PROBLEM
Low heat during operation
Low spray arm water flow
With power on, activating
start switch does not begin
cycle
Start switch requires more
than 1-second activation to
run cycle
Activating fill switch does
not fill machine
Fill water won't shut off
Activating drain switch
does not drain machine
Detergent pump does not
run
Sani pump does not run
*The timer assembly motor (
independently if that is the only component that has failed.
MODEL L-1X & L-1X16 PARTS MANUAL Rev. 1.15
LIKELY CAUSE
Low incoming water temperature
(below 140° F)
Thermostat out of adjustment
(Optional) sustainer heater not
installed
Defective sustainer heater
Limed up spray arm nozzles
Defective fill/start switch (cycle
light will not light either)
Defective timer assembly
(Cam 1)
Defective (Instant Start) ice cube
relay
Defective fill/start switch
Defective water solenoid valve
Defective water solenoid valve
Defective fill/start switch
Defective timer assembly
(Cam 4)
Drain hose is kinked
Defective drain switch
Defective drain valve motor
(Pump will still run)
Defective detergent pump motor
Defective timer assembly
(Cam 2)
Defective sani pump motor
Defective timer assembly
(Cam 5)
) or micro switches (
P/N: 00501.00
Electrical Diagram
SOLUTION
Turn up supply water heater
Insulate supply water pipe
Adjust thermostat
Install (optional) sustainer
heater
P/N: 04109.10
Replace heater
P/N: 04109.10
De-lime spray arm nozzles
Replace fill/start switch
P/N: 03470.01
Replace timer assembly*
P/N: 00408.80
Replace ice cube relay
P/N: 00631.00
Replace fill/start switch
P/N: 03470.01
Replace water solenoid valve
P/N: 03603.10
Replace water solenoid valve
P/N: 03603.10
Replace fill/start switch
P/N: 03470.01
Replace timer assembly*
P/N: 00408.80
Un-kink drain hose
Replace drain switch
P/N: 03406.64
Replace drain valve motor
P/N: 04103.21
Replace pump motor
P/N: 00416.00
Replace timer assembly*
P/N: 00408.80
Replace pump motor
P/N: 00416.00
Replace timer assembly*
P/N: 00408.80
) can be replaced
P/N: 00411.00
Page
13
