C2N-SSC-2 Symbol Signal Descriptions (continued)
Signal Type & Name
Digital input:
<Sh1_ReportPos>
Digital input:
<Sh1_UpperLimUp>
Digital input:
<Sh1_UpperLimDn>
Digital input:
<Sh1_LowerLimUp>
Digital input:
<Sh1_LowerLimDn>
Digital input:
<Sh1_Reverse>
(continued on next page)
Operations & Installation Guide - DOC. 6318
ILT Shade Controller
Description
Reports the position of Shade 1 (via
<Sh1_PosReport>) with each rising edge of
the input.
Subsequent changes in position are reported
for as long as the input remains high.
High/1 (rising edge and level sensitive) =
Report position;
Low/0 = Disable reporting
Opens Shade 1 while the input is high, and
sets the upper travel limit on release.
Turns on SETUP LED for 20 seconds.
High/1(level sensitive) = Shade up;
Low/0 (falling edge) = Stop and set upper limit
Closes Shade 1 while the input is high, and
sets the upper travel limit on release.
Turns on SETUP LED for 20 seconds.
High/1 (level sensitive) = Close shade;
Low/0 (falling edge) = Stop and set upper limit
Opens Shade 1 while the input is high, and
sets the lower travel limit on release.
Turns on SETUP LED for 20 seconds.
High/1 (level sensitive) = Shade up;
Low/0 (falling edge) = Stop and set lower limit
Closes Shade 1 while the input is high, and
sets the lower travel limit on release.
Turns on SETUP LED for 20 seconds.
High/1 (level sensitive) = Shade down;
Low/0 (falling edge) = Stop and set lower limit
Reverses motor direction on the rising edge of
the input.
Reversing direction sets the upper and lower
limits to the current shade position, resulting in
no movement if a position input is asserted.
Therefore, upper and lower limits must be
reset after the reverse command is triggered.
For most applications, reverse command is set
only once, if necessary, during installation.
High/1 (rising edge) = Reverse motor rotation;
Low/0 = No effect
