bar nut, through the third and fourth mounting holes of the bottom 5 Us. Slide the rail teeth over
the screws and tighten. Ensure the rail teeth are between the bar nut and the mounting holes.
Refer to the following figure.
Bar Nut
Teeth
Rack Rail
Mounting
Holes
Button-Head
Screws
5
