Crestron C2N-SSC-2
Uploading a SIMPL Windows Program
A control
The SIMPL Windows file can be uploaded to the control system using
system
SIMPL Windows or via the Crestron Viewport.
source file
has the
Upload via SIMPL Windows
extension
.smw. A
compiled
SIMPL
Windows file
has the
extension
.spz for a 2-
Series
control
Upload via Crestron Viewport
system, .bin
for CNX
generation,
and .csz for
CNX
generation
with
SIMPL+.
File Transfer | Send Program Command
NOTE: Refer to the latest version of the Crestron 2-Series Control
Systems Reference Guide (Doc. 6256) or the respective Operations
Operations & Installation Guide - DOC. 6318
1.
Start SIMPL Windows.
2.
Select File | Open to view the "Open" window,
navigate to the SIMPL Window file (.smw),
and click Open.
3.
Select Project | Transfer Program.
1.
Verify that the procedure for "Communication Settings" that
begins on page 27 has been performed.
2.
As shown after this step, select File Transfer | Send
Program (alternatively, press Alt+P) from the Viewport
menu bar.
3.
The "Send Program" window appears, as shown on the next
page. Click Browse, locate the compiled file (.spz for PRO2)
and click Open. This will display the program's header
information and enable one or both of the What to Send check
boxes. If the program does not contain any SIMPL+ modules,
only the SIMPL Program check box will be enabled. If it does
contain SIMPL+ modules, then the SIMPL+ Program(s)
check box will also be enabled. Select one or both check
boxes and then click Send Program to begin the transfer.
ILT Shade Controller
ILT Shade Controller: C2N-SSC-2 •
31
