iM3 Revolution 4DC-Mobile Installation Manual page 35

iM3 Revolution 4DC- Mobile Installation Manual
Appendix 5 Cont.
4. T06: SELECT WIRELESS CHANNEL
Pressing and keys at the same time will enable or disable the icon If icon
is not displayed in T06 menu, please enable this setting. This setting will check whether selected channel
is busy and will set to the first free channel available.
To select desired Wireless Channel:
Once you hit at T06, you will enter Wireless Channel selection menu. Use or
to toggle through channels. When you are on the desired channel, hit to save settings. A
beep will be heard on Tube head and on remote, then remote will return to T06 Menu screen if
successful. If handheld unit displays EE, the procedure was not successfully completed.
Once settings are saved, hit to back out of Technical Menu and again to back out of
Parameters Menu. Wireless Remote will now run on desired channel and remote should display "Ready"
with signal bars.
32
