Appendix 1: How to Resync Remote to Tube Head

If the remote control or the generator head needs to be replaced it is only necessary to
associate the remote control with the head. To do this, you first need to set the head in
combination mode (an operation that can be done in two different way) then send a
recognition signal from the heads remote control.
1). Setting the head in combination mode:
This procedure can only be activated within ten seconds of the generator unit being turned
on.
a). With unit turned off, remove the collimator from the head, then turn on the generator unit.
You will hear a beep, wait for a few seconds until the light on the head turns violet, then tap the
collimator black microswitch seven times (black microswitch is located inside on right side
where base of collimator would be). The head will emit a beep that confirms the head has
switched to combination mode and the LED on the head will flash once and stay solid violet.
2). Send the recognition signal from the remote control to the head:
a). Turn on the remote by pressing
b). Hit both
complete steps below or remote will time out and have to start over.
c). Hit
d). Once at P08, hit both
e). Hit
f). Once at T02, hit
hear a 5 second beep. If synchronization is successful, unit will restart and display signal bars
and "Ready" at top of remote.
Revolution 4DC Remote Control Sync Instructions
and
to go into menu starting at P01. You have 8 seconds to
until you get to P08.
and
to go to T02.
. After this, PA01 will display. Wait for a few seconds. You will
to go into menu starting at T01.
