Advertisement
π
H-2861
Sofpull
automatic
®
paper towel diSpenSer
tooLs neeDeD
Drill
attention: read all instructions before using
the towel dispensing system.
TO rEDucE THE rISk OF BurnS, FIrE, ElEcTrIcAl
SHOck Or Injury TO PErSOnS:
1. close supervision is necessary when this furnishing is
used by children or disabled persons.
2. use this furnishing only for its intended use
as described in these instructions. Do not
use attachments not recommended by the
manufacturer.
3. never operate this furnishing if it is not working
properly, if it has been dropped or damaged, or
dropped into water. return the furnishing to a
service center for examination and repair.
note: recommended mounting height is 44"
from the floor to bottom of dispenser.
1.
Press button on top of dispenser to open cover.
(See Figure 1)
PAGE 1 OF 3
1-800-295-5510
uline.com
Drill Bit
Phillips Screwdriver
Dispenser x 1
important safety instructions
mounting instructions
parts
note: this dispenser runs on four D-cell alkaline
batteries, which are not included with product.
note: mounting hardware is not included with
this item. When mounting dispenser, ensure
that proper mounting hardware is used for
appropriate wall composition.
4. never operate the furnishing with the air openings
blocked. keep the air openings free of lint, hair and
the like.
5. never drop or insert any foreign object into any
opening.
6. Do not use outdoors.
7.
Do not operate where aerosol (spray) products are
being used or where oxygen is being administered.
8. Do not mix old and new batteries.
9. Do not mix non-rechargeable and rechargeable
batteries.
Figure 1
0514 IH-2861
Advertisement
Table of Contents
Related Manuals for U-Line SOFPULL H-2861
Summary of Contents for U-Line SOFPULL H-2861
- Page 1 π H-2861 1-800-295-5510 uline.com Sofpull automatic ® paper towel diSpenSer tooLs neeDeD Drill Drill Bit Phillips Screwdriver parts note: this dispenser runs on four D-cell alkaline batteries, which are not included with product. Dispenser x 1 note: mounting hardware is not included with this item.
- Page 2 mounting instructions continueD 2. Open dispenser cover completely and hold dispenser 3. using a pencil, mark the four holes on the wall where to ideal mounting place on wall. (See Figure 2) screws will be inserted. (See Figure 2) 4. Set dispenser aside and drill into wall at four marked Figure 2 locations with an appropriate drill bit.
- Page 3 LoaDing instructions continueD lOADInG THE PAPEr TOwElS 2. Push the end of the paper in between the two feed rollers. (See Figure 7) with dispenser cover open, place the roll of paper towels on the roll holder supports located inside the Figure 7 dispenser.
