Block Error Messages - Labnet MultiGene Mini Operation Manual

2 Error Messages
No.
Error Message when running "Please contact the
1
distributor"， with "AD1213 failure"
Error Message when running "Please contact the
2 distributor."， with "Heatsink temperature is
too high"
Error Message when running "Please contact the
3 distributor."，
disconnected."
Error Message when running "Please contact the
4 distributor."，and "Temperature sensor No.1 is
disconnected."
Error Message when running "Please contact the
5 distributor."，and "Temperature sensor No.1 is
short-circuited."
Error Message when running "Please contact the
6 distributor."，and
disconnected"
Error Message when running "Please contact the
7 distributor."，and "Hotlid sensor is short-
circuited."
Note: During the warranty term, please contact Labnet or your distributor. If the instrument is opened
by an unauthorized individual the warranty is void.
Error Message
and "Heatsink sensor
"Hotlid sensor
Possible Reasons
The microchip can not communicate with the
AD1213. AD1213 broken or circuit board trouble.
Heat sink temp.
temperature sensor is broken, there is a short
circuit or the fan is not working.
Heat sink temp. less than 5℃，the sensor broken,
is
there is a short circuit or the fan is not working.
Block sensor No.1 reports an open circuit
Block sensor No.1 reports a short circuit
is Hot-lid sensor reports an open circuit
Hot-lid sensor reports a short circuit
15
higher than 70℃，the
