Commend C-GEC881S.C Service Manual page 6

Technical Data
Technical Data AL10-16
Load rating / music power:
Impedance:
Sound Pressure Level:
Max. Sound Pressure Level:
Transmission range (–3 dB):
Transmission angle (–6 dB):
Material:
Net weight:
Connection:
Accessories (included):
Dimensions (including brackets):
Colours:
Technical Data PA 24W15V
Primary:
Secondary:
Efficiency:
Temperature range:
Measurements:
Weight:
Colour:
Cable length:
Technical Data Power Cable
Types:
Cable length:
Technical Data KABJTAG3
Weight:
Cable length:
6
GEC 880 Service Manual
220 - 16 000 Hz
Horizontal (3 m): 1/4/8 kHz: 220°/60°/60°
Vertical (3 m): 1/4/8 kHz: 140°/100°/30°
housing: plastic, grille: metal
2-core cable (50 cm)
U-type mounting bracket
W 100 mm, H 300 mm, D 98 mm
(3.9" x 11.8" x 3.9")
Black (AL10-16S), White (AL10-16W)
90 – 264 VAC (47 - 63 Hz)
14,5 – 15,5 VDC, 1,6 ADC, 24 W
–5° C bis +40° C (23°F 104°F)
W 54 mm x H 110 mm x D 38 mm
(2.12 x 4.33 x 1.49 in)
KAB-C13-AU (Australia)
KAB-C13-EU (Europe)
KAB-C13-UK (Great Britain)
KAB-C13-US (USA)
150 cm (60 in)
12/15 W
16 Ohm
94 dB/W/m
110 dB (1 m)
1,600 g
75 – 85%
approx. 175 g
black
1.5 m (4.9 ft)
1.5 m (4.9 ft)
approx. 73 g
1.2/0111
