iM3 Revolution 4DC- Mobile Installation Manual
Revision History
Date
9/11/17
9/19/17
9/20/17
9/22/17
3/14/18
4/6/18
4/11/18
7/9/18
7/12/18
10/18/19
iM3 Revolution 4DC- Mobile Installation Manual, version 4.5
Version
2.1
2.2
2.3
3.0
4.0
4.1
4.2
4.3
4.4
4.5
Author
Alan Fennell
Alan Fennell
Jeremy Moran
Alan Fennell
Alan Fennell
Alan Fennell
Alan Fennell
Alan Fennell
Jeremy Moran
Alan Fennell
Description
Add Warning Labels
Add Remote Sync Instructions
Update Base instructions, wiring
for power connector, securing
remote to wall mount
Base and Scissor arm orientation
Update Contact Info. Add new
remote image. Update base
instructions. Add new image of
Revolution.
Update White 3pin Scissor Arm
Molex connector note. Pg 13, 14.
Update Attaching Generator
Head Instructions, P. 17
Update to Step 10. P. 20, Added
Step 11: Check for Arm Drift. P.
20. Added Step 12: Check tube
head rotation. P. 20. Added Step
13: Calibration Test. P.20. Added
Appendix 1-4. P. 24-29
Update to Step 6: Added Main
Board layout description. Added
Step to include how to change
WiFi Channel. Added Appendix 5.
Updated
Title/Footer/Header/Index.
Update to Step 12. Added tube
head/scissor arm
functionality/performance test.
Updated Actuator adjustment
instructions. Updated Office
Hours.
