H-2590
HEAVY DUTY AUTOMATIC
TAPE DISPENSER
1. When using automatic feed, remove the first piece
of tape. The unit will automatically feed and cut the
next piece at the preset length.
2. Feed length can be easily set using thumbwheel
controls.
6. Tape Length Display – Shows preset feed length.
Four-digit display can be set from 50-9999mm
(2" - 393").
7. Interval Knob – Sets delay time before dispensing
next piece.
8. Auto/Manual Switch – Toggles operating mode
between manual (press tape advance button
to dispense) and auto (automatic feed and cut
when piece is removed).
PAGE 1 OF 3
1-800-295-5510
uline.com
HOLD DOWN SHAFT
(UNDER TOP COVER)
MODE SELECTION
(MANUAL, AUTO & INTERVAL)
TAPE LENGTH DISPLAY
INTERVAL KNOB
FEATURES
3. Hold down shaft increases accuracy by maximizing
tape adhesion to the feed rollers.
4. The blade is easy to remove and replace.
5. Optional serrated blade for hard to cut materials.
ALARM
9. Power Switch – Press to turn power on and off.
10. Tape Advance Button – Press to feed and cut one
piece of tape to the preset length.
11. Hold Down Shaft – Increases adhesion to feed roller.
12. Reel Holder – 3" core to hold material.
13. Alarm – Lights when there is a malfunction in the unit.
REEL HOLDER
TAPE ADVANCE BUTTON
POWER SWITCH
0810 IH-2590
