C2N-SSC-2 Symbol Signal Descriptions (continued)
Signal Type & Name
Analog input:
<Sh1_Preset#>
Analog input:
<Sh1_Position>
Analog output:
<Sh1_PosReport>
Analog input:
<Sh1_JogTime>

Example Program

An example program for the Shade Controller is available from the
"Example Programs" section of the Crestron website
(http://www.crestron.com/exampleprograms). Search for C2N-SSC-2.zip.
26 • ILT Shade Controller: C2N-SSC-2
Crestron C2N-SSC-2
Description
Sets the preset number for which a position
will be saved (on the rising edge of
<Sh1_SetPreset>) or recalled (on the rising
edge of <Sh1_RecallPreset>).
Valid values range from 1d to 20d.
Out of range values will cause the save and
recall inputs to have no effect.
Sets Shade 1 position relative to the full range
of travel between the upper and lower limits.
Valid values range from 0d to 65,535d, which
is 0000h to FFFFh (upper limit).
Note: Only the most significant bits affect the
position.
0000h = No movement.
00xxh (where xx is any value between 01 and
FF) = Lower limit.
FFxxh (where xx is any value between 100
and FF) = Upper limit.
Reports the position of Shade 1 on the rising
edge of <Sh1_ReportPos>, and all
subsequent changes in position for as long as
<Sh1_ReportPos> is high.
Reported values range from 0d to 65,535d,
which is 0000h to FFFFh (upper limit).
Note: Only the most significant bits are
recognized position changes.
Defines the period that Shade 1 will jog open
or jog closed.
Valid values range from 0.05s (0.05 seconds)
to 2s (2 seconds).
Values above 2s will set the jog time to 2
seconds; values below 0.05s will set the jog
time to 0.05s.
