Step 10- Test Fire Generator Tube Head/Check Remote Sync
Tools Required: None
Hardware Required: None
Parts Required: Generator Remote Controller
Description: Test fire generator to check for proper synchronization of remote to tube head. If when remote is turned on it does
not read "Ready" and cannot fire test shot, please see Appendix 1 on page 24 on how to resync remote to tube head.
Step 11- Correcting E301/E302 Error Code
Tools Required: None
Hardware Required: None
Parts Required: Generator Remote Controller
Description: If upon test fire of generator, remote displays E301 error code, this error refers to action taken by user of not
holding shoot button down long enough. To clear error, hit on remote and try again with holding shoot button down
longer. If E302 error code displays, please see Appendix 5 on page 31 on how to change WiFi Channel on remote control.
Step 12- Tube Head/Scissor arm Functionality/Performance Test.
and
Tools Required for Scissor Arm/Actuator adjustment: #2 Phillips Screwdriver, 3mm, 4mm, and 5mm Allen Wrench,
Flathead Jeweler screwdriver.
Parts Required: None
Description of Functionality/Performance Test:
With generator turned on, engage/disengage touch pads on tube head in rapid succession (2 touches per second) at least 15
times, ensuring tube head unlocks and locks properly each time. If tube head fails to unlock during this test, an actuator
adjustment is needed. See Appendix 3 on page 28/29 on how to correct.
Next, while moving tube head in various positions/angles, check if scissor arm is drifting horizontally/vertically. If drift is present
(more than 1 inch), see Appendix 2 on page 26/27 on how to correct.
If you need assistance with test or correction of issue, please call iM3 Technical Support line at 1-844-838-3092.
Step 13: Calibration Test
Tools Required: None
Hardware Required: None
Parts Required: Generator Remote Controller
Description: If after installation you receive a low/high voltage error message on remote control and/or if remote latency has
increased beyond limits as indicated in technical manual, a calibration of the x-ray tube head may be required. Please call iM3
Technical Support line and see Appendix 4 on page 29 on how to conduct calibration test.
