H260) (If Installed) 3. BASS/TREBLE Control Knob 4. SCAN Button 6. BAND Selector 7. PRESET Button 5. TUNE/SEEK Select Button 1. POWER ON-OFF/VOLUME/BALANCE Control Knob 2. FADER Control Knob H260A01O 1- 70...
  • Page 79 FEATURES OF YOUR HYUNDAI H260B03E-AAT 3. BASS Control Knob 6. BAND Selector 1. POWER ON-OFF Control Knob Press to pop the knob out and turn to the left Pressing the button changes the AM, FM/AM The radio unit may be operated when the or right for the desired bass tone.
  • Page 80 FEATURES OF YOUR HYUNDAI You should then release the button, and proceed to program the next desired sta- tion. A total of 18 stations can be pro- grammed by selecting one AM and two FM stations per button. o When completed, any preset station may be recalled by selecting AM, FM or FM2 band and the appropriate station button.
  • Page 81 FEATURES OF YOUR HYUNDAI H260B01O-AAT COMPACT DISC PLAYER OPERATION (H260) (If Installed) 4. SCAN Button 1.Playing CD 3. TRACK UP/DOWN 6. EJECT Button 2. FF/REW Button 5. REPEAT Button H260A01O 1- 73...
  • Page 82 FEATURES OF YOUR HYUNDAI o This unit is made of precision parts. Do B260D02O-AAT 5. REPEAT Button 1. Playing CD not attempt to disassemble or adjust any o To repeat the track you are currently listen- o Insert the CD with the label facing upward.
  • Page 83 FEATURES OF YOUR HYUNDAI B260E01E-AAT CD AUTO CHANGER (H260) (If Installed) 6. SCAN Button 1. CD Select Button 3. TRACK UP/DOWN 4. FF/REW Button 5. REPEAT Button 2. DISC Select Button H260A01O 1- 75...
  • Page 84 The played. Hyundai CD changer can hold up to eight discs. This process will be continued until you The disc number will be lit, and the track push the button again.
  • Page 85 FEATURES OF YOUR HYUNDAI H290A01FC-GAT STEREO RADIO OPERATION (H280) (If Installed) 1. POWER ON/OFF VOLUME Control Knob 8. BEST STATION MEMORY or SCAN Button (If installed) 7. EQUALIZER Button 3. TREBLE/FAD Konb 2. BASS/BALANCE Control Knob 5. PRESET Buttons 4. TUNE/SEEK Select Button H290A01O 6.
  • Page 86 FEATURES OF YOUR HYUNDAI H290B03E-GAT 3. TREBLE/FAD Knob 5. PRESET STATION Select Buttons 1. POWER ON-OFF Control Knob Six (6) stations for AM, FM and FM2 respec- TREBLE Control Knob The radio unit may be operated when the tively can be preset in the electronic memory Press to pop the knob out and turn to the left ignition key is in the "ACC"...
  • Page 87 FEATURES OF YOUR HYUNDAI 6. BAND Selector Pressing the button changes the AM, FM1 FM/AM and FM2 bands. The mode selected is shown on the display. 7. EQUALIZER Button Press the EQ button to select the CLASSIC, JAZZ, ROCK and DEFEAT MODE for the de- sired tone quality.
  • Page 88 FEATURES OF YOUR HYUNDAI H290C01FC-GAT CASSETTE TAPE PLAYER OPERATION (H280) (If Installed) 5. EQUALIZER Button 4. TAPE EJECT Button 2. AUTO MUSIC Select Button 1. FF/REW Button 6. DOLBY Button 3. TAPE PROGRAM Button H290A01O 1- 80...
  • Page 89 FEATURES OF YOUR HYUNDAI H290D01O-GAT 4. TAPE EJECT button 1. FF/REW Button o When the button is pressed with the o Fast forward tape winding starts when the cassette loaded, the cassette is ejected. FF ( ) button is pressed during the PLAY...
  • Page 90 FEATURES OF YOUR HYUNDAI H290E01FC-GAT COMPACT DISC PLAYER OPERATION (H280) (If Installed) 6. CD EJELT Button 7. SCAN Button (If installed) 5. EQUALIZER Button 3. TRACK UP/DOWN 2. FF/REW Button 4. REPEAT 1. CD Select Button H290A01O 1- 82...
  • Page 91 FEATURES OF YOUR HYUNDAI NOTE: H290F01O-GAT 4. REPEAT 1. CD Select Button o To assure proper operation of the unit, o To repeat the track you are currently listen- o Insert the CD with the label facing upward. keep the vehicle interior temperature ing to, press the RPT button.
  • Page 92 FEATURES OF YOUR HYUNDAI H290G02FC-GAT CD AUTO CHANGER (H280) (If Installed) 6. SCAN Button (If installed) 7. EQ Button 3. TRACK UP/DOWN 4. FF/REW Button 5. REPEAT 2.DISC Select Button 1. CD CHANGER Select Button H290A01O 1- 84...
  • Page 93 The Hyundai CD changer can WARNING: This process will be continued until you hold up to eight discs. The disc number will be Never attempt to change CDs the already push the button again.
  • Page 94 SOLUTION CD DECK MECHANICAL ERROR AFTER RESETTING THE AUDIO, PUSH THE EJECT BUTTON. (EJECT ERROR, LOADING ERROR) IF DISC IS NOT EJECTED, CONSULT YOUR HYUNDAI DEALER. FOCUS ERROR MAKE SURE THE DISC IS NOT SCRATCHED OR DAMAGED. DATA READ ERROR PRESS THE EJECT BUTTON AND PULL OUT THE DISC.
  • Page 95 FEATURES OF YOUR HYUNDAI B850A01F-AAT Do not grip or pull out the disc with your hand B860A01A-AAT CARE OF DISC Care of Cassette Tapes while the disc is being pulled into the unit by the self loading mechanism. Proper Handling...
  • Page 96 FEATURES OF YOUR HYUNDAI Head Cotton applicator B880A01FC SSAR042B B860A04A o Be sure that the cassette label is not loose o The playback head, capstan and pinch roll- NOTE: or peeling off or tape ejection may be diffi- ers will develop a coating of tape residue Look at a tape before you insert it.
  • Page 97 FEATURES OF YOUR HYUNDAI B870D01FC-GAT ANTENNA Roof Antenna HFC2100 Your car uses a roof antenna to receive both AM and FM broadcast signals. This antenna is a removable type. To remove the antenna, turn the antenna counterclock- wise. To install the antenna, turn the antenna clockwise.

  • Page 98: Driving Your Hyundai

    Hyundai dealer. o Do not run the engine in an enclosed area.
  • Page 99 1. Look around the vehicle to be sure there are no flat tires, puddles of oil, water or other o If your Hyundai is equipped with a manual indications of possible trouble. transaxle, place the shift lever in neutral and 2.
  • Page 100 DRIVING YOUR HYUNDAI o "LOCK" C050A01A-GAT C050B02S-GAT STARTING FOR THE GASOLINE ENGINE NORMAL CONDITIONS The key can be removed or inserted in this position. The Starting Procedure: To protect against theft, the steering wheel locks 1. Insert key, and fasten the seat belt.
  • Page 101 If the Your Hyundai's manual transaxle has a conven- tachometer will enter the red zone. Such engine is cold, allow the engine to idle for tional shift pattern.
  • Page 102 C090A01FC 75 km/h (45 mph) speed can cause the drive wheels to lose The highly efficient Hyundai automatic transaxle traction and the vehicle to go out of control. has four forward speeds and one reverse speed. It has a conventional shift pattern as shown in the...
  • Page 103 DRIVING YOUR HYUNDAI CAUTION: C090C01A-AAT C090G01S-GAT o R(Reverse): o L (Low gear): Never shift into "R" or "P" position while the vehicle is moving. Use for backing up the vehicle. Bring the car to a Use for driving up a very steep grade or for complete stop before shifting the selector lever to engine braking when descending steep hills.
  • Page 104 DRIVING YOUR HYUNDAI o In the event your vehicle leaves the road- C090I02A-AAT o Do not "ride" the brakes. This can cause them CAUTION: to overheat and malfunction. Instead, when way, do not steer sharply. Instead, slow o Shift into "R" and "P" position only when...
  • Page 105 Hyundai dealer for assis- o Under some conditions your parking brake tance. can freeze in the engaged position. This is o Don't coast down hills with the car out of gear.
  • Page 106 If the indicator does not illuminate, have it checked This could endanger the safety of yourself or Traction control is only a driving aid; all by an authorized Hyundai dealer. others. normal precautions for driving in inclement weather and on slippery driving surfaces Should there be any unusual conditions in the should be observed.
  • Page 107 Always maintain a safe distance from other always be taken under gentle acceleration. If you your Hyundai should be kept clean and free of vehicles so you can avoid unnecessary brak- follow these suggestions, tire wear will be held to corrosive materials.
  • Page 108 Window washer anti-freeze is available will not prevent side skids. consult your Hyundai dealer. from Hyundai dealers and most auto parts out- lets. Do not use engine coolant or other types of NOTE: anti-freeze as these may damage the finish.
  • Page 109 Ask your overheating and possible failure of the tires. Severe Usage Conditions" on page 5-5. Hyundai dealer for further details before towing. Avoid using worn or damaged tires which may result in reduced traction or tire failure.
  • Page 110 DRIVING YOUR HYUNDAI NOTE: C190D01A-GAT Safety Chains 1. Never load the trailer with more weight in Should the hitch connection between your car the back than in the front. About 60% of and the trailer or vehicle you are towing fail, the...
  • Page 111 DRIVING YOUR HYUNDAI 5. Always secure items in the trailer to prevent 14.When going down a hill, shift into a lower gear kg (Lbs.) load shift while driving. and use the engine braking effect. Maximum Towable 6. Check the condition and air pressure of all When ascending a long grade, downshift the tires on the trailer and your car.

  • Page 112: What To Do In An Emergency

    1. If your car has an automatic transaxle, be 4 If engine still refuses to start, call a Hyundai tance. Automobile batteries contain sulfuric sure the gear selector lever is in "N" or "P" and dealer or seek other qualified assistance.
  • Page 113 If you do not know why your battery became conditioning had been in use, it is normal for discharged (because the lights were left on, cold water to be draining from it when you etc.), have the charging system checked by your stop). Hyundai dealer.
  • Page 114 5. The temporary spare tire should not be used be checked as soon as possible by a Hyundai on any other wheels, nor should standard WARNING (Diesel only): dealer.
  • Page 115 WHAT TO DO IN AN EMERGENCY D040B01FC-GAT D040B01A-AAT 2. When the car is stopped, turn on your emer- FULL SIZE SPARE TIRE (If Installed) Handling the Spare Tire gency hazard flashers, set the parking brake The following instructions for the FULL SIZE and put the transaxle in "P"...
  • Page 116 WHAT TO DO IN AN EMERGENCY D060K01FC-GAT 4. Reinstall the wheel cap by fitting the boss of D060C01A-AAT Wheel Cap (If Installed) 2. Block the Wheel the wheel cap in the groove of the wheel, hitting the center of the wheel cap with your Flat tire hand.
  • Page 117 WHAT TO DO IN AN EMERGENCY The wheel nuts should be loosened slightly be- D060F02E-AAT D060G01Y-AAT 5. Raising the Car 6. Changing Wheels fore raising the car. To loosen the nuts, turn the wheel nut wrench handle counterclockwise. When doing this, be sure that the socket is seated completely over the nut so it cannot slip off.
  • Page 118 WHAT TO DO IN AN EMERGENCY D060H02A-AAT D060I01E-GAT 7. Re-install Wheel Nuts 8. Lower Vehicle and Tighten Nuts STA3071H WARNING: D060I01FC D060H01FC Wheel and wheel covers may have sharp To reinstall the wheel cover, hold it on the studs, Lower the car to the ground by turning the wheel edges.
  • Page 119 Always reinstall the valve cap after checking or your Hyundai dealer or a commercial tow truck neutral. Also, be sure that the ignition key is in adjusting tire pressure. If the cap is not replaced, service.
  • Page 120 WHAT TO DO IN AN EMERGENCY D080C02A-GAT D080D02A-AAT Towing a Car with an Automatic Emergency Towing Transaxle D080C02FC o OK FOR AUTOMATIC OR MANUAL D080C01FC TRANSAXLE EQUIPPED VEHICLE o NOT OK FOR AUTOMATIC TRANSAXLE NOTE: EQUIPPED VEHICLE D080D01FC Before towing, check the level of the transaxle o OK FOR MANUAL TRANSAXLE For emergency towing when no commercial tow fluid.
  • Page 121 D120A01A-GAT IF YOU LOSE YOUR KEYS If you lose your keys, many Hyundai dealers can make you a new key if you have your key number. If you lock the keys inside your car and you cannot obtain a new key, many Hyundai dealers can use special tools to open the door for you.

  • Page 122: Corrosion Prevention & Appearance Care

    To achieve the long- In winter, hose off the underside of your car at contact with the car surfaces by moisture that is term corrosion resistance your Hyundai can de- slow to evaporate. least once a month and be sure to clean the liver, the owner’s cooperation and assistance is...
  • Page 123 Moisture can collect under the floor mats and are available at your Hyundai dealer or auto parts sion. To protect the paintwork of the car against carpeting to cause corrosion. Check under the outlet.
  • Page 124 In the normal course of use, leather upholstered clean, soft cloth or commercially available bug Hyundai. They are: and tar remover. Be gentle. surfaces will, like any material, pick-up dust and dirt. This dust and dirt must be cleaned off or it...
  • Page 125 If you have any questions about the care of your type are available in aerosol cans in liquid form or car, consult your Hyundai dealer. powder. Read the instructions and follow them exactly. Using a vacuum cleaner with the appro- priate attachment, remove as much dirt from the carpets as possible.

  • Page 126: Vehicle Maintenance Requirements

    These are the regular checks you should per- ceipts for all emission control system services be divided into three main areas: form when you drive your Hyundai or you fill the should be retained to demonstrate compliance with conditions of the emissions system war- fuel tank.
  • Page 127 VEHICLE MAINTENANCE REQUIREMENTS F030A01A-GAT SCHEDULED MAINTENANCE The following maintenance services must be performed to assure good vehicle control and performance. Keep receipts for all vehicle services to protect your warranty. Where both mileage and time are shown, the frequency of service is determined by whichever occurs first. F030B03E-GAT R :Replace I : Inspect and, after Inspection, clean, adjust, repair or replace if necessary.
  • Page 128 FUEL LINES, FUEL HOSE & CONNECTIONS Note : (1) EVERY 500 KM OR BEFORE STARTING A LONG TRIP : "I" (2) INSPECT EVERY 7,500KM OR 6 MONTHS AND REPLACE EVERY 15,000KM OR 12 MONTHS. WHEN REPLACING THE FUEL FILTER CARTRIDGE, USE HYUNDAI GENUINE PARTS.
  • Page 129 VEHICLE MAINTENANCE REQUIREMENTS F030C04E-GAT R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary KILOMETERS X 1000 DESCRIPTION MONTHS GENERAL MAINTENANCE COOLING SYSTEM See Note (1) GASOLINE ENGINE COOLANT DIESEL ENGINE MANUAL TRANSAXLE OIL AUTOMATIC TRANSAXLE European Community Only FLUID...
  • Page 130 VEHICLE MAINTENANCE REQUIREMENTS F040A03E-GAT MAINTENANCE UNDER SEVERE USAGE CONDITIONS The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MAINTENANCE DRIVING MAINTENANCE ITEM...
  • Page 131 VEHICLE MAINTENANCE REQUIREMENTS F060A01A-AAT F060D02A-AAT F060G01A-AAT o Fuel Lines, Fuel Hoses and EXPLANATION OF SCHEDULED o Vapor Hose and Fuel Filler Cap Connections The vapor hose and fuel filler cap should be MAINTENANCE ITEMS Check the fuel lines, fuel hoses and connec- inspected at those intervals specified in the F060M01A-AAT tions for leakage and damage.
  • Page 132 Air Cleaner Filter o Manual Transaxle Oil o Brake Fluid A Genuine Hyundai air cleaner filter is recom- Inspect the manual transaxle oil according to Check brake fluid level in the brake fluid reser- mended when the filter is replaced.
  • Page 133 VEHICLE MAINTENANCE REQUIREMENTS F070L01A-AAT F070Q01A-AAT o Suspension Mounting Bolts o Air Conditioning Refrigerant Check the suspension connections for loose- Check the air conditioning lines and connec- ness or damage. Retighten to the specified tions for leakage and damage. Check air condi- torque.

  • Page 134: Do-It-Yourself Maintenance

    DO-IT-YOURSELF MAINTENANCE 6. DO-IT-YOURSELF MAINTENANCE G010B01FC-GAT ENGINE COMPARTMENT (1.6 DOHC) CAUTION: When inspecting or servicing the engine, you should handle tools and other heavy objects carefully so that the plastic rocker cover of the engine is not damaged. HFC5001 9 10 1.
  • Page 135 DO-IT-YOURSELF MAINTENANCE G010C01FC-GAT ENGINE COMPARTMENT (1.8 DOHC) CAUTION: When inspecting or servicing the engine, you should handle tools and other heavy objects carefully so that the plastic rocker cover of the engine is not damaged. HFC003 9 10 1. Air filter element 5.
  • Page 136 DO-IT-YOURSELF MAINTENANCE G010E01FC-GAT ENGINE COMPARTMENT (DIESEL) G010E01FC-1 1. Air filter element 5. Relay box 9. Engine coolant reservoir 2. Engine oil filler cap 6. Power steering fluid reservoir 10.Battery 3. Brake fluid and clutch fluid reservoir 7. Engine oil level dipstick 11.Windshield washer fluid reservoir cap 4.
  • Page 137 Light condition and operation ly, inspect it carefully and seek assistance from o Windshield glass condition your Hyundai dealer if service is needed. NOTE: o Wiper blade condition SAE 5W-20 is not recommended for sus- o Paint condition and body corrosion tained high speed vehicle operation.
  • Page 138 DO-IT-YOURSELF MAINTENANCE G030B02FC-GAT G030C01FC-GAT Wait about five minutes (gasoline engine) /Wait CHECKING THE ENGINE OIL To Check the Oil Level about two minutes (diesel engine), then remove the dipstick, wipe it off, fully reinsert the dipstick Diesel Engine Gasoline engine and withdraw it again.
  • Page 139 DO-IT-YOURSELF MAINTENANCE If the oil level is close to or below the "L" mark, burned by the high temperature combustion 1. Park the car on level ground and set the add oil until it reaches the "F" mark. To add oil: gases during the combustion process.
  • Page 140 DO-IT-YOURSELF MAINTENANCE 6. Install a new oil filter in accordance with the G040B03FC-GAT 3. Slide underneath the car and loosen the oil CHANGING THE OIL AND FILTER instructions on the carton or on the filter pan drain plug by turning it counterclockwise itself.
  • Page 141 Use a high quality ethylene-glycol coolant in a filter should be changed by an authorized 50/50 mix with water. The engine coolant should Hyundai dealer. be compatible with aluminum engine parts. Additional corrosion inhibitors or additives should not be used. The cooling system must be main-...
  • Page 142 60% level or go below the quently. If the level drops again, visit your 35% level, or damage to the cooling system Hyundai dealer for an inspection and diagnosis Gasoline engine may result. For proper concentration when add- of the reason.
  • Page 143 When spark plugs are replaced, always use spark WARNING: plugs recommended by Hyundai. The use of The cooling fan is controlled by engine cool- other spark plugs can result in loss of perfor- mance, radio interference or engine damage.
  • Page 144 DO-IT-YOURSELF MAINTENANCE G060C01S-GAT Changing the Spark Plugs SSA6061A SSA6062A WARNING: NOTE: SSA6060B It is recommended that the engine be cool Spark plugs should be tightened firmly. Over- or cold when changing the spark plugs. If tightening can damage the threads in the You will find it easier to change spark plugs if the engine is hot, you could burn yourself the engine is cold.
  • Page 145 If the wipers continue to streak or smear the quent use. glass, replace them with Genuine Hyundai Re- The capacity of the washer reservoir is 3.0 G070A02FC placement Parts or their equivalent.
  • Page 146 Section 5. Level G110B03A-AAT Recommended Fluid Your Hyundai automatic transaxle is specially designed to operate with DIAMOND ATF SP-III or SK ATF SP-III. Damage caused by a nonspecified fluid is not covered by your new vehicle limited warranty.
  • Page 147 DO-IT-YOURSELF MAINTENANCE WARNING: G110D03A-GAT While the engine is idling, apply the brakes and To Check the Transaxle Fluid Level move the gear selector lever from "P" to each The cooling fan is controlled by engine cool- of its other positions -- "R", "N", "D", "2", "L" - ant temperature and may sometimes oper- - and then return to "N"...
  • Page 148 Use only they be checked and inspected by your DOT 3 or DOT 4 specification fluid from a Hyundai dealer. The brakes should be sealed container. Do not allow the fluid can checked and inspected for wear at those...
  • Page 149 2. If the air coming out of the in-dash vents is G130B02A-AAT not cold, have the air conditioning system To Replace the Fluid inspected by your Hyundai dealer. Recommended brake fluid conforming to DOT 3 or DOT 4 specification should be used. The CAUTION:...
  • Page 150 Pressing with your to changes in resistance that mark the limits of it is not, have it inspected by your Hyundai finger, you should not be able to deflect this belt the freeplay. If the freeplay is greater than dealer and adjusted or repaired if necessary.
  • Page 151 If the brake pedal clearance is not other parts of the engine. After a belt is re- ed by your Hyundai dealer and adjusted or within the limits specified in the illustration, have placed, the new belt should be adjusted again...
  • Page 152 If the fuse has burned out, you other parts of the engine. have a Hyundai dealer determine the cause, will see that the metal strip inside the fuse has repair the system and replace the fusible link.
  • Page 153 If it is not, have the fuse problem in the electrical circuit. If you re- WARNING: clip repaired or replaced by a Hyundai dealer. place a fuse and it blows as soon as the Batteries can be dangerous! When working...
  • Page 154 DO-IT-YOURSELF MAINTENANCE o If you swallow battery fluid, drink a large G220A01A-AAT G230A03A-GAT CHECKING ELECTRIC COOLING POWER STEERING FLUID LEVEL quantity of water or milk followed by milk of magnesia, eat a raw egg or drink vegetable FANS Gasoline engine oil.
  • Page 155 "ON", and that it goes off when the engine is fluid characteristic in extremely cold condi- started. tions. If in doubt, consult your nearest authorized HYUNDAI dealer. Recommended Fluid WARNING: Use PSF-3 type fluid Be sure to carefully wipe away any water...
  • Page 156 DO-IT-YOURSELF MAINTENANCE G270A02A-GAT 5. Push the bulb spring for removing the head- G290A01FC-GAT HEADLIGHT BULB HEADLIGHT AIMING ADJUSTMENT light bulb. Before performing aiming adjustment, make sure Replacement instructions: 6. Remove the protective cap from the replace- of the following. ment bulb and install the new bulb by match- ing the plastic base with the headlight hole.
  • Page 157 DO-IT-YOURSELF MAINTENANCE 5. Open the hood. If the vehicle has had front body repair and the 6. Draw the vertical line (through the center of headlight assembly has been replaced, the each headlight beam pattern) and the hori- headlight aiming should be checked using an zontal line (through the center of each head- aiming screen as shown in the illustration.
  • Page 158 DO-IT-YOURSELF MAINTENANCE G280A01FC-GAT HFC5006 Part Name Wattage Part Name Wattage Front Position Light High Mounted Rear Stop Light 60/55 License Plate Light Head Light (High/Low) Rear Fog Light (If installed) Front Fog Light (If installed) Luggage Compartment Light Front Turn Signal Light Rear Combination Turn Signal Light Side Repeater (If installed)
  • Page 159 DO-IT-YOURSELF MAINTENANCE G200C02FC-GAT FUSE PANEL DESCRIPTION Engine Compartment (GASOLINE) DESCRIPTION FUSE RATING PROTECTED COMPONENTS 120A Generator (A/CON, RR HTD, STOP, D/LOCK, HAZARD) Fuse Generator, Engine control relay, ECM Radiator fan relay Start relay, Ignition switch Blower relay P/WIN Power window relay COND Condenser fan relay #1 ABS control module, ABS bleeding connector...
  • Page 160 DO-IT-YOURSELF MAINTENANCE G200E01FC-GAT Engine Compartment (DIESEL) DESCRIPTION FUSE RATING PROTECTED COMPONENTS 100A Generator (A/CON, RR HTD, STOP, D/LOCK, HAZARD) Fuse Generator, Engine control relay, ECM Radiator fan relay Start relay, Ignition switch Blower relay P/WIN Power window relay COND Condenser fan relay #1 ABS control module, ABS bleeding connector ABS control module, ABS bleeding connector F/PUMP...
  • Page 161 DO-IT-YOURSELF MAINTENANCE G200D01FC-GAT Inner Panel DESCRIPTION FUSERATING PROTECTED COMPONENTS H/LP IND Head lamp indicator Defogger relay, Left(Right) outside mirror motor, HTD IND Rear window motor A/CON A/C Switch RR HTD Defogger relay STOP Stop lamp switch, Power window relay D/LOCK Door lock(unlock) relay, ETACM, Sunroof relay HAZARD Burglar alarm relay, Hazard relay...

  • Page 162: Emission Control Systems

    When the engine is tained by an authorized Hyundai dealer in ac- running, the fuel vapors absorbed in the canis- Catalytic Converter...
  • Page 163 Your Hyundai should not be either pushed or pulled to get it started. This can cause the catalytic converter to overload. o Take care not to stop your Hyundai over any combustible material such as grass, paper, leaves or rags. As these materials could come in contact with the catalytic converter and could cause a fire.

  • Page 164: Consumer Information

    These pressures were chosen to provide the I020A01A-AAT most satisfactory combination of ride comfort, TIRE INFORMATION tire wear and stability under normal conditions. The tires supplied on your new Hyundai are chosen to provide the best performance for normal driving.
  • Page 165 Tire chains, if necessary should be installed on by a Hyundai dealer so the cause may be o Check the pressure of your spare tire corrected. the front wheels. Be sure that the chains are...
  • Page 166 A tire that is out of balance may affect handling handling characteristics that may cause 1.6 mm (0.06 in.) and tire wear. The tires on your Hyundai were death, serious injury or property dam- balanced before the car was delivered but may age.

  • Page 167: Vehicle Specifications

    VEHICLE SPECIFICATIONS J030A01FC-GAT 9. VEHICLE SPECIFICATIONS TIRE Standard 185/65 R14 Option 195/55 R15 J010A01FC-GAT MEASUREMENT mm (in.) 205/55 R15 (1.8 DOHC only) Overall length 4,025(158.4) Overall width 1,740(68.5) J030B01FC-GAT Overall height (unladen) SPARE TIRE 1,635(64.3) *1,685(66.3) Standard Temporary Wheel base 2,600(102.3) Option Full size...
  • Page 168 VEHICLE SPECIFICATIONS J070A03FC-GAT ENGINE ITEMS DIESEL GASOLINE Engine Type 1.5 3Cylinder in-line SOHC 1.6/1.8 4Cylinder in-line DOHC Idle Speed (RPM) 800 ± 100 A/CON OFF 800 ± 100 (1.6L), 750 ± 100 (1.8 L) 800 ± 100 A/CON ON 800 ± 100 (1.6L), 800 ± 100 (1.8 L) Spark Plug BKR5ES-11 Unleaded...
  • Page 169 MAX. 1L / 1,500 Km Severe driving condition MAX. 1L / 1,000 Km Transaxle Manual HYUNDAI GENUINE PARTS MTF 75W/90 (API GL-4) 2.15 (2.3 us. qts., 1.86 Imp. qts) 6.1 (6.4 us. qts., 5.3 Imp.qts) (1.6 DOHC) DIAMOND ATF SP-III, SK ATF SP-III Auto 6.7 (7.0 us.

  • Page 170: Index

    Corrosion Protection Checking the brakes ..............6-15 Cleaning the interior ................ 4-3 Fluid ....................6-16 Protecting your Hyundai from corrosion ......... 4-1 Pedal clearance ................6-18 Washing and waxing ............... 4-2 Pedal free play ................6-18 Practices ................2-7 ~ 2-8 Brake Pad Wear Warning Sound .............
  • Page 171 INDEX Driving Economical driving ................ 2-10 General Checks .................. 6-4 Glove box ..................1-46 Smooth cornering ................2-10 Winter driving ................2-10 Hazard Warning System ..............1-40 Emissions Control Systems ..............7-1 Headlight Aiming Adjustment ............6-23 Engine Headlight Bulb ................... 6-23 Before starting the engine ...............
  • Page 172 INDEX Keys ....................1-2 Rear Fog Audible Warning Sound ............ 1-35 If you lose your keys ..............3-10 Rear Seat Positions ..................2-2 Adjustable headrests ..............1-11 Adjusting seatback angle .............. 1-11 Adjusting seat forward and rearward ..........1-11 Light Bulb Replacement ............6-22 ~ 6-23 Arm Rest ..................
  • Page 173 INDEX Sunroof ................... 1-44 ~ 1-45 Sunshade ..................1-44 Under Tray ..................1-10 Sun Visor ..................1-54 Vehicle Identification Number (VIN) ............ 8-1 Tail Gate ................... 1-51 Vehicle Specification ................9-1 Tail Gate Wiper And Washer Switch ..........1-40 Ventilation Tachometer ................
  • Page 174 SA000A1-E This Owners Manual should be considered a part of the car and remain with it when it is sold for the use of the next owner. OWNER I.D. ORIGINAL: NAME: ADDRESS: STREET: TOWN: COUNTRY: P.CODE: DATE OF SALE: SUBSEQUENT: NAME: ADDRESS: STREET:...
  • Page 175 This manual applies to all markets and includes descriptions and explanations of optional as well as standard equipment. As a result, some of the equipment operating descriptions referred to may not apply to the particular vehicle with which this manual is supplied. Please refer to the nearest franchised Hyundai dealer for information regarding current standard and optional equipment levels.
  • Page 176 It is recommended that all maintenance operations and repairs are entrusted to a franchised Hyundai dealer to ensure that the latest repair methods, specialized tooling and genuine Hyundai parts are used to ensure the continued reliability and safety of the vehicle.
  • Page 177 Page 9-3 in the Vehicle Specifications section of the Owner's Manual. Copyright 2002 Hyundai Motor Company. All rights reserved. No part of this publication may be reproduced, stored in any retrieval system or transmitted in any form or by any means without the prior written permission of Hyundai Motor Company.
  • Page 178 It is possible for incorrectly installed two way radio equipment including mobile telephones to adversely affect these systems. Before radio equipment of this kind is installed, please contact your Hyundai dealer for recommendation regarding the suitability of the particular radio equipment concerned and the recommended method of installation and equip- ment location.
  • Page 179 SA070A1-F SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as WARNING, CAUTION and NOTE. These titles indicate the following: WARNING: This indicates that a condition may result in harm or injury to you or other persons if the warning is not heeded.
  • Page 180 TABLE OF CONTENTS SECTION PAGE 1. CONTROLS AND EQUIPMENT ................ 1-1 2. DRIVING YOUR HYUNDAI ................2-1 3. IN CASE OF EMERGENCY ................3-1 4. APPEARANCE CARE ..................4-1 5. VEHICLE MAINTENANCE REQUIREMENTS ..........5-1 6. OWNER MAINTENANCE ................. 6-1 7.
  • Page 181 1. What are Hyundai Genuine Parts? by Hyundai Motor Company. Hyundai Genuine Parts are the same parts used by Hyundai Motor Company to man- 3. How can you tell if you are purchasing ufacture vehicles.

  • Page 182: Controls And Equipment

    Diesel fuel of 52 to 54 cetane is used in with detergent additives, which help to pre- Hyundai vehicle. If two types of diesel fuel are vent deposit formation in the engine. These available, use summer or winter fuel properly...
  • Page 183 CONTROLS AND EQUIPMENT B020A01FC-EAT B020B01FC-EAT 6SB035A1-FE RUNNING IN (Gasoline Engine) RUNNING IN (Diesel Engine) IMMOBILIZER SYSTEM The longevity and performance of the vehicle The longevity and performance of the vehicle The immobilizer system is an anti-theft de- are greatly affected by the care exercised are greatly affected by the care exercised vice, designed to prevent and deter automo- during the first 1,000 miles of motoring.
  • Page 184 New keys are available from any Hyundai dealer by quoting the rel- evant key number. In the interest of security, the metal tag at-...
  • Page 185 CONTROLS AND EQUIPMENT B040C01FC-GAT SB040D1-F SB040F1-E Locking From the Outside Locking from the Inside CHILD-PROOF REAR DOOR LOCK LOCK UNLOCK HFC2009-D B040D01FC-D HFC2006-D The rear doors are fitted with child proof locks To lock the doors from inside, simply close the The doors can be locked without a key.
  • Page 186 CONTROLS AND EQUIPMENT SB040G1-F B040H02L-EAT Park the car and stop the engine. Arm the CENTRAL DOOR LOCK Speed Sensing Auto Door Locking system as described below. (Not all models) (Not all models) 1) Remove the ignition key from the ignition When the speed of the vehicle keeps above switch.
  • Page 187 CONTROLS AND EQUIPMENT B070C01FC-EAT The system will be disarmed when the driver's B070F01A-EAT Alarm Stage Keyless Entry System (Not all models) or passenger's door is unlocked by depress- The alarm will be activated if any of the ing the "UNLOCK" button on the transmitter. Locking doors following occurs while the car is parked and 1.
  • Page 188 CONTROLS AND EQUIPMENT Replacement instructions: SB060A1-E B060A01E-EAT DOOR WINDOWS POWER WINDOWS (Not all models) Close Open Screwdriver MSO-0048-1 B060A01FC-D B050A01FC-D 1. Separate the case with a blade screw- The front door windows may be opened or The power windows operate when the ignition driver as shown in the illustration.
  • Page 189 CONTROLS AND EQUIPMENT window will stop and cannot be opened The front seat rake adjustment is performed or closed. by raising the lever at the front of the seat 3) Do not leave children alone in the car. base and sliding the seat to the desired posi- Always remove the ignition key for their tion.
  • Page 190 CONTROLS AND EQUIPMENT SB070D2-E SB070E1-E SB070F1-F Lumbar Support Adjustment Seat Cushion Height Adjustment Head Restraint Adjustment (Not all models) (Driver's seat only) (Not all models) (Driver's seat only) Lock knob HFC2028-D HFC2027-D HFC2026-D To raise the head restraint, pull it up. To lower Some models are fitted with adjustable driver To raise or lower the front part of the seat it, push it down while pressing the lock knob.
  • Page 191 CONTROLS AND EQUIPMENT B080G01FC-EAT B080H01FC-GAT B080I01FC-BAT UNDER TRAY (Not all models) REAR SEAT Adjusting Seatback Angle Seat Rake Adjustment Seatback folding lever HFC2059-D HFC2061 The tray is located under the front passenger HFC2060 To recline the seatback, push the seatback seat.
  • Page 192 CONTROLS AND EQUIPMENT SB070D2-E B090B01FC-GAT Head Restraint Adjustment Folding Rear Seatback and Seat Cushion For greater convenience, the entire seatback and seat cushion may be folded down and up. Lock Knob Seat cushion release lever HFC2075 4. Pull the seat cushion release lever up- B090A01FC ward, then fold up the seat cushion.
  • Page 193 CONTROLS AND EQUIPMENT o Objects should not extend higher than 5. To secure the seat, hook the securing During mild weather or under conditions where strap under the seat cushion to the head- the top of the front seatbacks. This the operation of the seat warmer is not needed, rest stay of front driver and passenger could allow cargo to slide forward and...
  • Page 194 Additional questions concerning seat Never allow children to ride in the front pas- will be unable to afford maximum protection if belt operation should be directed to a Hyundai senger seat. the front seats are at or near the fully reclined position.
  • Page 195 CONTROLS AND EQUIPMENT WARNING: B170A04A-EAT of movement whilst the belt is being worn. HEIGHT ADJUSTABLE FRONT SEAT o The height adjuster must be in the locked However, in the event of rapid deceleration or SHOULDER BELT (Not all models) position when the vehicle is moving. impact, the belt mechanism will automatically o The misadjustment of height of the lock.
  • Page 196 CONTROLS AND EQUIPMENT This could result of death, serious injury or ZB090W2-A ZB090X2-A SEAT BELTS (2-Point Static Type) Adjusting Your Seat Belt property damage. Both arms should not be (Rear Seat Centre) under or over the belt. Rather, one should be over and the other under, as shown in the To Fasten Your Seat Belt illustration.
  • Page 197 CONTROLS AND EQUIPMENT o Since a safety belt or child restraint ZB090Y1-A B230A03P-EAT To Release the Seat Belt CHILD RESTRAINT SYSTEM system can become very hot if it is left Children riding in the car should sit in the rear in a closed vehicle, be sure to check the seat and must always be properly restrained seat cover and buckles before placing a...
  • Page 198 CONTROLS AND EQUIPMENT o Never use an infant carrier or child safety ommended that the seat be placed in the Three Child Restraint Anchorage Fitting Pack- seat that "hooks" over a seatback; it vehicle's rear seat since this can make an ages are located where shown on the vertical may not provide adequate security in an important contribution to safety.
  • Page 199 The improper increased load attachments that connect to two ISOFIX an- immediately by your authorized Hyundai may cause the anchorage points or chors at specific seating positions in your ve- dealer.
  • Page 200 Child Seat Restraint Suitability For Seat Pre-Tensioner Seat Belt ISOFIX Anchor Position Your Hyundai vehicle is equipped with driver's Use child safety seats that have been offi- and front passenger's pre-tensioner seat belts. cially approved and are appropriate for your The purpose of the pre-tensioner is to make children.
  • Page 201 CAUTION: pre-tensioner seat belts yourself. This o Because the sensor that activates the 1. SRS airbag warning light must be done by an authorized Hyundai SRS airbag is connected with the pre- 2. Seat belt pre-tensioner assembly dealer. tensioner seat belt, the SRS airbag warn- 3.
  • Page 202 In addition, airbags to likely cause significant injury to the will not normally deploy in frontal Your Hyundai is equipped with a Supplemen- vehicle occupants. crashes below the deployment thresh- o The SRS is designed to deploy the tal Restraint (Airbag) System.
  • Page 203 CONTROLS AND EQUIPMENT B240B03A-DAT the SRSCM detects a considerable impact to SRS Components and Functions the front of the vehicle, it will automatically deploy the airbags. Passenger's Airbag SSA1110C The SRS service reminder indicator (SRI) on SSA1110B the instrument panel will blink for about 6 The SRS consists of the following compo- seconds after the ignition key is turned to the B240B04FC-D...
  • Page 204 B990B02Y YR10353A the SRS SRI does not come on, or Your Hyundai is equipped with a side impact continuously remains on, after flashing After complete inflation, the airbag immedi- airbag in each front seat. The purpose of the for about 6 seconds when the ignition...
  • Page 205 The entire SRS system must be upright position with the seat belt prop- child could be severely injured by an inspected by an authorized Hyundai dealer in erly fastened. The driver's hands should airbag deployment in case of an accident.
  • Page 206 SRS performance o If the airbags inflate, they must be re- and lead to unexpected injury. placed by an authorized Hyundai dealer. o Do not tamper with or disconnect SRS wiring, or other components of the SRS system.
  • Page 207 CONTROLS AND EQUIPMENT B250A01FC-EAT INSTRUMENTS AND CONTROLS 1. Passenger's Side Drink Holder 9 1011 2. Passenger's Airbag 3. Accessory Tray 4. Heating/Air Conditioning Control Panel (Not all models) 5. Hazard Warning Light 6. Instrument Cluster 7. Windscreen Wiper/Washer Switch 8. Horn and Driver's Airbag 9.
  • Page 208 CONTROLS AND EQUIPMENT B260A01FC-EAT INSTRUMENT CLUSTER AND INDICATOR (GASOLINE ENGINE) 1. Temperature Gauge 2. Tachometer 3. Speedometer 4. Digital Clock 5. Odometer/Trip Odometer/Trip Computer (Not all models) 6. Fuel Gauge 7. Turn Signal Indicator Light 8. Automatic Transaxle Position Indicator Light (Auto T/A only) 9.
  • Page 209 CONTROLS AND EQUIPMENT B260B01FC-EAT INSTRUMENT CLUSTER AND INDICATOR (DIESEL ENGINE) 1. Temperature Gauge 2. Tachometer 3. Speedometer 4. Digital Clock 5. Odometer/Trip Odometer/Trip Computer (Not all models) 6. Fuel Gauge 7. Fuel Filter Warning Light 8. Turn Signal Indicator Light 9.
  • Page 210 If this occurs, have your vehicle checked by mal operation and the cause is not an insuffi- your Hyundai dealer as soon as possible. The cient oil level, or the light fails to illuminate normal braking system will still be operational, when the ignition is turned "on", contact the...
  • Page 211 If the light illuminates whilst the vehicle is be refuelled. If the vehicle is driven for an vice of the nearest Hyundai dealer must be being driven, stop the vehicle as soon as it is extended period with the low fuel warning light sought before the vehicle is driven again.
  • Page 212 If the engine were not started 10 seconds (Not all models) rized Hyundai dealer and have the system after the preheating is completed, turn the If the vehicle is driven at 6mph(10km/h) for checked.
  • Page 213 If the cause of the overheating can- other than an approximate indication of not be readily established, the assistance of a the fuel level and is unsuitable for the Hyundai dealer should be sought. purposes of calculating fuel consumption B300A01FC figures.
  • Page 214 CONTROLS AND EQUIPMENT ated beyond the beginning of this zone or SB215F1-E Function of digital odometer/ TACHOMETER serious engine damage may result. Trip odometer Gasoline engine Pushing in the reset switch when the ignition switch is turned "ON" will display the following B310B01FC-EAT sequence: ODOMETER/TRIP ODOMETER...
  • Page 215 To shift from TRIP A to TRIP B, press the by your authorized Hyundai dealer. o Pushing in the reset switch changes the reset switch. When pressed for 1 second, it o The distance to empty can differ from display as follows;...
  • Page 216 CONTROLS AND EQUIPMENT SB220B1-E B340C01FC-EAT 3. DRIVE TIME Lane Change Signal LIGHTING SWITCH Drive time symbol Drive time HFC2054 o This mode indicates the drive time trav- elled since the last drive time reset. o Pressing the reset switch for more than 1 second, when the drive time is being dis- B340C01FC-D B340B01FC-D...
  • Page 217 CONTROLS AND EQUIPMENT SB220D1-E SB230A1-E B350B01O-EAT HIGH AND LOW BEAM WINDSCREEN WIPER/WASHER Windscreen Washer Operation To turn on the headlight high beams, push the SWITCH lever forward (away from you). For low beams, pull the lever back (toward you). The appropri- ate headlight beam indicator light will come on at the same time.
  • Page 218 CONTROLS AND EQUIPMENT To use the intermittent wiper feature, place SB240A1-E Mist Wiper Operation HAZARD WARNING SYSTEM the wiper switch in the "INT" position. With the switch in this position, the interval between wipes can be varied from approximately 1 to 18 seconds by turning the interval adjuster barrel.
  • Page 219 CONTROLS AND EQUIPMENT NOTE: SB250A1-E B360A01Y-GAT HEATED REAR WINDOW REAR FOG LIGHT SWITCH The engine must be running for the heated rear window to operate. B360B01FC-EAT FRONT FOG LIGHT SWITCH (Not all models) B360A01FC-1 HFC2080-D To operate the heated rear window depress To turn on the rear fog lights, push the switch.
  • Page 220 When this is done: If it is necessary to replace the cigarette lighter, use only a genuine Hyundai replace- Pressing "R" between 10 : 30 and 11 : 29 ment part. changes the readout to 11 : 00.
  • Page 221 CONTROLS AND EQUIPMENT B450A01FC-EAT B450B01FC-EAT B611A01FC-EAT DRINK HOLDER (Not all models) REAR SEAT DRINK HOLDER REAR SEAT ARM REST (Not all models) (Not all models) Driver's Passenger's HFC2097-D The drink holder is used for holding cups or B610A01FC HFC2098 cans. This arm rest is located in the centre of the The drink holder is located on the rear main To use the passenger's drink holder, push the...
  • Page 222 CONTROLS AND EQUIPMENT B340G01FC-EAT The electrically operated sunroof may be used Switch HEADLIGHT LEVELING DEVICE Loading Condition only whilst the ignition switch is at the "ON" Position position. The sunroof is equipped with a sun- SYSTEM Driver only shade which may be used whilst the sunroof is at the closed position to obscure incoming Driver + front passenger light.
  • Page 223 CONTROLS AND EQUIPMENT CAUTION: The sunroof can be tilted and closed by de- o Do not open the sunroof in severe cold pressing the button indicated. Release the temperature or when it is covered with button when the sunroof reaches the up posi- ice or snow.
  • Page 224 CONTROLS AND EQUIPMENT B480A01E-EAT SB340B1-E B491A02F-EAT INTERIOR LIGHT Interior Light SPECTACLE CASE (Not all models) Map Light Without Sunroof With Sunroof With Sunroof Without Sunroof HXDOM241 B490A01E B490B01E The spectacle case is located on the front B480A01E B480B01E The interior courtesy light has a button of overhead console.
  • Page 225 CONTROLS AND EQUIPMENT B500A01A-EAT B500B02E-GAT B510B01FC-EAT GLOVE BOX MULTI BOX EXTERIOR REAR VIEW MIRROR Electric Type HFC2058-D HFC2095-D HFC2011-D The multi box may be opened by pulling it out WARNING: by its grip. To avoid the possibility of injury, the glove The outside rear view mirror can be adjusted It is used for storing small commodities.
  • Page 226 CONTROLS AND EQUIPMENT B510D01HP-EAT SB360C1-F FOLDING THE OUTSIDE REAR VIEW OUTSIDE REARVIEW MIRROR HEATER MIRRORS (Not all models) B510D01E CAUTION: o Do not leave the switch on for an B510C01FC-D unneces-sary length of time. HFC2080-D To fold the outside rear view mirrors, push o Scraping ice from the mirror face could The outside rearview mirror heater is actuated them towards the rear.
  • Page 227 CONTROLS AND EQUIPMENT SB370A1-E SB380A1-E B550A01S-DAT INTERIOR REAR VIEW MIRROR PARKING BRAKE HIGH-MOUNTED REAR STOP LIGHT B520A01E B530A01FC-D B550A01FC In addition to the lower-mounted rear stop- The parking brake must always be set when The interior mirror is of the day/night type to lights on either side of the car, the high the vehicle is to be left unattended.
  • Page 228 CAUTION: an accident or a sudden stop, the fold-up Do not use electric accessories or equip- tray should be place its original position ment other than the Hyundai genuine while the vehicle is moving. parts in the socket. 1- 47...
  • Page 229 CONTROLS AND EQUIPMENT B570A01FC-EAT SB440A1-E BONNET RELEASE REMOTE FUEL FILLER LID RELEASE (Not all models) HFC2019 CAUTION: HFC2018-D Ensure that the bonnet prop has been HFC2015-D Pull the release lever inside the vehicle to removed prior to closing the bonnet. Al- The fuel filler lid may be opened from inside unlatch the bonnet.
  • Page 230 See additional warnings concerning placement, only a Genuine Hyundai re- exhaust gases on page 2-1. placement part should be used to prevent o The tail gate can be locked or unlocked fuel leakage.
  • Page 231 CONTROLS AND EQUIPMENT B650A01FC-DAT If your Hyundai has a roof rack, you can load B560B01O-GAT CARGO AREA COVER Auto Fuel Cut Switch (Gasoline Engine) things on top of your vehicle. Crossrails and fixing components to adapt the roof rack on your vehicle may be obtained from an autho- rized Hyundai dealer.
  • Page 232 CONTROLS AND EQUIPMENT B580A01E-EAT SB520A1-F B610A01S-DAT SUN-VISOR STEERING WHEEL TILT LEVER HORN (With Airbag) Vanity mirror HFC2094-D HFC2099 HFC2041 Sun visors are fitted to both the driver and Press the pad of the steering wheel to sound To adjust the steering wheel: passenger side of the vehicle.
  • Page 233 CONTROLS AND EQUIPMENT B710A01Y-EAT B710A01S-AAT Heating and Cooling Control (Not all models) VENTILATION To operate the ventilation system: o Set the air intake control to "Fresh" mode o To direct all intake air to the dashboard vents, set the air flow control to "Face". o Adjust the fan speed control to the desired speed.
  • Page 234 CONTROLS AND EQUIPMENT B670A01FC-EAT B670B01A-AAT B670C02FC-EAT HEATING AND VENTILATION Fan Speed Control (Blower Control) Air Intake Control ROTARY TYPE (Not all models) HFC2067 HFC2065 B670A01FC This is used to turn the blower fan on or off This is used to select fresh outside air or and to select the fan speed.
  • Page 235 CONTROLS AND EQUIPMENT NOTE: o It should be noted that prolonged op- eration of the heating in "Recirculation" mode will increase to fogging of the windscreen and side windows and the air within the passenger compartment will become stale. In addition, prolonged use of the air conditioning with the "Recirculation"...
  • Page 236 CONTROLS AND EQUIPMENT This is used to turn the heating system on and Your Hyundai is equipped with bi-level heating off and to select the degree of heating de- controls. This makes it possible to have cooler sired. air from the dashboard vents and warmer air from the floor outlets at the same time.
  • Page 237 CONTROLS AND EQUIPMENT To remove interior fog on the windscreen; NOTE: B740A01S-EAT AIR CONDITIONING SYSTEM o Set the air flow control to the defrost ( When the A/C is operated continuously on position. (The A/C will turn on automati- the floor-defrost level ( ) or defrost level (Not all models) cally and "Fresh"...
  • Page 238 CONTROLS AND EQUIPMENT B740B01FC-GAT B740C01FC-GAT B740D01A-AAT Air Conditioning Operation Dehumidified Heating Operation Tips Cooling o If the interior of the car is hot when you first get in, open the windows for a few minutes to expel the hot air. o When you are using the air conditioning system, keep all windows closed to keep hot air out.
  • Page 239 CONTROLS AND EQUIPMENT CAUTION: B760A01FC-EAT POLLEN FILTER o Replace the filter every 10,000 miles or once a year. If the car is being driven in (IN FRONT OF BLOWER UNIT) severe conditions such as dusty, rough Outside air Inside air roads, more frequent air filter inspec- tions and changes are required.
  • Page 240 CONTROLS AND EQUIPMENT B750A02A-AAT AM reception FM radio station STEREO SOUND SYSTEM Ionosphere Unobstructed How Car Audio Works area FM reception Ionosphere Mountains Buildings Iron bridges SSAR011A Obstructed area SSAR012A AM broadcasts can be received at greater FM broadcasts are transmitted at high fre- distances than FM broadcasts.
  • Page 241 CONTROLS AND EQUIPMENT B750B02Y-AAT Using a cellular phone or a two-way radio When a cellular phone is used inside the vehicle, noise may be produced from the audio equipment. This does not mean that something is wrong with the audio equipment. In such a case, use the cellular phone at a place as far as possible from the audio equip- ment.
  • Page 242 CONTROLS AND EQUIPMENT B870D01FC-GAT ANTENNA Roof Antenna HFC2100 Your car uses a roof antenna to receive both AM and FM broadcast signals. This antenna is a removable type. To remove the antenna, turn the antenna counterclock- wise. To install the antenna, turn the antenna clockwise.

  • Page 243: Driving Your Hyundai

    DRIVING YOUR HYUNDAI SC000A1-E 2. DRIVING YOUR HYUNDAI SC020A1-E WARNING: ENGINE EXHAUST CAN BE DANGEROUS! Engine exhaust gases are potentially lethal. If at any time engine exhaust gas is detected within the passenger compartment, move the vehicle to an open area and open all windows.
  • Page 244 To Start the Engine The engine must never be turned off and o If your Hyundai is equipped with a manual the key removed from the ignition key 1. Look around the vehicle to be sure there transaxle, place the shift lever in neutral...
  • Page 245 DRIVING YOUR HYUNDAI celerator pedal whilst starting the engine. should not be left at this position since the SC060A1-E STARTING THE GASOLINE ENGINE battery will become discharged and damage Allow the engine to idle for 20 seconds or to the ignition system may also result. For so before driving the vehicle.
  • Page 246 DRIVING YOUR HYUNDAI NOTE: C050B02S-GAT This idle time will allow the turbo charger to NORMAL CONDITIONS If the engine were not started 10 seconds cool prior to shutting the engine off. The Starting Procedure: after the preheating is completed, turn the WARNING: 1.
  • Page 247 1 or R(Reverse), o Do not attempt to engage reverse gear nance services are performed by a Hyundai put the shift lever in N(Neutral) position when the car is in motion. dealer at the time and/or mileage intervals and release the clutch.
  • Page 248 C090A01FC-D 1. Turn the ignition key to the "ACC" position. The shift points as shown above are recom- The highly efficient Hyundai automatic 2. Simultaneously push and turn the ignition mended for optimum fuel economy and per- transaxle has four forward speeds and one key counterclockwise from the "ACC"...
  • Page 249 DRIVING YOUR HYUNDAI For optimum fuel economy, accelerate grad- DC110D1-E DC110G2-E o N (Neutral): o L (Low Gear): ually. The transaxle will automatically shift to the second, third and overdrive gears. With the selector in this position, no gear is...
  • Page 250 DRIVING YOUR HYUNDAI C090I02A-EAT o Always engage the parking brake when o If rapid acceleration is required, fully de- CAUTION: the vehicle is unattended, never use the press the accelerator pedal. In this condi- o Shift into "R" and "P" only when the "P"...
  • Page 251 "OFF". The transaxle will start o Use only genuine Hyundai replacement NOTE: from rest in first gear and upshift to second brake pads and shoes to ensure consis-...
  • Page 252 If the indicator does not illuminate, have it high speed driving or cornering. This could normal precautions for driving in inclem- checked by an authorized Hyundai dealer. endanger the safety of yourself or others. ent weather and on slippery driving sur- faces should be observed.
  • Page 253 DRIVING YOUR HYUNDAI SC150A1-F o Be sure that the wheels are aligned cor- o Don't "lug" or "over-rev" the engine. Lug- DRIVING FOR ECONOMY rectly. Improper alignment can result from ging is driving too slowly in too high a gear...
  • Page 254 DRIVING YOUR HYUNDAI NOTE: ZC170B1-E ZC170D1-E Electrical System Door Locks Never allow undiluted screen washer fluid Winter conditions impose severe demands Should the door lock mechanism become additive to spill upon the paintwork or use upon vehicle electrical systems, particularly...
  • Page 255 Running In has been completed. All checks relating to engine oil, transmission oil anticipate the change in characteristics and Hyundai MATRIX models are suited to tow- and tyres must be performed at each refuelling adjust the driving style in keeping with these ing trailers and caravans up to the limits to ensure maximum reliability and safety.
  • Page 256 DRIVING YOUR HYUNDAI o The maximum permissible static verti- will assist with braking performance when long down hill gradients are encountered. cal load on the coupling device : 52kg Improved acceleration performance will be Maximum Towable o The maximum permissible overhang of available by selecting "Overdrive Off","2", or...
  • Page 257 DRIVING YOUR HYUNDAI 5. Always secure items in the trailer to pre- 11.Avoid jerky starts, sudden acceleration or vent load shift while driving. sudden stops. 6. Check the condition and air pressure of all 12.Avoid sharp turns and rapid lane changes.

  • Page 258: In Case Of Emergency

    3. Check fuel line in the engine room. case of fuel injected derivatives, the fuel or"N" position. 4. If engine still refuses to start, call a Hyundai pump will not operate under tow start con- 2. Check the battery terminals and connec- dealer or seek other qualified assistance.
  • Page 259 IN CASE OF EMERGENCY with copious amounts of water and medi- ponents such as the Fuel Injection system SD030A1-E JUMP STARTING cal assistance sought. computer and the Automatic Transaxle computer. The battery must never be dis- 1. Ensure that the booster battery is 12 volt connected whilst the engine is running.
  • Page 260 (50 mph) is not recommended. subject to high pressure even after the a Hyundai dealer should be sought. 4. As the temporary spare tyre is specifically engine stopped. The fuel jet produced by...
  • Page 261 IN CASE OF EMERGENCY SD050A2-E 2. If the vehicle is creating a hazard and the D060K01FC-EAT SPARE WHEEL (Not all models) Wheel Cap (Not all models) road conditions do not permit the wheel to The spare wheel is stored under the luggage be changed safely, assistance should be compartment floor and is accessed from within sought.
  • Page 262 IN CASE OF EMERGENCY 4. Reinstall the wheel cap by fitting the boss of SD070D1-E The wheel nuts should be loosened slightly 2. Block the Wheel the wheel cap in the groove of the wheel, before raising the car. To loosen the nuts, turn hitting the centre of the wheel cap with hand.
  • Page 263 IN CASE OF EMERGENCY WARNING: SD070G1-E SD070H1-E 5. Raising the Car 6. Changing Wheels It is important that the faces of the wheel and hub are clean prior to installing the wheel. The prescence of dirt or other mat- ter in the wheel or hub faces could result in the wheel nuts becoming loose whilst the Wrench bar vehicle is being driven.
  • Page 264 IN CASE OF EMERGENCY SD070J1-E SD070K1-E SD080A1-E 8. Lower Vehicle and Tighten Nuts AFTER CHANGING WHEELS VEHICLE TOWING OR RECOVERY D080A01FC o OK FOR AUTOMATIC OR MANUAL TRANSAXLE EQUIPPED VEHICLE D060B01FC D060I01FC-D The pressure of the spare tyre should be Lower the car to the ground turning the wheel CAUTION: checked at the first available opportunity.
  • Page 265 IN CASE OF EMERGENCY o If a suspended tow is being given to the SD090A1-E Manual Transaxle Vehicle rear, the ignition key must be at the "ACC" position since the steering lock is not designed to withstand the force required to hold the front wheels straight during the tow.

  • Page 266: Appearance Care

    By using the most advanced design and con- rectification to be made thus preventing corro- washing the underbody, the more vulnera- struction practices, every Hyundai is built to sion from becoming established and spreading ble areas such as wheel arches should be retain the original factory finish for many years.
  • Page 267 It is recommended SEAT BELTS the colour coat and exposing the under coat. that repairs are entrusted to a Hyundai dealer to Seat belts should be cleaned only with a mild ensure that replacement parts used are of the soap solution.

  • Page 268: Vehicle Maintenance Requirements

    Hyundai age alone. It is strongly recommended that dealer to ensure that the latest repair and the maintenance operations are performed by the factory-trained or distributor-trained tech- nicians at your Hyundai dealer because of the...
  • Page 269 VEHICLE MAINTENANCE REQUIREMENTS SF040A2-E SCHEDULED MAINTENANCE to a Hyundai dealer to ensure that the manufacturers recommended In order to ensure the continued safety, reliability and longevity of the vehicle, the following maintenance service operations should be per- procedures are employed and that only genuine Hyundai replacement parts are used.
  • Page 270 VEHICLE MAINTENANCE REQUIREMENTS F030D02B-EAT R :REPLACE I : INSPECT AND, AFTER INSPECTION, CLEAN, ADJUST, REPAIR OR REPLACE IF NECESSARY. MILES X 1,000 DESCRIPTION MONTHS ENGINE CONTROL SYSTEM MAINTENANCE (DIESEL) ENGINE OIL & FILTER (API Class: CF-4 or ABOVE) See Note(1) (ACEA Class: B4 or ABOVE) AIR CLEANER FILTER FUEL FILTER CARTRIDGE...
  • Page 271 VEHICLE MAINTENANCE REQUIREMENTS F030C01E-EAT R : REPLACE I : INSPECT AND, AFTER INSPECTION, CLEAN, ADJUST, REPAIR OR REPLACE IF NECESSARY MILES X 1,000 DESCRIPTION MONTHS GENERAL MAINTENANCE COOLING SYSTEM COOLANT GASOLINE ENGINE DIESEL ENGINE ENGINE COOLANT SPECIFIC GRAVITY MANUAL TRANSAXLE OIL AUTOMATIC TRANSAXLE FLUID BRAKE PIPES, HOSES, AND CONNECTIONS BRAKE FLUID...
  • Page 272 VEHICLE MAINTENANCE REQUIREMENTS F040A04E-EAT MAINTENANCE UNDER SEVERE USAGE CONDITIONS The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : REPLACE I : INSPECT AND, AFTER INSPECTION, CLEAN, ADJUST, REPAIR OR REPLACE IF NECESSARY MAINTENANCE DRIVING MAINTENANCE ITEM...
  • Page 273 VEHICLE MAINTENANCE REQUIREMENTS 6ZF060A1-A 6ZF060D2-A 6ZF060G1-A EXPLANATION OF SCHEDULED o Fuel lines, fuel hoses and o Vapour hose and fuel filler cap The vapour hose and fuel filler cap should be MAINTENANCE ITEMS connections inspected at those intervals specified in the Check the fuel lines, fuel hoses and connec- maintenance schedule.
  • Page 274 6ZF070G2-A o Air cleaner filter o Manual transaxle oil o Brake fluid A Genuine Hyundai air cleaner filter is recom- Inspect the manual transaxle oil according to Check brake fluid level in the brake fluid mended when filter is replaced.
  • Page 275 VEHICLE MAINTENANCE REQUIREMENTS 6ZF070L1-A 6ZF070P1-A o Suspension mounting bolts o Driveshafts and boots Check the suspension connections for loose- Check the drive shafts, boots and clamps for ness or damage. Retighten to the specified cracks, deterioration, or damage. Replace torque. any damaged parts and, if necessary, repack the grease.

  • Page 276: Owner Maintenance

    OWNER MAINTENANCE SG000A1-E 6. OWNER MAINTENANCE G010B01FC-EAT ENGINE COMPARTMENT (1.6 DOHC) CAUTION: When inspecting or servicing the engine, you should handle tools and other heavy objects carefully so that the plastic rocker cover of the engine is not damaged. HFC5001 9 10 1.
  • Page 277 OWNER MAINTENANCE G010C01FC-EAT ENGINE COMPARTMENT (1.8 DOHC) CAUTION: When inspecting or servicing the engine, you should handle tools and other heavy objects carefully so that the plastic rocker cover of the engine is not damaged. HFC003 9 10 5. Relay box 10.Radiator cap 1.
  • Page 278 OWNER MAINTENANCE G010E01FC-GAT ENGINE COMPARTMENT (DIESEL) G010E01FC-1 1. Air filter element 5. Relay box 9. Engine coolant reservoir 2. Engine oil filler cap 6. Power steering fluid reservoir 10.Battery 3. Brake fluid and clutch fluid reservoir 7. Engine oil level dipstick 11.Windscreen washer fluid reservoir cap 4.
  • Page 279 OWNER MAINTENANCE SG020B1-E G030A01FC-EAT A multi grade oil having a specification which DAILY OPERATING CHECKS ENGINE OIL meets A.P.I. specification of SG or above is The following items should be checked on a The correct engine oil level is of paramount recommended.
  • Page 280 OWNER MAINTENANCE The engine oil level should be checked with SG030D2-E ENGINE OIL REPLENISHMENT NOTE: the engine at normal operating temperature SAE 0W-30 oil is for extra cold zone and and the vehicle parked upon level ground. Gasoline engine to be restricted by driving condition and Prior to checking the level, the vehicle should dealing area.
  • Page 281 OWNER MAINTENANCE the level again, allow several minutes for the o The engine oil consumption is strongly Diesel engine oil to drain into the sump. Replace the oil filler effected by the viscosity and quality of oil, cap rotating it in a clockwise direction until engine rpm and driving condition etc.
  • Page 282 OWNER MAINTENANCE sites and garages for the disposal of used 4. When the oil has drained from the sump, Diesel engine replace the drain plug using a new washer oil and oil filters. If in doubt, contact the ensuring that the plug is not over tight- local authority for disposal instructions.
  • Page 283 6. Start the engine with the radiator cap still falls below the "LOW" mark on a regular basis removed and continue to add coolant as the despite being topped up, consult a Hyundai level decreases as air is expelled from the dealer.
  • Page 284 OWNER MAINTENANCE you are not injured by a rotating fan blade. As the engine coolant temperature decreas- es, the fan will automatically shut off. This is a normal condition. SG060A1-E SPARKING PLUG REPLACEMENT 0.039 ~ 0.043 in. (1.0 ~ 1.1 mm) SSA6060B SSA6061C 3.
  • Page 285 To ensure maximum filtration performance and continued engine performance, only genuine SSA6062A Hyundai replacements should be used. 5. Replace the plug lead ensuring that the cap is pushed firmly into place. Confirm HFC5003 G080A01A-EAT...
  • Page 286 Only smear the glass, replace them with genuine reservoir has a total capacity of 3 litres. those lubricants specified below should be Hyundai replacement. used in order to prevent gear shifting difficul- CAUTION: ties or transaxle damage.
  • Page 287 Remove the level plug Your Hyundai automatic transaxle is specially cised to prevent injury occurring through con- from the transaxle when lubricant should be- designed to operate with DIAMOND ATF SP-III tact with hot or rotating parts of the engine.
  • Page 288 Use extreme caution when working other than those listed below should be near the blades of the cooling fan so that entrusted to a Hyundai dealer. you are not injured by a rotating fan blade. As the engine coolant temperature de-...
  • Page 289 OWNER MAINTENANCE SG130A1-C Ensure that the clutch fluid level is always Diesel engine CHECKING THE CLUTCH FLUID between the "MAX" and "MIN" level markings on the fluid reservoir. Fill as required. Fluid To Check the Clutch Fluid loss indicates a leak in the clutch system Gasoline engine which should be inspected and repaired im- mediately.
  • Page 290 OWNER MAINTENANCE SG140A1-E pulleys. Adjustment of the belt should be SG150A1-E AIR CONDITIONING SYSTEM STEERING WHEEL FREEPLAY entrusted to a Hyundai dealer. MAINTENANCE Condenser SG140C1-E Ensure that the condenser is periodically Checking the Refrigerant inspected and that accumulations of dirt, dead 1.
  • Page 291 490 N applied to the pedal. If either value is incorrect, the necessary adjustment should be performed by a Hyundai dealer. Pedal to floor clearance: 1.97 in. (50 6-16...
  • Page 292 The circuit necting the circuit will create a potential fire should be checked by a Hyundai dealer at the hazard. first available opportunity. D010B01FC...
  • Page 293 OWNER MAINTENANCE SG220A1-E WARNING: Diesel engine ELECTRIC COOLING FANS Motor vehicle batteries contain sulphuric WARNING: acid which is corrosive and poisonous. Hy- The cooling fan is controlled by engine drogen gas is emitted from the battery which coolant temperature and may sometimes is explosive when combined with oxygen.
  • Page 294 "ON", and that it goes off when the engine is started. If in doubt, consult your nearest authorized HYUNDAI dealer. WARNING: Be sure to carefully wipe away any water drained out in this manner, because the...
  • Page 295 OWNER MAINTENANCE the bulb only when installed in a head- base in the back of the headlight. Vertical Aiming 4. Remove the dust cover. light. Replace the headlight if damaged or Horizontal Aiming cracked. Keep the bulb out of the reach of 5.
  • Page 296 OWNER MAINTENANCE SPECIFICATIONS: G290B01FC-EAT Adjustment After Headlight Assembly Replacement "H" Horizontal centre line of headlights from Vertical ground. Horizontal line line : 26.8 in.(656 mm) "P" 1.18 in. (30mm) "W" 0.59 in. (15mm) Distance between each headlight centre. : 47.7 in. (1,164 mm) Cut-off line "L"...
  • Page 297 OWNER MAINTENANCE G280A01FC-EAT HFC5006-D Part Name Wattage Part Name Wattage Front Position Light High Mounted Rear Stop Light Head Light (High/Low) 60/55 Rear Fog Light Front Fog Light (Not all models) License Plate Light Luggage Compartment Light Front Turn Signal Light Rear Combination Turn Signal Light Side Repeater...
  • Page 298 OWNER MAINTENANCE G200C01FC-GAT FUSE PANEL DESCRIPTION Engine Compartment (GASOLINE) DESCRIPTION FUSE RATING PROTECTED COMPONENTS 120A Generator (A/CON, RR HTD, STOP, D/LOCK, HAZARD) Fuse Generator, Engine control relay, ECM Radiator fan relay Start relay, Ignition switch Blower relay P/WIN Power window relay COND Condenser fan relay #1 ABS control module, ABS bleeding connector...
  • Page 299 OWNER MAINTENANCE G200E01FC-GAT Engine Compartment (DIESEL) DESCRIPTION FUSE RATING PROTECTED COMPONENTS 100A Generator (A/CON, RR HTD, STOP, D/LOCK, HAZARD) Fuse Generator, Engine control relay, ECM Radiator fan relay Start relay, Ignition switch Blower relay Power window relay P/WIN COND Condenser fan relay #1 ABS control module, ABS bleeding connector ABS control module, ABS bleeding connector F/PUMP...
  • Page 300 OWNER MAINTENANCE G200D01FC-GAT Inner Panel DESCRIPTION FUSE RATING PROTECTED COMPONENTS H/LP IND Head lamp indicator Defogger relay, Left(Right) outside mirror motor, HTD IND Rear window motor A/CON A/C Switch RR HTD Defogger relay STOP Stop lamp switch, Power window relay D/LOCK Door lock(unlock) relay, ETACM, Sunroof relay HAZARD...

  • Page 301: Emission Control System

    The purge control solenoid valve is controlled recommended that the vehicle is inspected and by the ECU; when the engine coolant tempera- maintained by an authorized Hyundai dealer in ture is low or the engine is idling, the purge accordance with the maintenance schedule in...
  • Page 302 (Note, it is ; For a diesel engine impossible to push or tow start a Hyundai All Hyundai vehicles are equipped with oxida- model equipped with fuel injection since the tion type catalytic converter to reduce the car-...

  • Page 303: Consumer Information

    CONSUMER INFORMATION SI010B1-E I030A01FC-EAT SI000A1-E Engine Number TYRE PRESSURES 8. CONSUMER Gasoline engine INFORMATION I010A01FC-EAT VEHICLE IDENTIFICATION NUMBER (VIN) I030A01FC-D EADA010C In modern high-speed motoring, correct tyre Diesel engine pressures are vitally important. Incorrect tyre pressures can affect vehicle safety by caus- ing reduced adhesion, steering response and tyre failure through overheating.
  • Page 304 CONSUMER INFORMATION NOTE: Tyre pressures should be increased by 3 psi I060A01FC-EAT TYRE ROTATION when the vehicle is driven fully laden or under o Do not use the temporary spare tyre conditions of sustained high speed motoring. for tyre rotation. o Aluminium wheels which are not sup- plied as Original Equipment should SI030A2-E...
  • Page 305 TYRE REPLACEMENT WHEEL REPLACEMENT The original wheels may only be replaced with 0.06 in.(1.6 mm) Hyundai Approved wheels. WARNING: Driving on worn or defective tyres is dan- gerous. Worn tyres may cause loss of steer- ing control and a serious deterioration of braking efficiency.

  • Page 306: Vehicle Specifications

    VEHICLE SPECIFICATIONS J030A01FC-DAT SJ000A1-F TYRE 9. VEHICLE SPECIFICATIONS Standard 185/65 R14 Option 195/55 R15 J010A01FC-EAT 205/55 R15 (1.8 DOHC only) MEASUREMENT in. (mm) Overall length 158.4 (4,025) J030B01FC-DAT SPARE TYRE Overall width 68.5 (1,740) Overall height (unladen) 64.3 (1,635) Standard Temporary *66.3 (1,685) Option...
  • Page 307 VEHICLE SPECIFICATIONS J070A02FC-EAT ENGINE GASOLINE DIESEL ITEMS 1.6/1.8 4Cylinder in-line DOHC 1.5 4Cylinder in-line SOHC Engine Type A/CON OFF 800 ± 100 (1.6L), 750 ± 100 (1.8L) 800 ± 100 Idle Speed (RPM) A/CON ON 800 ± 100 (1.6L), 800 ± 100 (1.8L) 800 ±...
  • Page 308 MAX. 1 L / 1,500 Km Severe driving condition MAX. 1L / 1,000 Km Manual HYUNDAI GENUINE PARTS MTF 75W/90 (API GL-4) 2.15 (2.3 us. qts., 1.86 Imp. qts) Transaxle 6.1 (6.4 us qts., 5.3 lmp. qts) (1.6 DOHC) Auto DIAMOND ATF SP-III, SK ATF SP-III 6.7 (7.0 us qts., 5.8 lmp.

  • Page 309: Index

    INDEX CATALYTIC CONVERTOR OPERATING PRECAUTIONS ..... 7-1 JK000A1-A 10. INDEX CENTRE VENTILATOR ..............1-52 CENTRAL DOOR LOCKS ............... 1-5 CHANGING A FLAT TYRE .............. 3-4 CHECKING THE CLUTCH FLUID ..........6-14 ACCESSORY TRAY ..............1-47 CHILD-PROOF REAR DOOR LOCK ..........1-4 AIR CONDITIONING SWITCH ............
  • Page 310 INDEX ENGINE COMPARTMENT ............. 6-1 ~ 6-3 HEADLIGHT LEVELING DEVICE SYSTEM ......... 1-41 ENGINE COOLANT CHECKING AND REPLACING ......6-7 HEAD RESTRAINT ADJUSTMENT ........1-9, 1-11 ENGINE OIL AND FILTER REPLACEMENT ........6-6 HEATED REAR WINDOW ............. 1-38 ENGINE OIL CONSUMPTION ............6-6 HEATING CONTROL ..............
  • Page 311 POWER STEERING FLUID LEVEL ..........6-18 SIDE VENTILATOR ............... 1-52 POWER STEERING HOSES ............6-19 SMOOTH CORNERING ..............2-11 POWER WINDOW ................1-7 SNOW TYRES ................8-1 PROTECTING YOUR HYUNDAI FROM CORROSION ....4-1 SPARE WHEEL ................3-3 SPARKING PLUG REPLACEMENT ..........6-9 10-3...
  • Page 312 INDEX SPECTACLE CASE ............... 1-43 SUPPLEMENTAL RESTRAINT (AIRBAG) SYSTEM ... 1-21 ~ 1-25 VEHICLE IDENTIFICATION NUMBER ..........8-1 STARTING THE ENGINE ............... 2-3 VEHICLE TOWING OR RECOVERY ..........3-7 STEERING WHEEL FREEPLAY ........... 6-15 STEERING WHEEL TILT LEVER ..........1-51 STEREO SOUND SYSTEM ..........

Table of Contents
