LOADING AND SECURING
► Separate both tension chains from
each other.
ü
The tension chains have been re-
leased.
8.8

Additional aids

Other aids for load securing are, e.g.:
○ Anti-slip mats, to create the highest
possible friction between the load and
the load compartment (the contact
between the load and the load com-
partment must be raised),
○ Rectangular pieces of wood can be
used for support (wider side as a con-
tact surface),
○ Clamping planks and
○ Partition wall locks.
8.9

Using the Multi Safe system

The Multi Safe system includes various
load securing systems with which the
KRONE trailer can be equipped. Informa-
tion on the Multi Safe systems will be
provided below.
8.9.1 Using the Multi-Lock external
frame
KRONE trailers are equipped with a Multi-
lock external frame with universal load se-
curity possibilities. The lashing holes are
distributed along the whole length of the
vehicle at 100-mm intervals. The Multilock
external frame contains over 130 lashing
holes on each side of the vehicle and can
138
support loads of 2,000 daN (~kg) per lash-
ing hole, with a maximum total load of
8,000 daN (~kg) at a length of 1,000 mm.
Fig. 8-8:
1 Lashing hole
Other load securing systems can be
fastened in the Multi Lock external frame,
e.g. Multi Block or Multi Wall.
8.9.2
KRONE trailers can be equipped with Multi
Lash lashing rings. The pivoting lashing
rings allow a tension strap to be attached
above the exterior frame and thus, even
extremely flat loads can be secured.
Fig. 8-9:
1 Multi Lash lashing ring
2 Hole
Operating instructions • Semitrailer • 505369471-04 • 02/2019
1
Multilock external frame
Using the Multi Lash lashing
rings
1
Multi Lash with Multilock external
frame
2
