The following table lists the symbol input and output signals and their
functional descriptions. The table lists the signals and descriptions for
shade 1 (Sh1); the same signals repeat for shade 2 (Sh2).
C2N-SSC-2 Symbol Signal Descriptions
Signal Type & Name
Digital input:
<Sh1_OpenMomentary>
Digital input:
<Sh1_CloseMomentary>
Digital input:
<Sh1_OpenFull>
Digital input:
<Sh1_CloseFull>
Digital input:
<Sh1_Stop>
Digital input:
<Sh1_OpenJog>
Digital input:
<Sh1_CloseJog>
(continued on next page)
Operations & Installation Guide - DOC. 6318
ILT Shade Controller
Description
Opens Shade 1 toward the upper limit of travel
on the rising edge of the input, and stops on
release.
High/1 (rising edge) = Open;
Low/0 (falling edge) = Stop
Closes Shade 1 toward the lower limit of travel
on the rising edge of the input, and stops on
release.
High/1 (rising edge) = Close;
Low/0 (falling edge) = Stop
Opens Shade 1 to the upper limit of travel on
the rising edge of the input.
High/1 (rising edge) = Open full;
Low/0 = No effect
Closes Shade 1 to the lower limit of travel on
the rising edge of the input.
High/1 (rising edge) = Close full;
Low/0 = No effect
Stops Shade 1 movement on the rising edge
of the input.
High/1 (rising edge) = Stop;
Low/0 = No effect
Opens Shade 1 toward the upper limit of travel
for <Sh1_JogTime> seconds, on the rising
edge of the input.
High/1 (rising edge) = Jog open;
Low/0 = No effect
Closes Shade 1 toward the lower limit of travel
for <Sh1_JogTime> seconds, on the rising
edge of the input.
High/1 (rising edge) = Jog close;
Low/0 = No effect
