1. Specifications

1.1. L-1X & L-1X16
WATER CONSUMPTION
PER RACK
PER HOUR
OPERATING CYCLE
WASH TIME-SEC
RINSE TIME-SEC
DWELL TIME-SEC
TOTAL CYCLE
OPERATING CAPACITY
RACKS PER HOUR
WASH TANK CAPACITY
PUMP CAPACITY
WATER REQUIREMENTS
WATER INLET
DRAIN CONNECTION
CYCLE TEMPERATURES
WASH-°F (Min)
FRAME DIMENSIONS
DEPTH
WIDTH
L-1X HEIGHT
L-1X16 HEIGHT
L-1X MAX CLEARANCE FOR DISHES
L-1X16 MAX CLEARANCE FOR DISHES
ELECTRICAL*
SUSTAINER HEATER
(Not Booster Heater)
WASH PUMP MOTOR
*MUST CONNECT TO DEDICATED 20 AMP SUPPLY CIRCUIT.
COMPLIANCE WITH LOCAL ELECTRICAL CODES MUST BE FOLLOWED.
SHIPPING WEIGHT
L-1X (Approximate)
L-1X16 (Approximate)
MODEL L-1X & L-1X16 INSTALLATION & OPERATION MANUAL Rev. 1.15
METRIC
EQUIVALENT
1.7 GAL. 6.44 L
40.8 GAL. 154.4 L
57 57
48 48
15 15
2 MIN. 2 MIN.
24 24
1.7 GAL. 6.44 L
35 GPM 132.5 LPM
140°F 60°C
½" —
1" —
140 60°C
23 ½" 59.69 cm
24" 60.96 cm
30" 76.2 cm
33 ¾" 85.73 cm
12 ¼" 31.11 cm
16" 40.64 cm
115 VAC
15.8 AMPS
0.8 kW
13.4 AMPS
190# 86.2 kg
195# 88.5 kg
